- Page 1 Installation Operation Maintenance Parts Manual Air Boss Model 38 Series ® READ AND SAVE THESE INSTRUCTIONS Industrial Mist Precipitator T R I O N | w w w . t r i o n i a q . c o m ®...
-
Page 2: Table Of Contents
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l INDUSTRIAL MIST PRECIPITATOR TYPE IMP AIR BOSS... -
Page 3: Principle Of Operation And General Description
For 220-240 VAC units, a 1.2 Amp fuse is installed for added protection in the terminal block in the field wiring junction box. The TRION part number for the 5 mm x 20 mm fuse is 151678-001. w w w. t r i o n i a q . c o m... -
Page 4: Installation
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l II. -
Page 5: Maintenance
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l IV. -
Page 6: Recommended Spare Parts
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l 3. -
Page 7: Outline Drawings
(L). A third unfused terminal is included for the neutral (N) supply wire. A strain relief connector for connecting a supply cable to the junction box, suitable for cable diameters of 4.8 to 7.9 mm, is furnished. It is packaged with the junction box. 150 CFM PARTS Power Supply TRION Weight Inlet Outlet Part Number Part Number (lbs.) -
Page 8: 150 Cfm - Outline Drawing With Inlet Flange Or Pipe (424396)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l w w w. -
Page 9: 150 Cfm - Outline Drawing With Inlet & Outlet Flange Or Pipe (424397)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l w w w. -
Page 10: 300 Cfm Parts
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l 300 CFM PARTS Power Supply TRION Weight Inlet... -
Page 11: 300 Cfm - Outline Drawing With Inlet Flange Or Pipe (424399)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l w w w. -
Page 12: 300 Cfm - Outline Drawing With Inlet & Outlet Flange Or Pipe (424398)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l w w w. -
Page 13: 600 Cfm Parts
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l 600 CFM PARTS Power Supply TRION Weight Inlet... -
Page 14: 600 Cfm - Outline Drawing (429436)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l w w w. -
Page 15: Electrical Schematic (150, 300, 600 Cfm)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l VIII. -
Page 16: Electrical Parts List (150, 300, 600 Cfm)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l IV. ELECTRICAL PARTS LIST 150 CFM 300 CFM 600 CFM Item TRION Part No. Description 267232-120 Power Supply - 120 VAC Input Voltage 267232-240 Power Supply - 240 VAC Input Voltage... -
Page 17: Diagram
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l V. - Page 18 TRION ® 101 McNeill Rd. | Sanford, NC 27330 P: 800.884.0002 | F: 800.458.2379 | www.trioniaq.com | customerservice@trioniaq.com Form No. 61-0184 Rev. 10/16 © TRION 2016. All Rights Reserved.
