Summary of Contents for Boston Acoustics Micro90c
- Page 1 System9000 The System9000 is composed of the following: VRS Micro Micro90c Micro90X...
- Page 2 Micro90c Micro90x Micro80x Micro Reference Series...
- Page 3 How to Wire Your Speakers You need to wire your speakers correctly to obtain the best sound quality and the proper image. Wiring should just take a few minutes, but it’s important to do it carefully, since incorrect wiring (such as reversed connections) can result in a poor soundstage or poor bass. We recommend using 18-gauge or larger speaker wire for runs up to 25 feet (8m), and thicker 16-gauge or larger for longer runs.
- Page 4 Placement Micro90c Center Channel Placement Place the Micro90c as close to the TV monitor as possible, with its front panel flush with the front of the television. Self-adhesive rubber feet are included with the Micro90c to protect the TV’s...
- Page 5 An optional pedestal shelf stand/wall-mount bracket (Model MRB) is available for the Micro80x that provides greater positioning flexibility. For more information, contact your dealer or Boston Acoustics directly. Setting Up Your Home Theater System Volume Levels: To obtain the best home theater effect, match the sound levels of each speak- er.
-
Page 6: Specifications
Description Micro90c Center Channel Speaker System The Micro90c center channel speaker system delivers exceptionally articulate on-screen dialog and effects from a small, sleek package. Point-source driver spacing and a low crossover fre- quency assure wide, uniform horizontal dispersion for complete coverage of the listening area. -
Page 7: Limited Warranty
Limited Warranty For five years from the date of purchase, Boston Acoustics will repair for the original owner any defect in materials or workmanship that occurs in normal use of the Micro90c, Micro90x or Micro80x speakers, without charge for parts and labor. - Page 8 VRS Micro Micro Reference Diffuse-Field Surround Speaker System...
- Page 9 Specifications Frequency Response (±3dB) Recommended Amplifier Power Nominal Impedance Sensitivity [1 watt (2.83v) at 1m] Full-Range Driver High-Frequency Driver Crossover Frequency Dimensions (HxWxD) Weight /each Finish Description The VRS Micro is a diffuse-field surround speaker that provides realistic rear channel surround effects with Dolby ProLogic ®...
- Page 10 Diffuse Sound In a movie theater, a diffuse surround sound field is created by using an array of surround speakers around the sides and rear of the theater. Since this is not practical in the home, a diffuse-field speaker achieves the same effect with a single pair of speakers.
- Page 11 Connecting Your VRS Micro Speakers Connect the speaker’s terminals to those on the amplifier or receiver designated for “surround” or “rear channel effects.” Maintain consistency of the + (red) and – (black) connections by using the markings on the wire. We recommend 18-gauge (or heavier) speaker wire for runs up to 25' (8m), and thicker 16-gauge speaker wire for longer runs.
-
Page 12: Room Placement
Room Placement Room placement is one of the most important factors contributing to the quality of home theater sound. Take a few minutes to place your speakers correctly to ensure they will sound their best. Place the VRS Micro speakers on either side of the listening area. - Page 13 Listening Levels and Power-Handling IMPORTANT: Adjusting Listening Volume–To obtain the best home theater effect, balance the sound level of each speaker. Home theater systems contain a test signal that simplifies this proce- dure. Refer to the instructions provided with your surround sound electronics. The power recommendation for the speaker assumes the amplifier is not overdriven, which, over a long period, can damage even our rugged speakers.
- Page 14 ⁄ " (23mm) 1" (25mm) Mounting 1. Make two holes using the bracket as a template. If running wires behind the wall, make a hole for them 1" (25mm) below the bracket (left). 2. Insert the machine screws through the bracket and thread onto the toggle wings before pene- trating the wall (center).
- Page 15 Limited Warranty For five years from the date of purchase, Boston Acoustics will repair for the original owner any defect in materials or workmanship that occurs in normal use of the VRS Micro speaker system, without charge for parts and labor.
