- Page 1 Watervue Smart Bathroom TV User Manual Models: 19”, 24”, 27”, 32”, 43”...
-
Page 2: Table Of Contents
Content Safety Information TV Specifications Accessories Overview of Back Panel Remote Control Unit Home Page What’s New Featured APP Apps Sports & Music Settings Media Player TV Apps Input Source Main Menu Troubleshooting... -
Page 3: Safety Information
Safety Information IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufactures instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 4: Tv Specifications
TV Specifications Screen Size 19” Display Type TFT LED Resolution 1366 x 768 Aspect Ratio 16:9 Alimentation DC 12V Audio Output L/R 5W x 2 Dimensions of Front 490mm x 335mm x 5mm Screen Mounting Plate 473mm x 318mm x 51 mm Screen size 24”... - Page 5 TV Specifications Screen Size 27” Screen Size 32” Display Type TFT LED Display Type TFT LED Resolution 1920 x 1080 Resolution 1920 x 1080 Aspect Ratio 16:9 Aspect Ratio 16:9 Alimentation DC 12V Alimentation DC 12V Audio Output L/R 5W x 2 Audio Output L/R 5W x 2 Dimensions of Front...
- Page 6 Energy rating 19” 24” 27” 32” 43”...
- Page 7 EU Declaration of Conformity This product complies with the following standards EMC Directive: 2014/30/EU Low voltage directive: 2014/35/EU RoHS Directive: 2011/65/EC RE Directive: 2014/53/EU Relevant harmonized standards user or other technical specifications in relation to which conformity is declared: Safety EN 60065:2014 EN 55032:2015 EN 61000-3-2:2014...
-
Page 8: Accessories
Accessories Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. Power Cord Mains Adaptor Owner’s Instructions Remote Control Battery (CR2032) -
Page 9: Overview Of Back Panel
Overview of back panel 19”/24”/32”/43” DC 12V COAXIAL OUT DV 12V input. Coaxial Digital audio output. RJ45 HDMl (ARC) Ethernet connection. Connect for HDMI. VIDEO USB 1/2 Connect for VIDEO signal input in Composite mode Connect media stick for content. -
Page 10: Remote Control Unit
Remote Control Unit... - Page 11 Remote Control Unit Button Description POWER Set your TV to power on or standby mode P.MODE Select the picture mode S.MODE Select the sound mode MUTE Press to mute the sound. Press again to regain sound Quick Tune. Quick TV Channel Autotune button AUDIO Press to display the language of the audio in DTV ASPECT...
-
Page 12: Home Page
Home Page What’s New There are recommended videos which can be updated every day. Press ◄/► button to select the video, and then press ENTER key to play video you want. Featured APP There are the recommended APPS in APP Store, press Enter key to download the APPs from the Store, you can go to the APP Store to download other APPS. - Page 13 Home Page Download Netflix from the APP Store.
-
Page 14: Apps
Home Page APPS This is part of the system preset in user installation applications. Press ◄/► button to select APP, and then press ENTER key to run it. User can access the Internet by Browser APP. -
Page 15: Sports & Music
Home Page Sports & Music This part is a sports and music column. Press ◄/► button to select the video, and then press ENTER key to play it. Setting Press ENTER key to access system settings. - Page 16 Home Page Network Settings Press button to select the Network that you want to use. ...
- Page 17 Home Page Time Setting Press key to select the items, and then press ENTER key to modify it. Common...
- Page 18 Home Page Language Setting Press key to select the system Language that you want, then press the Enter key to confirm. As the figure shows,...
- Page 19 Home Page Application Manage Press Enter key to select Installed Applications to see your downloaded apps. You can uninstall apps that you have downloaded with Uninstalled Applications item. as the figure shows:...
- Page 20 Home Page OTA Update...
- Page 21 Home Page System Recovery Click the “FACTORY DATA RESET” button to doe-System Recovery. All apps you have downloaded will be deleted.
- Page 22 Home Page About TV This part shows the system information. As the figure shows,...
-
Page 23: Media Player
Home Page Media Player Note: Before opening MEDIA menu, plug in USB device or memory card Press button to select Media Player in the Home Page, and then press ENTER to access. Press key to select and press ENTER key to enter ... - Page 24 Home Page Photos The picture is for reference only. Press button to select Photo in the main menu, and then press ENTER button to enter. Press EXIT button to return back to the previous menu. You can see the information of the current playing photo after you press the INFO button, then press ► button to ...
- Page 25 Home Page Music The picture is for reference only. Press button to select Music in the main menu, and then press ENTER button to enter. Press EXIT button to return back to the previous menu. Press button to select the song you want to listen, and then press ENTER or ► or ►...
- Page 26 Home Page You can see the information of the current playing song at the left on the menu. Video The picture is for reference only. Press button to select Video in the main menu, then press ENTER button to enter. ...
- Page 27 Home Page Press button to select the folder that you want to view. Press ENTER button to select the sub folder. Press ENTER button or ► button to play, Press ■ button or EXIT button to stop playing. Press the ◄...
-
Page 28: Tv Apps
Home Page & TV Apps Applications The picture is for reference only. Press ◄/► button to select Application in the main menu, then press ENTER button to enter OK. You can install applications by this selection. Press EXIT button to return back to the previous menu. TV Apps INPUT SOURCE 1.Press SOURCE button to display the input source list. -
Page 29: Main Menu
TV Apps Main Menu Press MENU button to display the MAIN OSD MENU. Press ▲/▼ button to select the MENU you want. Press ENTER button or ► button to enter the sub menu, and press ◄ button to return back to the previous menu. Press ▲/▼... - Page 30 TV Apps Picture Mode Press ▲/▼ button to select Picture Mode, then press ENTER button to enter (Available Picture Mode: Standard, Dynamic, Mild, User). You can adjust the value of brightness, contrast, sharpness, colour, when the picture is in User mode. TIPS: You can press P-MODE button on the remote control again and again to change the picture mode directly Colour Temperature Press ▲/▼...
- Page 31 TV Apps Sound Setup 1. Press ▲/▼ button to select the option that you want to adjust in the Sound menu, then press ENTER button to enter. 2. Press ◄/► button to adjust or press ▲/▼ to select, and press ENTER button to select sub menu. 3.
- Page 32 TV Apps Balance Press ▲/▼ button to select Balance, then press ◄/► button to adjust. Then press EXIT button to return back the previous menu directly. Press ▲/▼ button to select AVL, then press ENTER button to adjust. Then press EXIT button to return back the previous menu directly. Digital Audio Output Press ▲/▼...
- Page 33 TV Apps Country Press ▲/▼ button to select Country, and then press ENTER button to confirm Auto Search Press ▲/▼ button to select Auto Search, and then press ENTER button to do auto search DTV Manual Scan Press ▲/▼ button to select, press ◄/► button to adjust, and then press EXIT button to return pre-menu, The menu will appear as follows: Channel Edit Press ▲/▼...
- Page 34 TV Apps The menu will appear as follows: Common Interface Press ▲/▼ button to select Common Interface, and then press ENTER button to enter. You can check the CAM/Cl card information by this menu. DTV Setting Press ▲/▼ button to select DTV Setting, and then press ENTER button to enter. The menu will appear as follows:...
- Page 35 TV Apps Subtitle Display Press ENTER key to enter the sub menu, you can press E N T E R key to select Subtitle ON/OFF. When the subtitle set to ON, you can select subtitle language by Subtitle language item. Press EXIT button to return pre-menu.
- Page 36 TV Apps Teletext Language Press ENTER key to enter the sub menu,you can press ENTER key to select the Teletext Language (West Europe/East Europe/Russian/Arabic). Press EXIT button to return pre-menu. System Lock Press ENTER key to enter the sub menu,you will see a graphic as follows. Enter the default PIN 0000, you will enter the Parental controls menu.
- Page 37 TV Apps Auto Power Down Press ENTER key to enter the sub menu. Press ▲/▼ button to select Off/1 hour/2 hour/3 hour/4 hour item and then press ENTER button to confirm. Press EXIT button to return pre-menu. Record Menu (DTV Source only} Press ENTER key to enter the sub menu,you will see a graphic as follows.
- Page 38 TV Apps OSD Timer (OSD display time) Press ▲/▼ button to select OSD Timer. Press ENTER button to enter. Press ▲/▼ to select Off/10s/20s/30s/40s/50s/60s items and then press ENTER button to confirm. Press EXIT button to return pre-menu. Sleep Timer (power off time) Press ▲/▼...
-
Page 39: Troubleshooting
Troubleshooting Area Problem Potential Cause Solution Check connection between power Power supply not receiving/ No red standby light on TV lead and PSU - green light should giving power be visible on PSU Power Standby light stuck on red Remote not emitting signal Try new battery in the remote Check connection between power Power supply not receiving/... - Page 40 WEEE Compliance Scheme & Netflix We are a producer of Electrical and Electronic Equipment (EEE) and is therefore obligated under the Waste Electrical and Electronic Equipment (WEEE) Regulations. We are fully compliant with all responsibilities as a registered member of UK government approved WEEE Compliance Scheme. We have formally documented policies relating to the WEEE Regulations and we review our processes on a formalised and regular basis to ensure we remain fully compliant.
