Summary of Contents for Carnival King 382IBS250
- Page 1 12/2020 Block ice shaver Item #382IBS250 www.CarnivalKingSupplies.com...
-
Page 2: Items Included With This Unit
www.CarnivalKingSupplies.com | | | | | info@carnivalking.com BLOCK Ice Shaver Machine Manual Items Included with this Unit -Foot Pedal -Circular Ice Block Mold -Drain Hose General Safety Precautions To ensure safe operation, read the following statements carefully. This manual will outline safety warnings and precautions, operating, maintenance, and cleaning. - Page 3 | | | | | info@carnivalking.com BLOCK Ice Shaver Machine Manual Ice Shaver Machine Specs Item # 382IBS250 Ice Block Width/Height 4"–7" / Up to 7" Overall Dimensions 13.5"W x 16.5"D x 34"H Wattage 250W Frame Material Plastic + Aluminum...
-
Page 4: Operation
8. To adjust the ice texture, turn the Blade Adjustment Knob CLOCKWISE for a finer ice texture, COUNTERCLOCKWISE for a coarser ice texture. 9. Top with Carnival King Sno-Cone Syrup, condensed milk, frozen or fresh fruit, or marshmallow fluff! Minimum Maximum 4"... - Page 5 | | | | | info@carnivalking.com BLOCK Ice Shaver Machine Manual Choice and Carnival King Dessert Cups Molds See WebstaurantStore for more options Cleaning To maintain the appearance and increase the service life, clean your unit daily. NOTE: Do not clean the unit with steel wool.
- Page 6 www.CarnivalKingSupplies.com | | | | | info@carnivalking.com BLOCK Ice Shaver Machine Manual...
-
Page 7: Wiring Diagram
www.CarnivalKingSupplies.com | | | | | info@carnivalking.com BLOCK Ice Shaver Machine Manual Parts and Accessories Ice Shaver Machine Specs Parts Parts Name Quantity Name Quantity Number Number Cover Small belt pulley 6*18mm screw 8*16 Inner six angle Screw cap 8*16 Outer six corners Main Screw Shim 4*10mm screw... - Page 8 www.CarnivalKingSupplies.com | | | | | info@carnivalking.com BLOCK Ice Shaver Machine Manual Blade Maintenance & Replacement Instructions REMOVING THE SHAVING PLATE 1. To remove ice shaving plate, unscrew the adjustment knob completely. Then remove the two screws underneath the shaving plate. 2.
-
Page 9: Troubleshooting
www.CarnivalKingSupplies.com | | | | | info@carnivalking.com BLOCK Ice Shaver Machine Manual Troubleshooting Cause Solution Decription Plug is not inserted Insert socket Fail to start Circut breaker in operation Press the reset button Continuous operation may lead to Turn OFF machine and allow Stop during use overheating, which triggers the circuit motor to cool for 30 minutes. - Page 10 The warranty is not transferable. Carnival King Equipment installed in/on a food truck or trailer will be limited to a period of 30 days from the original date of purchase.
