BV9200
In-Dash Double-DIN
DVD/MP3/CD AM/FM Receiver
with 6.5" TFT Monitor
and Built-in TV Tuner
Congratulations on your purchase
of a
Multi-media Receiver
with Monitor.
It has been designed, engineered
and manufactured to bring you the
highest level of performance and
quality, and will afford you years of
listening pleasure.
Thank you for making
choice for car audio entertainment!
U S E R ' S M A N U A L
CONTENTS
page
2
General and safety precautions
3
3
4
6
8
9
9
10
11
Speaker connections
12
Audio connections in amplified system
13
Power and antenna connections
14
Connections to multi-disc changer
14
Basic operations
your
15
Auxiliary video input connections
16
Auxiliary video output connections
16
TV antenna connections
17
20
BV9200 User's Manual - Contents
Advertisement
Table of Contents
Related Manuals for Boss Audio Systems BV9200
Summary of Contents for Boss Audio Systems BV9200
-
Page 1: Table Of Contents
Setup menu structure System wiring: Speaker connections Audio connections in amplified system Power and antenna connections Connections to multi-disc changer Basic operations your Auxiliary video input connections Auxiliary video output connections TV antenna connections Troubleshooting Specifications BV9200 User’s Manual - Contents... -
Page 2: Operating Precautions
There are dangerous voltages present within the unit. There are no user-serviceable parts within the unit. BV9200 User’s Manual - page 2 Operating precautions Turn the unit off when it is not in use. Do not switch the player between ON and OFF rapidly. -
Page 3: Features
• Multiple viewing angles (if available on disc) What is included? When first unpacking your new BV9200, please check first that the package contains all of the items below. If something is missing, contact the store where you purchased it. -
Page 4: Front Panel Controls
UP or DOWN button to change the setting. A picture of the picture options is show on page 9. BV9200 User’s Manual - page 4 MU LTI-MED IA DISC PLAYER 6.5-INC H WIDE SCREEN TFT MONIT OR WITH... -
Page 5: Intro Scan
THREE DIMENSIONAL SOUNDTRACK In DVD mode, a SHORT press of this button will cause the unit to advance to display and advance through the different soundtrack options available on the particular disc you are watching. BV9200 User’s Manual - page 5... -
Page 6: Remote Control Features
Press this button to display the current time of day. SOURCE Press this button to display the current time of day (Note: The BV9200 will only display time in 24 hour clock mode). Pressing this button permits you to choose one of the three preset equalizer curves. - Page 7 Pressing this button opens up the SETUP menu, which permits you to make various system settings (described on page 9). ZOOM If your DVD disc supports zooming into the image, pressing this button will provide this function. BV9200 User’s Manual - page 7...
-
Page 8: Remote Control Battery Replacement
(as shown below) and slide the drawer out. Insert a new battery and push the drawer back fully into the remote. Battery Release button BV9200 User’s Manual - page 8... -
Page 9: Video Quality Settings
Disc Select UP and Disc Select DOWN buttons. ENGLISH INTRO PAL/ NTSC BV9200 User’s Manual - page 9 Current setting BAND... -
Page 10: Setup Menu Structure
The Setup Menu is structured as follows: SET LANGUAGE SET PICTURE SET VOICE LIKE SETTING (Preferences ) EXIT SETUP MENU BV9200 User’s Manual - page 10 Language Selection Voice Language (no options available) Caption Language (no options available) Picture format... -
Page 11: Left Front
System wiring: Speaker connections If you are using the BV9200 in a mobile system which does not include an audio amplifier (so you are using the internal amplifier in the BV9200), connect the speakers to the wiring connector provided as shown in the drawing below. - Page 12 System wiring: Audio connections in an amplified system If you are using the BV9200 in a mobile A/V system which includes a power amplifier and speakers, connect the To FRONT Audio Inputs of amplifier RIGHT FRONT AUDIO OUT (GREY CABLE with RED JACK) BV9200 User’s Manual - page 12...
- Page 13 If not present, ORANGE wire is left unconnected. to Reverse (Backup) Light Switch (+) (do not connect to camera, shown only as example) Chassis ground point Constant +12V (Memory voltage source) to Ignition Switch to Ignition Switch (ACC+) (ACC+) BV9200 User’s Manual - page 13...
-
Page 14: System Wiring
System wiring: Connections to a Multi-Disc Changer (optional) The BV9200 has internal circuitry to permit it to be used to control an external CD changer, such as the BOSS Model CDC3000A or similar compatible models. If you are considering adding a CD changer to your system, please call BOSS Audio technical support to get advice about which changers are compatible with the BV9200. - Page 15 System wiring: Auxiliary video input connections If you are using the BV9200 in a mobile system which does not include an audio amplifier (so you are using the internal amplifier in the BV9200), connect the speakers to the wiring connector provided as shown in the drawing below.
- Page 16 If you have an other video monitor(s) in your vehicle that you wish to display the program playing in the BV9200, connect the monitor as shown in the diagram below. If there is more than one such monitor, you will need to add a video splitter or a multi-channel video signal amplifier to the system as well.
-
Page 17: Lcd Screen Problems
Make sure the vehicle cabin is at room temperature. The display brightness is automatically reduced when the headlights are on. Adjust Color and Tint controls. Set the NTSC/PAL setting properly according to the other video source. BV9200 User’s Manual - page 17... -
Page 18: Disc/Tv Reception/Sound Problems
In the Zone setup, the speakers are front and rear speakers playing from have different sources. different sources. BV9200 User’s Manual - page 18 REMEDY Eject the disc before loading another one. Clean the disc with a soft cloth. Replace with an undamaged disc. -
Page 19: Dvd/Mp3 Playback Problems
DVD playback setup for help. It is normal for dual-layer discs to pause during playback briefly and then resume playback. REMEDY Use only discs which have files storage according to ISO9600 Level 1/Level 2 standards. BV9200 User’s Manual - page 19... -
Page 20: Specifications
GENERAL Input voltage Current consumption Dimensions All specifications subject to change without notice. BV9200 User’s Manual - page 20 6.5-inch wide format (143.4 x 79.33mm) TFT active matrix LCD 1440 x 234 pixels NTSC, PAL, SECAM DVD-Video, Audio CD, Video CD, MP3 CD...
