- Page 1 Balt Odyssey 24 Laptop Charging Cart - 27652 Instruction Manual...
- Page 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4...
- Page 3 Odyssey Laptop Charging Cart Part Drawing Description Part Drawing Description Hardware List M6X15mm Socket Screw 32 EA Metal Base 1 EA M6X45 mm Socket Screw 8 EA M6X65 mm Socket Screw 4 EA Top Panel 1 EA Grommet Metal Base 4 EA Shelf 7 EA...
- Page 4 Odyssey Laptop Charging Cart Part Drawing Description Part Drawing Description Hardware List Center Back Panel 1 EA Back Lock 1 EA Lock Clip 1 EA Vertical Support 2 EA Shelf Pin 28 EA Left Door ! EA Door Hinge 4 EA Hinge Screw-Wood 16 EA Hinge Screw-Door...
- Page 5 HROUGH NSTRUCTIONS FROM BEFORE BEGINNING TO END STARTING TO ASSEMBLE UNIT Identify and Separate all the Parts and Hardware. Illustration # 1 2.) Attach two Locking Casters (C) to the bottom front and two Non-Locking Casters (D) to the bottom rear of Metal Base (P-1) using four Screws (A) for each caster.
- Page 6 4.) Attach the Left Side Panel (P5) to the Side Handle (P4) using four Screws (A1) and four Tapped Rivets (G) as shown in Illustration # 3. Illustration # 3 5.) Secure the Left Side Panel (P5) to the Metal Base (P1) using two Screws (A) as shown in Illustration # 4.
- Page 7 6.) Screw in two Cam Posts (I) into the embedded plastic inserts in the Left Side Panel (P5) as shown in Illustration # 5. Install two Cams (H) into the large holes in the Bottom Back Panel (P7-1). Install a Wood Dowel (J) in the center hole on the edge of the Bottom Back Panel (P7-1).
- Page 8 Screw in two Cam Posts (I) into the embedded plastic inserts in the Left Side Panel (P5) as shown in Illustration # 5. Install two Cams (H) into the large holes in the Upper Back Panel (P7). Install a Wood Dowel (J) in the center hole on the edge of the Upper Back Panel (P7). With the Cam’s (H) arrows pointed at the Cam Posts (I), slide the Upper Back Panel (P7) into place and turn the Cams clockwise a quarter turn to the lock position.
- Page 9 10.) Attach the Right Side Panel (P6) to the Side Handle (P4) using four Screws (A1) and four Tapped Rivets (G) as shown in Illustration # 9. Illustration # 9 11.) Secure the Right Side Panel (P6) to the Metal Base (P1) using two Screws (A) as shown in Illustration # 10.
- Page 10 12.) Insert two Cams (H) into the top of the Left Side Panel (P5) and one into the top left of the Back Panel (P7) making sure the arrow on the Cams (H) are pointed up. Press in two Wood Dowels (J) into the top edge of the Left Side Panel (P5).
- Page 11 14.) Attach two Electrical Mounts (K) to the top Back Panel (P7) and two to the bottom Back Panel (P7) using one Electrical Mount Screw (L) into each embedded threaded insert as shown in Illustration # 13. Illustration # 13 Snap in a large Electrical Strip (M) into the top Electrical Mounts (K) with the cord exiting to the 15.) right.
- Page 12 Insert the Shelf Pins (R) into the predrilled shelf location holes in the Right Side Panel (P6) and the 16.) Left Side Panel (P5) as shown in Illustration #15a. Place each Shelf (P3) on the Shelf Pins (R) making sure the notches in the side flanges on each Shelf (P3) hook onto the Shelf Pins (R). Illustration # 15 Illustration # 15a 17.)
- Page 13 18.) Attach two Door Hinges (S) to the Left Side Panel (P5) using four Hinge Screws -Wood (T) into the prdrilled locate holes for each hinge. Attach the Left Door (P12) to the Door Hinges (S) using two Hinge Screws-Metal (U) as shown in Illustration #17. Illustration # 17 19.) Repeat Step 18 to install the Right Door (P13) to the Right Side Panel (P6) as shown in...
- Page 14 Side Panel (P5) Illustration # 19 21.) Install Magnet (X) under the Top Panel (P2) in the front center so it catches and holds the Left Door (P12) when it is closed. Use two Magnet Screws (Y) to secure. 27652,27655_5-14-14 WWW.MYBINDING.COM...
