Cautions

1. The unit must only be operated by professional lighting engineer or electrician in accordance with the
Safety requirements of the Chinese People's Republic of operation and installation.
2. Operate strictly with the above instructions, please do not disassemble or repair by yourself. Failure to
professionals repair and maintenance has to buy my factory original parts or the corresponding parameters
of the electronic parts.
3. Fixed installation and prevent being strong vibration or impact.
4. Before connect the power, make sure that power supply good ground, then tighten the electrical components
to avoid electric shock.
5. There are no serviceable parts inside, please do not open it.
6. Transport again, please note shockproof, the best use of the original.

Warnings

1. During installation and maintenance work, please verify that the power cut off.
2. Keep combustible materials and lighting from distance above 0.5meters.
3. The lights on the power requirements of 100-240V, 50-60Hz. If beyond this range, recommended regulator
device, otherwise it will seriously affect life span.

Installation

1. Before installation, make sure that the power supply voltages you are using and line voltage are identified.
2. Professional installation required, please be safe and reliable lighting fixed, and transferred to the
appropriate radiation angle.
3. When installing this equipment, make sure that there are no explosive materials within 0.5 meter. Keep wall
partitions more than 15cm.
4. For the sake of security reasons, the power cord earth ground is very important.

Maintenance

Keep the equipment with Regular maintenance and repair. Due to long-term use of lighting, the light exit lens
surface of dust, air humidity, reducing the lamp output power, resulting in damage to electrical parts. Please use
a damp cloth and water to clean the lens surface, do not use organic detergent by a professional electrician or
lighting of the user. The period of maintenance is subject to three months.

Technical data:

Output
Light source
Electrical
www.ehrlich-licht.eu
M.S.V. Musik-Sound-Vertriebs GmbH
LED stage spot 100W-FR lens
Lux@2m(Minimum facula)
Lux@4m(Minimum facula)
Lux@6m (Minimum facula)
Lux@8m(Minimum facula)
Lux@2m (Maximum facula)
Lux@4m (Maximum facula)
Lux@6m (Maximum facula)
Lux@8m (Maximum facula)
LED
Drive Current
Color temperature
CRI
Input voltage
M.S.V. Musik-Sound-Vertriebs GmbH
office@m-s-v.eu
5800
Lux
1350
Lux
620
Lux
350
Lux
2920
Lux
700
Lux
320
Lux
200
Lux
COB 100W
2.5A
3000K
95
100~240VAC
office@m-s-v.eu
