Quick Start: PTLink for IP60 – Print Server
Section 1: Overview
The PTLink IP60 wireless print module is a print server that allows the Primera IP60 Photo
Printer to receive prints from IPhone/IPad devices. It features two separate network modes:
1. Hotspot network mode (default) allows the iPhone/iPad to connect and print directly to
the IP60 with no other network present. This is great for events where you will not
necessarily have access to a wifi network.
2. Wifi network mode allows users to connect the IP60 to their own wireless network,
making it accessible throughout their personal network infrastructure. This is ideal for
an office where you want easy access to print to the IP60 just by connecting your device
to the same wifi network.
Section 2: First Time Setup
1. Connect PTLink to power using the included micro USB power supply.
2. Connect the IP60 printer to the PTLink module using the included USB cable (a-b).
3. The hotspot network will be activated and PTLink will
create its own Wi-Fi network.
4. Go to Settings – Wifi on your iPhone/iPad. Choose the
new network name that appears in the following
format: Network Name = ptlink-xxxxxx (The
Micro USB Power
Network Name is
printed on a label
found on the back
USB (Connect cable from
Primera IP60 here)
1
Advertisement
Table of Contents
Summary of Contents for Primera PTLink
- Page 1 Primera IP60 here) Section 1: Overview The PTLink IP60 wireless print module is a print server that allows the Primera IP60 Photo Printer to receive prints from IPhone/IPad devices. It features two separate network modes: 1. Hotspot network mode (default) allows the iPhone/iPad to connect and print directly to the IP60 with no other network present.
- Page 2 1. Starting connected to PTLink’s ad-hoc wireless network, navigate using your Safari web browser to ptlink-xxxxxx.local (The numbers/characters which are represented by the xxxxxx will be different for each PTLink module and will be printed on a label attached to your PTLink.) 2.
- Page 3 Section 4: Hotspot Mode 4A: Manually Reverting to Hotspot If you would like to set PTLink back to its original hotspot Wi-Fi network, follow these steps: 1. From an iPhone/iPad device on the same network as the Primera IP60 wireless print module, navigate using the safari web browser to ptlink-xxxxxx.local and type in your...
- Page 4 3. A window will appear. Enter the network name and password you wish to have and press the update button 4. PTLink may take a moment to configure. If you are connected to the hotspot, you will need to select your newly created network inside of the WiFi selection panel of your iPhone/iPad.
- Page 5 Section 7: Troubleshooting 1. I accidentally entered the wrong password for my personal Wi-Fi! PTLink will attempt to make a connection. If it is unsuccessful, it will simply revert back to its own ad-hoc wireless network. 2. Printer cannot be found on personal infrastructure Wi-Fi network! If your printer is not showing up after connecting the Primera IP60 wireless print module to your local network, check to make sure that the switch occurred.
- Page 6 IP60 wireless print module. Check to make sure that you are on the same network that PTLink is connected to. If not connected to any infrastructure networks, you can find PTLink and access its web portal on its self-generated ad-hoc network.
