EN.IO.WW.11.ALW INTRODUCTION The subject of manual is display type WW-11ALW. The manual applies to the standar and intrinsically safe Exi versions. The manual contains data, tips and general recommendations for safe installation and operation of the display, as well as troubleshooting in case of possible failure.
GUARANTEE General terms and conditions of guarantee are available on the manufacturer’s website: www.aplisens.com/ogolne_warunki_gwarancji The guarantee shall be repealed if the display is used against its intended use, failure to comply with user’s manual or interference with the structure of the device.
5.2. Display identification Depending on the version of the display, the nameplates may differ in the amount of information and parameters. Figure 1. Nameplate of the display WW-11ALW in standard version. Logo and name of the manufacturer. CE mark. Product code.
EN.IO.WW.11.ALW Figure 2. Nameplate of the display WW-11ALW in Exi version. Logo and name of the manufacturer. CE mark. Number of notified body supervising the Ex products. Product code. Display type designation. Input signal. Permissible range of ambient temperature. Voltage drop.
EN.IO.WW.11.ALW CERTIFICATES FOR USE IN HAZARDOUS AREAS 6.1. Directive ATEX – intrinsically safe version Displays may be used in potentially explosive atmospheres in accordance with the following explo- sion-proof designations: II 2G Ex ia IIC T4 Gb II 1D Ex ia IIIC T110°C Da KDB 16 ATEX 0006 The displays are designed and manufactured in accordance with requirements of the following stand- ards: EN 60079-0:2012 + A11:2013, EN 60079-11:2012.
7.1. General recommendation WW-11ALW displays are intended for direct mounting on flat surface or on pipe using mounting kit. In order to mount the display on a flat surface, e.g. a wall, the holes fo M6 screws should be prepared for its surface according to the spacing of the holes in the display housing.
Figure 4. Connection diagram for WW-11ALW display without HART communication. In the WW-11ALW display signal cables shall be led to the housing through cable ducts (cable glands) and shall be connected to terminals (1), (2) and (3) of the terminal block according to the dia- gram presented on the fig.4, 5 or 6 and the below table containing numbers of the terminals.
EN.IO.WW.11.ALW 8.3. Electrical connection of display in safe areas Figure 5. Connection diagram of WW-11ALW display in the safe zones. a) Diagram of connection with transmitter; b) diagram of connection with transmitter with Hart communication. In order to communicate with the intelligent transmitter (via HART protocol), before connect-...
The display must be earthed in accordance with local electrical standards. The recommended way to connect earthing for WW-11ALW display is shown in figure 7. Shield of a cable shall be connected from the one side with earth terminal if cable in the shield is used.
EN.IO.WW.11.ALW OPERATION The LCD has three primary information fields in the figure belowa as LCD1, LCD2, LCD3. Figure 8. Display information fields. LCD1 - value of current or guidance percent preset range display. Depending on the display configuration will be displayed the current value of the current line 4…20 mA with a resolution of 0.1 mA, or percent guidance the preset range with a resolution of indications 1%.
EN.IO.WW.11.ALW Figure 10. View of the backlighting jumper of WW-11ALW display in the electronics board (back side of the electronics board). 9.1. Display configuration The user can change the display settings using the buttons below the display. The buttons can be accessed by unscrewing the display cover.
EN.IO.WW.11.ALW Figure 11. Structure of local setpoints MENU. Revision 01.B.003/2020.09...
Page 18
PERCEN Percentage value of input setting will be presented on the display. The WW-11ALW display must be configured or the correctness of indications must be checked after changing the measuring range of the transmitter connected to the display. Revision 01.B.003/2020.09...
EN.IO.WW.11.ALW 9.2. Local Menu, error messages During perform some functions in Local Menu may appear on LCD2 field an error message EXXXX (the letter E and 4 digits error code). The error message indicates that the Local Menu command has not been executed.
