DVD470B
DVD490T
DVD Player with Built in TV Tuner
Congratulations on your purchase
of a
DVD Player.
It has been designed, engineered
and manufactured to bring you the
highest level of performance and
quality, and will afford you years of
listening pleasure.
Thank you for making
choice for car audio entertainment!
page
1
3
3
4
6
8
8
9
10
10
11
12
13
14
your
15
16
17
18
21
22
U S E R ' S M A N U A L
CONTENTS
General and safety precautions
Features
DVD player controls and features
A/V input connections on front panel
Amplfiier connections
TV Mode setup and operation
Playback mode (PBC)
DVD470B/DVD490T User's Manual - Contents
Advertisement
Table of Contents
Related Manuals for Boss Audio Systems DVD-470B
Summary of Contents for Boss Audio Systems DVD-470B
-
Page 1: Table Of Contents
DVD470B DVD Player DVD490T DVD Player with Built in TV Tuner Congratulations on your purchase of a DVD Player. It has been designed, engineered and manufactured to bring you the highest level of performance and quality, and will afford you years of listening pleasure. - Page 2 DVD470B/DVD490T User’s Manual...
- Page 3 General precautions Before installing and using your new DVD Player, please become familiar with all the information contained in this manual. Please keep this manual in a safe place for future reference. Safety precautions • This disc player is a Class 1 Laser Product.
- Page 4 Operating precautions Turn the unit off when it is not in use. Do not switch the player between ON and OFF rapidly. Please wait about 10 seconds between turning the unit ON after turning it OFF, and vice versa. Do not use broken, scratched, dusty, oily or warped discs in the player.
-
Page 5: Dvd Player
Features This DVD player features the following: • Multiformat compatibility: DVD, Video-CD, CD, DVCD, CDR and • Reads 12 cm diameter discs • Front panel AUX video input jack for other sources, such as video games and cameras • Last position memory •... - Page 6 Front Panel Controls POWER Press to turn unit ON or OFF. UP/DOWN/LEFT/RIGHT Use these keys to navigate the menu of a DVD or the system’s menu. ENTER Press this button to execute the selected command, or to select a menu. FAST REVERSE/FAST FORWARD While playing a disc, pressing one of these will cause it to play the disc in...
- Page 7 Front Panel Features DISC SLOT DISPLAY AUDIO INPUTS (R & L) Rear Panel Features RF IN VIDEO OUTPUT LEFT AUDIO OUTPUT RIGHT AUDIO OUTPUT VIDEO INPUT JACK AUX OUTPUT JACK REMOTE SENSOR (EYE) INPUT DIGITAL AUDIO OUTPUT S-VIDEO OUTPUT POWER CONNECTION DVD470B/DVD490T User’s Manual - page 5 (COAXIAL)
- Page 8 Remote Control POWER Press to turn unit ON or OFF. MENU/PBC While playing a DVD, pressing this key displays the disc’s options menu. Press this key to shift to PBC mode. For a DVD/SVCD disc, if PBC is not enabled, press the STOP button, then press MENU/PBC to enable the PBC mode.
- Page 9 FAST REVERSE/FAST FORWARD While playing a disc, pressing one of these will cause it to play the disc in that direction at a faster speed. Press again up to three more times to further increase speed. Press a fifth time to return to normal speed playback.
-
Page 10: Remote Control Battery Replacement
Remote Control Battery Replacement Slide open the battery door on the remote as shown below. Insert two AAA batteries, observing proper polarity as shown on the battery door. Replace the battery door. Remote IR Sensor If you need to mount the DVD player in a location which is inaccessible, or where the line-of-sight between the remote control and the face of the player is interrupted, connect the Remote Sensor as shown in the diagram below. -
Page 11: A/V Output Connections
A/V Output Connections to Video Monitor This disc player sends video output signals simultaneously to both the S-Video and the RCA Video outputs. However, ONLY ONE of these can be connected at a time. Please connect the player using one of the two methods shown. Using standard video output (RCA type) DVD Player Using S-Video output... -
Page 12: Tv Antenna Connection (Dvd490T)
A/V Input Connections (using Front Panel Inputs) This disc player offers you the option of using the auxiliary front panel A/V input jacks to connect a video game, digital camera/camcorder or other units you wish to use in your mobile video system. A/V Input Source Video Game, Camera, etc. - Page 13 Amplifier Connections This disc player offers you a choice of analog (RCA) or digital (coaxial) audio outputs to connect to your amplifier. Using standard audio output (RCA type) Using Digital Audio (coaxial) output TV SET DVD PLAYER – OR – DVD470B/DVD490T User’s Manual - page 11 AUDIO INPUTS AUDIO INPUTS...
-
Page 14: Vehicle Power Connections
Vehicle Power Connections Follow the connection diagram below. The cable provided for this connection has two inline fuses and a choke assembly with fuse. Please note: The yellow wire should be connected directly to the vehicle’s battery. +12V DC (BATT +) Ground (BATT -) Ignition switch (ACC +) - Page 15 TV Mode setup (DVD490T only) To set up the DVD player to use in the TV Tuner mode, press MODE once. Press SETUP and select “Auto Search” from the menu. Press the button. The player will automatically scan for and memorize the available TV channels.
-
Page 16: Basic Operations
Basic operations After installation is complete and you have installed the batteries in the remote control, you are ready to operate the player. Turn on all other related audio and video equipment first. Be sure to check that your TV/Video monitor is switched to the Video Input mode. - Page 17 SELECTING A TRACK There are three basic ways to select a track with the DVD player: 1- using the SKIP buttons ( 2– entering a track number using the numeric keypad, or 3– making a selection from a displayed track list. Using the SKIP buttons to select During playback, you can use the buttons to skip ahead or skip...
-
Page 18: Other Playback Operations
Other playback operations REPEAT PLAY For DVD discs, pressing REPEAT once during playback will repeat the chapter. Press this button again to repeat the title. Pressing a third time will exit the repeat feature. For non-DVD discs, when PBC is off, pressing REPEAT will cause the track currently being played to repeat. -
Page 19: Mp3 Playback
MP3 Playback Playback of MP3 files on this player may be done in one of two different modes: 1– “with menu” mode 2– “no menu” mode The factory default for this player is the “without menu” mode. If you wish to change the MP3 playback mode, please refer to the Settings section in the column entitled “SmartNav Settings”... -
Page 20: System Settings
System Settings Press the SETUP button to display the system setup menu: The Setup Menu Main Page: Highlight indicates the current selection Press the keys to highlight the desired operation. Press ENTER to display the sub-menu for that operation, and press the button to enter the right side of the sub- menu. - Page 21 COAXIAL AUDIO OUTPUT If you are using the coaxial terminal to output the digital audio signal, the system must be set up to either SPDIF/RAW or SPDIF/PCM. Please note: If you are unsure which setting applies to your application, we suggest you first try SPDIF/PCM.
- Page 22 System Settings, continued MENU DISPLAY LANGUAGE This DVD player is programmed to offer you the on-screen menu system in the following five languages: English • French • Spanish • Chinese Japanese Press the SETUP button to display the Setup Menu. Use the to highlight “Preferences.”...
-
Page 23: Troubleshooting
Troubleshooting If you experience operation or performance problems with this product, compare your installation with the electrical wiring diagram on the previous page. If problems persist, read the following troubleshooting tips which may help eliminate the problems. SYMPTOM CAUSE No sound. Volume is set to minimum. -
Page 24: Specifications
Specifications DVD470B Mobile DVD Player DVD490T Mobile DVD Player with Built-in TV Tuner DVD PLAYER Playable disc formats Video formats Audio formats Video signal output Audio signal output Output types Frequency response Audio signal-to-noise ratio Net weight Dimensions Additional specifications for: DVD490T Mobile DVD Player with Built-in TV Tuner TV TUNER...
