  • Page 1 MP-6VIP-C+ Motherboard User’s Manual Product Name: MP-6VIP-C+ Manual Revision: English, 1.00 Release Date: January, 2000...
  • Page 2 All trademarks, product names or brand names appearing in this document are registered property of their respective owners. Copyright Magic-Pro Computer Co., LTD. All rights reserved Author : Raymond Printed in Taiwan...

  • Page 3: Table Of Contents

    CONTENT MOTHERBOARD DIAGRAM ............ 5 NOTE: For 100MHz/133MHz CPU environment, the SDRAM sepc must comply with PC-100/PC-133 spec....... 5 STANDARD CMOS SETUP ............ 12 BIOS FEATURES SETUP ............14 CHIPSET FEATURES SETUP ..........18 POWER MANAGEMENT SETUP ........... 21 PnP/PCI CONFIGURATION SETUP ........
  • Page 4 Appendix B Driver installation ..............38 Appendix C THE USAGE OF RT2 ............. 40...
  • Page 5 VIA APOLLO PRO133 SOCKET-370 F E A T U R E PROCESSOR CHIPSET SYSTEM MEMORY SLOT ONBOARD I/O POWER BIOS FORM FACTOR / PCB "...

  • Page 6: Motherboard Diagram

    M O T H E R B O A R D D I A G R A M JP21 JP22 FAN1 JP20 JP20/JP21/JP22 Intel 1-2 SHORT Cyrix 2-3 SHORT 693A Controller JP10 JP11 JP12 JP13 PCI 1 JP14 JP15 JVGA1 PCI 2 596B FAN2...
  • Page 7 C P U C L O C K S E T T I N G CPU Type Configuration CPU MODEL BUS RATIO BUS CLOCK JP12 Celeron 300/66 JP13 (66MHz * 4.5x) JP14 JP15 Celeron 333/66 JP12 (66MHz * 5.0x) JP13 Pentium III 500E/100 JP14 (100MHz * 5.0x)
  • Page 8 J U M P E R S E T T I N G A. : HDD LED B. : INFRARED (IR) C. : POWER SWITCH D. : SUSPEND CONNECTOR E. : SPEAKER F. : RESET SWITCH G. : POWER LED H.
  • Page 9 JP4 / JP5: CPU Host Clock Select CPU Host Clock JP4 / JP5 Auto (default) 100MHz (overlock) JP6: Bus Clock Select Bus Clock Select 100MHz 133MHz Auto Select 66/100/133MHz (default) JP10 / JP11: USB Port Select USB Port JP10 / JP11 Redirect USB port1 to USB connector (default) Redirect USB port1 to AGP...
  • Page 10 JP17: Power Lost Resume This jumper allows user to use the switch of ATX power supply to control ON/ OFF switch directly instead of using the power switch on the motherboard. Power Lost Resume JP17 Enabled ! Normal (default) ! JP20 / JP21 / JP22: Intel / Cyrix CPU Select CPU TYPE JP20...
  • Page 11 JP12 / JP13 / JP14 / JP15: Bus Ratio Select BUS RATIO JP12~JP15 BUS RATIO JP12~JP15 JP12 JP12 JP13 JP13 2.0x 2.5x JP14 JP14 JP15 JP15 JP12 JP12 JP13 JP13 3.0x 3.5x JP14 JP14 JP15 JP15 JP12 JP12 JP13 JP13 4.0x 4.5x JP14...
  • Page 12 BIOS This VIA 82C693A chipset comes with the AWARD BIOS from AWARD Soft- ware Inc. Enter the AWARD BIOS program Main Menu by: 1. Turn on or reboot the system. After a series of diagnostic checks, the following message will appear: PRESS <DEL>...

  • Page 13: Standard Cmos Setup

    BIOS STANDARD CMOS SETUP Standard CMOS Setup allows you to record some basic system hardware con- figuration and set the system clock and error handling. You only need to modify the configuration values of this option when you change your system hardware configuration or the configuration stored in the CMOS memory gets lost or damaged.
  • Page 14 BIOS Set the current date and time. This field records the specification for all non-SCSI Hard Disk Drives installed in your system. Refer to the respective docu- mentation on how to install the drives. Set the field to the type(s) of Floppy Disk drive(s) installed in your system.

  • Page 15: Bios Features Setup

    BIOS BIOS FEATURES SETUP BIOS Features Setup allows you to improve your system performance or set up system features according to your preference. Run the BIOS Features Setup as follows: 1. Choose “BIOS FEATURES SETUP” from the Main Menu and a screen with a list of options will appear.
  • Page 16 BIOS Enabled: Activates automatically when the system boots up causing a warning message to appear if there is anything attempting to access the boot sector or Hard Disk partition table. Disabled: No warning message will appear when there is something attempting to access the boot sector or Hard Disk partition table.
  • Page 17 BIOS Enabled (default): During POST, BIOS checks the track num- ber for Floppy Disk drive to see whether it’s 40 or 80 tracks. Disabled: During POST, BIOS will not check the track num- ber for Floppy Disk drive. On (default): Activate the NumLock function at boot up. Off: Close the NumLock function at boot up.
  • Page 18 BIOS Choose Enabled or Disabled (default). It determines whether or not the MPEG ISA cards can work with PCI / AGP. Non-OS2 (default): For Non-OS/2 operating system. OS: For OS/2 operating system. Enabled (default): Map the VGA BIOS to system RAM. Disabled: Don’t map the VGA BIOS to system RAM.

  • Page 19: Chipset Features Setup

    BIOS CHIPSET FEATURES SETUP Chipset Features Setup changes the values of the chipset registers. These registers control the system options. Run the Chipset Features Setup as follows: 1. Choose “CHIPSET FEATURES SETUP” from the Main Menu and a screen with a list of options will appear. 2.
  • Page 20 BIOS This item allows you to select the value in this field, depend- ing on whether the board has paged DRAMs or EDO (extended data output) DRAMs. The choice: EDO 50ns, EDO 60ns, Slow, Medium, Fast, Turbo You can select CAS latency time in HCLKs of 2/2 or 3/3. The system board designer should have set the values in this field, depending on the DRAM installed.
  • Page 21 BIOS Choose Enabled or Disabled (default). When enabled, the access to the VGA RAM addressed is cached. Choose 4, 8, 16, 32, 64 (default), 128 or 256MB. Memory map and graphics data structures can reside in a Graphics Aperture. This area is like a linear buffer. BIOS will automati- cally report the starting address of this buffer to the O.S.

  • Page 22: Power Management Setup

    BIOS POWER MANAGEMENT SETUP Power Management Setup changes the system power savings function. Run the Power Management Setup as follows: 1. Choose “POWER MANAGEMENT SETUP” from the Main Menu and a screen with a list of options will appear. 2. Use one of the arrow keys to move between options and modify the selected options by using PgUp/PgDn/+/- keys.
  • Page 23 BIOS Enabled: Turn on ACPI function. Disabled (default): Turn off ACPI function. Choose Max. Saving, User Define (default), Disabled, or Min. Saving. Choose Yes (default) or No. You need to choose Yes when the operating system has the APM functions, otherwise choose No.
  • Page 24 BIOS When On of VGA, any activity from one of the listed system peripheral devices or IRQs wakes up the system. Choice: On(default), Off. When On of LPT&COM, any activity from one of the listed system peripheral devices or IRQs wakes up the system. Choice: LPT/COM(default), NONE, LPT or COM.
  • Page 25 BIOS The following is a list of IRQ’s(Interrupt ReQuests), which can be exempted much as the COM ports and LPT ports above can. When an I/O device wants to gain the attention of the operating system, it signals this by causing an IRQ to occur. When the operating system is ready to respond to the request, it interrupts itself and performs the service.

  • Page 26: Pnp/Pci Configuration Setup

    BIOS PnP/PCI CONFIGURATION SETUP PnP/PCI Configuration Setup defines PCI bus slots. Run the PnP/PCI Configuration Setup as follows: 1. Choose “PnP/PCI CONFIGURATION SETUP” from the Main Menu and a screen with a list of options will appear. 2. Use one of the arrow keys to move between options and modify the selected options by using PgUp/PgDn/+/- keys.
  • Page 27 BIOS Yes: OS supportsss Plug and Play function. No (default): OS doesn’t support Plug and Play function. Choose Manual or Auto (default) . The BIOS checks the IRQ/DMA channel number on the ISA and PCI card manu- ally if you choose Manual. And th e IRQ/DMA channel num- ber will be checked automatically if you choose Auto.
  • Page 28 BIOS Enabled (default): Add one IRQ to USB controller. Disabled: Remove IRQ from USB controller. The system will have extra IRQ for other devices but the USB con- troller will still not be diabled (only IRQ was removed) Enabled (default): Add one IRQ to VGA controller. Disabled: Remove IRQ from VGA controller.

  • Page 29: Load Setup Defaults

    BIOS LOAD SETUP DEFAULTS Load Setup Defaults option loads the default system values to the system configuration fields. If the CMOS is corrupted the defaults are loaded automatically. Choose this option and the following message will appear: “Load Setup Defaults (Y/N)? N” To use the Setup Defaults, change the prompt to “Y”...

  • Page 30: Cpu Speed Setting

    BIOS CPU SPEED SETTING CPU Speed Setting option allows user to adjust CPU’s settings and retain some informations inside computer when it is working. Run the Integrated Peripherals as follows: 1. Choose “CPU SPEED SETTING” from the Main Menu and a screen with a list of options will appear.
  • Page 31 BIOS Select the CPU Ratio. The choice: 3.0x (default), 3.5x, 4.0x, 4.5x, 5.0x, 5.5x, 6.0x, 6.5x, 7.0x, 7.5x, 8.0x. Choose Disabled (default) or Enabled. The clock generator will turn off the DIMM clock if this slot is empty. Choose Disabled (default) or Enabled. This function is de- signed to EMI test only.

  • Page 32: Integrated Peripherals

    BIOS INTEGRATED PERIPHERALS Integrated Peripherals option changes the values of the chipset registers. These registers control system options in the computer. Run the Integrated Peripherals as follows: 1. Choose “INTEGRATED PERIPHERALS” from the Main Menu and a screen with a list of options will appear. 2.
  • Page 33 BIOS The chipset contains a PCI IDE interface with support from two IDE channels. Select Enabled to activate the first and/or the second IDE interface. Select Disabled to deactivate an interface, if you install a primary and/or second add-on IDE interface.
  • Page 34 BIOS Choose Standard (default), HPSIR or ASKIR. Choose Half (default) or Full. Choose Lo,Lo (default) / Lo,Hi / Hi,Hi / Hi,Lo. Enabled: Enable delay when transferring data. Disabled (default): Disable delay when transferring data. Choose the printer I/O address: 378H/IRQ7 (default), 3BCH/ IRQ7, 278H/IRQ5 or Disabled.
  • Page 35 BIOS When user sets a password for keyboard, the password user set that return the system to Full On state. Boot up the system via predetermined keyboard hot key. The choice: <Ctrl> + <F1>...<F12> 3. Press <ESC> and follow the screen instructions to save or disregard your setting.

  • Page 36: Supervisor/User Password

    BIOS SUPERVISOR/USER PASSWORD These two options allow you to set your system passwords. Normally, the supervisor has a higher ability to change the CMOS setup option than the user. The way to set up the passwords for both supervisor and user are as follows: 1.

  • Page 37: Ide Hdd Auto Detection

    BIOS IDE HDD AUTO DETECTION IDE HDD Auto Detection detects the parameters of an IDE Hard Disk drive and automatically enters them to the Standard CMOS Setup screen. The screen will ask you to select a specific Hard Disk for Primary Master after you selected this option.

  • Page 38: Flash Memory Update Installation

    Appendix A APPENDIX A FLASH MEMORY UPDATE INSTALLATION...
  • Page 39 Appendix B APPENDIX B DRIVER INSTALLATION If you are using Windows 98 SE, you do not need to install the 4-in-1 driver as the IRQ Routing Driver and the ACPI Registry are already incorpo- rated into the operating system. Users with Windows 98 SE may update the IDE Busmaster and AGP drivers by installing them individually.
  • Page 40 Appendix C APPENDIX C THE USAGE OF RT2 MP-6VIP-C+ Super-Cops III Installation Hardware Monitor...
