Summary of Contents for Banner EZ-SCREEN LS2 30-150Q8 Series
- Page 1 ® EZ-SCREEN Type 2 Light Screen Instruction Manual Original Instructions 122452 Rev. H 19 February 2021 © Banner Engineering Corp. All rights reserved 122452...
-
Page 2: Table Of Contents
® EZ-SCREEN Type 2 Light Screen Contents 1 About This Document ..............................4 1.1 Important... Read This Before Proceeding! ............................4 1.1.1 Use of Warnings and Cautions ..............................4 1.2 EU Declaration of Conformity (DoC) ..............................4 2 Introduction ...................................5 2.1 Features ......................................5 2.2 System Description .................................. - Page 3 7.1 Cleaning ......................................42 7.2 Manufacturing Date ..................................42 7.3 Warranty Service ...................................42 7.4 Disposal ......................................42 7.5 Banner Engineering Corp Limited Warranty ..........................42 7.6 Contact Us ..................................... 43 8 Checkout Procedures ..............................44 8.1 Schedule of Checkouts ................................. 44 8.2 Commissioning Checkout ................................
-
Page 4: About This Document
1.2 EU Declaration of Conformity (DoC) Banner Engineering Corp. herewith declares that these products are in conformity with the provisions of the listed directives and all essential health and safety requirements have been met. For the complete DoC, please go to www.bannerengineering.com. -
Page 5: Introduction
Note: This manual refers to an emitter and its receiver, and their cabling as "a System". Banner EZ-SCREEN Type 2 emitters and receivers provide a redundant, microprocessor-controlled, opposed-mode optoelectronic "curtain of light", or "light screen". EZ-SCREEN Type 2 typically is used for point-of-operation safeguarding, and is suited to safeguard a variety of lower-risk machinery. -
Page 6: Appropriate Applications And Limitations
Ensure that all legal requirements have been met and that all technical installation and maintenance instructions contained in this manual are followed. The user has the sole responsibility to ensure that this Banner device is installed and interfaced to the guarded machine by Qualified Persons , in accordance with this manual and applicable safety regulations. -
Page 7: Examples: Appropriate Applications
Failure to follow these instructions could result in serious injury or death. • Use Banner's EZ-SCREEN Type 2 only on machinery that can be stopped immediately after a stop signal is issued at any point in the machine's stroke or cycle, such as part-revolution clutched machines. -
Page 8: Control Reliability And Safety Categories
Replacement of the failed component (to restore the safety function) • The appropriate reset procedure. 2.5 Operating Features The Banner EZ-SCREEN Type 2 Light Screen models described by this manual feature standard functions: • Trip or Latch Output (depending on model) •... -
Page 9: Wiring Options For Emitter/Receiver Swapability
WARNING: Use of Auto (Trip) or Manual (Latch) Start/Restart Application of power to the Banner device, the clearing of the sensing field, or the reset of a manual start/ restart (latch) condition MUST NOT initiate dangerous machine motion. Machine control circuitry must be designed so that one or more initiation devices must be engaged (in a conscious act) to start the machine –... -
Page 10: Status Indicators
® EZ-SCREEN Type 2 Light Screen 2.5.4 Status Indicators Status indicators on both the emitter and receiver are clearly visible on each sensor’s front panel. Figure 2. EZ-SCREEN Type 2 emitter and receiver status indicators Power/Fault LED (Green) Alignment LEDs (Yellow) Status Blocked LED (Red) Status Clear LED (Green) -
Page 11: Mechanical Installation
Ensure that all legal requirements have been met and that all technical installation and maintenance instructions contained in this manual are followed. The user has the sole responsibility to ensure that this Banner device is installed and interfaced to the guarded machine by Qualified Persons , in accordance with this manual and applicable safety regulations. - Page 12 ® EZ-SCREEN Type 2 Light Screen Figure 3. Safety distance (minimum distance) and hard (fixed) guarding Hard (fixed) Guarding Hard (fixed) Guarding Robot Turn- Table Safety Light Curtain/Screen Nearest Hazard Point Reset Switch Models With Response Times Models (see note below) Defined Area Height Number of Beams Response Time (Tr)
- Page 13 ® EZ-SCREEN Type 2 Light Screen U.S. Applications European Applications the Safety Distance, in inches the Minimum Distance, in mm, from danger zone to light screen center line; minimum allowable distance is 100 mm ( 175 mm for non-industrial applications), regardless of calculated value 1600 mm per second (or 63 in per second), the OSHA 29CFR1910.217, and ANSI B11.19 recommended hand-speed constant (see Note 1 below)
-
Page 14: Reducing Or Eliminating Pass-Through Hazards
Failure to observe this warning could result in serious injury or death. • If a Banner device is installed in an application that results in a pass-through hazard (for example, perimeter guarding), either the Banner device or the Machine Primary Control Elements (MPCEs) of the guarded machine must cause a Latched response following an interruption of the defined area. -
Page 15: Supplemental Safeguarding
® EZ-SCREEN Type 2 Light Screen 3.1.3 Supplemental Safeguarding Properly position the EZ-SCREEN Type 2 such that an Figure 4. An example of supplemental safeguarding individual cannot reach through the defined area and access the hazard point before the machine has stopped. Hard (fixed) Guarding Additionally, the hazard cannot be accessible by reaching Opening... - Page 16 ® EZ-SCREEN Type 2 Light Screen All reset switches must be: • Outside the guarded area • Located to allow the switch operator a full, unobstructed, view of the entire guarded area while the reset is performed • Out of reach from within the guarded area •...
- Page 17 ® EZ-SCREEN Type 2 Light Screen Use of Corner Mirrors EZ-SCREEN Type 2 may be used with one or more corner mirrors. Mirrors are not allowed for applications that would allow undetected personnel access into the safeguarded area. The use of glass-surface corner mirrors reduces the maximum specified emitter/receiver separation by approximately 8 percent per mirror, as follows: Light Screen Maximum Range Light Screen Series...
- Page 18 ® EZ-SCREEN Type 2 Light Screen WARNING: • Properly install system components • Incorrectly orienting the system components impairs the performance of the system and results in incomplete guarding, which can result in serious injury or death. • Install the system components with their corresponding cable ends pointing in the same direction. Figure 7.
-
Page 19: Mounting System Components
® EZ-SCREEN Type 2 Light Screen Figure 9. Installation of Multiple Systems Receiver Receiver Scan Code 1 Emitter Scan Code 1 Emitter Receiver Emitter Scan Code 2 Scan Code 2 Receiver Emitter b. Two or three systems stacked (or alternate receiver/ a. -
Page 20: Mounting And Initial Alignment Of Emitter/Receiver Pairs
® EZ-SCREEN Type 2 Light Screen Mounting Hardware Figure 10. Emitter and Receiver End-Cap Mounting Brackets The EZ-SCREEN standard end-cap mounting bracket hardware is supplied with each emitter and receiver. Brackets are designed to mount directly to MSA Series stands using the hardware with the supplied stands. Using Center Mounting Brackets Center mounting brackets are supplied with longer sensors Figure 11. - Page 21 ® EZ-SCREEN Type 2 Light Screen 1. From a common point of reference (ensuring the calculated safety distance), make measurements to locate the emitter and receiver in the same plane with their midpoints directly opposite each other. Important: The connector ends of both sensors must point in the same direction (see Emitter and Receiver Orientation on p.
- Page 22 ® EZ-SCREEN Type 2 Light Screen Note: Make sure that the emitter and receiver are not tilted front-to-back or side-to-side as shown. www.bannerengineering.com - Tel: + 1 888 373 6767...
-
Page 23: Electrical Installation And Testing
Ensure that all legal requirements have been met and that all technical installation and maintenance instructions contained in this manual are followed. The user has the sole responsibility to ensure that this Banner device is installed and interfaced to the guarded machine by Qualified Persons , in accordance with this manual and applicable safety regulations. -
Page 24: Initial Electrical Connections
® EZ-SCREEN Type 2 Light Screen 4.2 Initial Electrical Connections WARNING: Proper Electrical Hookup Electrical hookup must be made by Qualified Personnel and must comply with NEC (National Electrical Code) and local standards. Make no more connections to the EZ-SCREEN Type 2 System than are described in this manual. -
Page 25: Initial Checkout Procedure
® EZ-SCREEN Type 2 Light Screen Individual Cordsets Splitter Cordsets +24V dc Or/Bk n.c. n.c. OSSD2 OSSD1 0V dc Gn/Ye Ground Reset/Test & EDM Description Description Emitter Emitter Receiver Receiver QDE-8..D Cordsets DEE2R.. Cordsets CSB.. Cordsets 4.3 Initial Checkout Procedure The initial checkout procedure must be performed by a Qualified Person. -
Page 26: Initial Power-Up
® EZ-SCREEN Type 2 Light Screen 4.3.2 Initial Power-Up 1. Inspect the area near the light screen for reflective surfaces, including work pieces and the guarded machine. Reflective surfaces may cause light beams to reflect around a person in the light screen, preventing the person from being detected and not stopping the machine motion (see Adjacent Reflective Surfaces on p. - Page 27 ® EZ-SCREEN Type 2 Light Screen 1. Verify the sensor mounting. 2. Verify the optimal alignment, adjusting the sensor rotation with the power on: a. Verify that the emitter and the receiver are pointed squarely at each other. Use a straight edge (for example, a level) to determine the direction the sensor is facing.
-
Page 28: Optical Alignment Procedure With Mirrors
Note: A LAT-1-LS Laser Alignment Tool is very helpful by providing a visible red dot along the optical axis. Figure 14 on p. 28 and Banner Safety Applications Note SA104 (p/n 57477) for further information. Figure 14. Optical alignment using the LAT-1-LS Figure 15. -
Page 29: Electrical Connections To The Guarded Machine
® EZ-SCREEN Type 2 Light Screen Figure 16. Trip Test Emitter Test Piece Receiver 4. During each pass (see Status Indicators on p. 37 for more details): • Trip Output Operation: The Status Blocked indicator must turn ON Red and remain ON for as long as the test piece remains in the defined area (and the Status Clear indicator OFF during the same time). -
Page 30: Ossd Output Connections
• To ensure proper operation, the Banner device output parameters and machine input parameters must be considered when interfacing the Banner device OSSD outputs to machine inputs. Design machine control circuitry so that all of the following are true: The maximum load resistance value is not exceeded. -
Page 31: Machine Primary Control Elements And Edm Input
® EZ-SCREEN Type 2 Light Screen Protective Stop (Safety Stop) Circuits A protective stop (safety stop) allows for an orderly cessation of motion for safeguarding purposes, which results in a stop of motion and removal of power from the MPCEs (assuming this does not create additional hazards). A protective stop circuit typically comprises a minimum of two normally open contacts from forced-guided, mechanically linked relays, which are monitored through External Device Monitoring to detect certain failures in order to prevent the loss of the safety function. - Page 32 ® EZ-SCREEN Type 2 Light Screen Connect the receiver’s reset/test wire (pin 8) to the supply voltage (see Generic Wiring to FSDs (manual reset) on p. 34 Generic Wiring — Interface Module (2-Channel EDM, Manual Reset) on p. 35) via the reset switch. The switch should be a normally closed (N.C.) reset switch, or contacts of the Machine Control Test circuit (typically a normally open contact held or energized closed), or the monitoring contacts of the external device(s) being verified.
-
Page 33: Preparing For System Operation
® EZ-SCREEN Type 2 Light Screen 4.4.5 Preparing for System Operation After the initial trip test has been accomplished, and the OSSD safety outputs and EDM connections have been made to the machine to be controlled, the EZ-SCREEN Type 2 is ready for testing in combination with the guarded machine. The operation of the EZ-SCREEN Type 2 with the guarded machine must be verified before the combined System and machine may be put into service. -
Page 34: Generic Wiring To Fsds (Manual Reset)
® EZ-SCREEN Type 2 Light Screen 4.5.2 Generic Wiring to FSDs (manual reset) Figure 19. Generic Wiring to FSDs (manual reset) +24V dc 0V dc Receiver Bn (Pin #1) +24V dc 8-pin male Euro-style face view Gn/Ye (#7) Ground Bu (#6) 0V dc Bk (#5) OSSD1... -
Page 35: Generic Wiring - Interface Module (2-Channel Edm, Manual Reset)
® EZ-SCREEN Type 2 Light Screen 4.5.3 Generic Wiring — Interface Module (2-Channel EDM, Manual Reset) Figure 20. Generic Wiring — Interface Module (2-Channel EDM, Manual Reset) Receiver 8-pin male Euro-style face view +24V dc 0V dc Bn (Pin #1) +24V dc Gn/Ye (#7) Ground... -
Page 36: System Operation
® EZ-SCREEN Type 2 Light Screen 5 System Operation 5.1 Security Protocol Certain procedures for installing, maintaining, and operating the EZ-SCREEN Type 2 must be performed by either Designated Persons or Qualified Persons. A Designated Person is identified and designated in writing, by the employer, as being appropriately trained and qualified to perform system resets and the specified checkout procedures on the EZ-SCREEN Type 2. -
Page 37: Receiver
® EZ-SCREEN Type 2 Light Screen 5.3.1 Receiver Alignment Indicators Two Yellow Alignment indicators (Top and Bottom) tell the alignment status of the top and bottom beams in the light screen. This is helpful for sensor alignment: first align the Top beam (the sync beam), then the bottom beam. The Alignment indicators also flash together to indicate a manual reset is needed (Latch output models). -
Page 38: Normal Operation
® EZ-SCREEN Type 2 Light Screen 5.4 Normal Operation 5.4.1 System Power-Up Trip Output Systems: When power is applied, each sensor will conduct self-tests to detect critical internal faults and prepare for operation. If either sensor detects a critical fault, scanning ceases, the receiver outputs remain Off and diagnostic information is displayed via the LEDs;... -
Page 39: Troubleshooting
® EZ-SCREEN Type 2 Light Screen 6 Troubleshooting 6.1 Troubleshooting and Lockout Conditions Evaluate status indicators per Status Indicators on p. 36. A Lockout condition causes all the EZ-SCREEN Type 2 OSSD outputs to turn or remain OFF, sending a stop signal to the guarded machine. -
Page 40: Electrical And Optical Noise
EZ-SCREEN Type 2 wires from high-voltage wires. 1. Use the Banner model BT-1 Beam Tracker Alignment Aid to detect electrical transient spikes and surges. 2. Cover the lens of the BT-1 with electrical tape to block optical light from entering the receiver lens. -
Page 41: Check For Sources Of Optical Noise
6.3.2 Check for Sources of Optical Noise 1. Turn off the emitter, completely block the emitter, or open the Test input. 2. Use a Banner BT-1 Beam Tracker (see Accessories on p. 49) to check for light at the receiver. -
Page 42: Product Support And Maintenance
Banner Engineering Corp. warrants its products to be free from defects in material and workmanship for one year following the date of shipment. Banner Engineering Corp. will repair or replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. -
Page 43: Contact Us
® EZ-SCREEN Type 2 Light Screen 7.6 Contact Us Banner Engineering Corp. headquarters is located at: 9714 Tenth Avenue North Minneapolis, MN 55441, USA Phone: + 1 888 373 6767 For worldwide locations and local representatives, visit www.bannerengineering.com. www.bannerengineering.com - Tel: + 1 888 373 6767... -
Page 44: Checkout Procedures
Results should be recorded and kept in the appropriate place (for example, near the machine, and/or in a technical file). Banner Engineering highly recommends performing the System checkouts as described. However, a qualified person (or team) should evaluate these generic recommendations considering their specific application and determine the appropriate frequency of checkouts. - Page 45 ® EZ-SCREEN Type 2 Light Screen • It is not possible for a person to stand between the defined area and the dangerous parts of the machine, or • Supplemental safeguarding and hard (fixed) guarding, as described by the appropriate safety standards, are in place and functioning properly in any space (between the defined area and any hazard) which is large enough to allow a person to stand undetected by the EZ-SCREEN Type 2.
-
Page 46: Specifications And Accessories
(Output Signal Switching Device) safety outputs. (Use optional mains interruptions of 20 ms, as specified in IEC/EN 60204-1. interface modules for AC or larger DC loads.) Not capable of the Banner "Safety Handshake". Supply Current (no load) ON-State voltage: ≥ Vin-1.5 V DC 90 mA maximum, exclusive of OSSD1 and OSSD2 loads (up to an OFF-State voltage: 0 V dc typical, 0.5 V dc maximum (no load) -
Page 47: Emitter And Receiver Dimensions
® EZ-SCREEN Type 2 Light Screen 9.1.4 Emitter and Receiver Dimensions 31.8 mm (1.25") 25.4 mm (0.96") 10.8 mm (0.43") 43.0 mm (1.69") 16.9 mm (0.66") R13 mm (0.5") 10.0 mm minimum bend (0.39") 65 mm (2.6") 31.8 mm (1.25") Defined Area 5 Y Emitter or Receiver Model Housing Length... - Page 48 ® EZ-SCREEN Type 2 Light Screen Standard End Cap Brackets Model USMB-1 Slots have clearance for M3 screws (supplied) and 10.7 mm 12.7 mm allow for ±30° rotation (0.42") (0.50") 15.7 mm 5.8 mm (0.62") (0.23") 15.7 mm (0.62") 23.2 mm 20.0 mm 31.9 mm (0.91")
-
Page 49: Accessories
® EZ-SCREEN Type 2 Light Screen 9.2 Accessories 9.2.1 Accessories Additional interfacing solutions and accessories continue to be added; refer to http://www.bannerengineering.com for a current list. 9.2.2 Cordsets Single-Ended (Machine Interface) Cordsets Single-Ended (Machine Interface) Cordsets (one cable for each emitter and receiver). Overmold and cables are PVC-jacketed. - Page 50 13.0 mm 7.0 mm (0.51") (0.28") 8-pin Euro-style female connector 3 m PMEF-810D (10 ft) wires, cut to length (Banner color code); 22 AWG/0.33 mm² 1/4-18NPT M12 x 1 O-Ring Splitter Cordsets Model CSB splitter cordsets allow easy interconnection between an EZ-SCREEN Type 2 8-pin receiver and its 8-pin emitter, providing a single “homerun”...
-
Page 51: Interface Modules
® EZ-SCREEN Type 2 Light Screen 8-Pin Threaded M12 Splitter Cordsets—Flat Junction Model Trunk (Male) Branches (Female) Pinout CSB-M1280M1280 No trunk No branches Male CSB-M1281M1281 0.3 m (1 ft) CSB-M1288M1281 2.44 m (8 ft) CSB-M12815M1281 4.57 m (15 ft) 2 x 0.3 m (1 ft) CSB-M12825M1281 7.62 m (25 ft) Female... -
Page 52: Contactors
® EZ-SCREEN Type 2 Light Screen 9.2.4 Contactors Contactors provide forced-guided, mechanically-linked relay (safety) outputs for the EZ-SCREEN Type 2 System. The contactor is required to be monitored via an EDM function (See Generic Wiring to FSDs (manual reset) on p. 34). Model Description 11-BG00-31-D-024... -
Page 53: Msa Series Stands
® EZ-SCREEN Type 2 Light Screen Models Construction Connector/LED Function/Inputs Nickel-plated brass housing, M18x1 thread; M18RGX8PQ8 8 thermoplastic lens Fully encapsulated IP67 T18RGX8PQ8 Thermoplastic polyester housing, thermoplastic lens Fully encapsulated IP67 8-pin Euro-style Integral QD Red/Green indication follows OSSD output T30RGX8PQ8 of the EZ-SCREEN receiver ON Red:—Power ON Beam Blocked or... -
Page 54: Ssm Series Corner Mirrors
® EZ-SCREEN Type 2 Light Screen • MSAMB adapter bracket kit included with each MSA stand. M4 x 10 mm Reflective Area Mounting Mirror Height Screw Mirror Model Part Number Length (Y) Length (L1) Overall (L2) (8 supplied) MSM4A 43162 165 mm (6.5") 221 mm (8.7") 191 mm (7.5") - Page 55 ® EZ-SCREEN Type 2 Light Screen Mirror Model Reflective Area Mounting Height Overall Height (L2) M6 x 19 mm 101.2 mm (L1) 9 screw Height (Y) (3.98") (4 supplied) SSM-100-S 100 mm (3.9 in) 211 mm (8.3 in) 178 mm (7.0 in) SSM-150-S 150 mm (5.9 in) 261 mm (10.3 in)
-
Page 56: Accessory Mounting Brackets
® EZ-SCREEN Type 2 Light Screen EZ-SCREEN Models SSM Models Type 2 SSM-1275 1200 1190 1200 4-400 SSM-1400 1350 1250 1260/1330 1350 SSM-1475 1390 1400 SSM-1550 1500 1470 1500 SSM-1675 1530 1540/1610 SSM-1750 1650 1670 1680 1650 SSM-1900 1800 1810 1750/1820 1800 9.2.11 Accessory Mounting Brackets... -
Page 57: Alignment Aids
® EZ-SCREEN Type 2 Light Screen 9.2.12 Alignment Aids Model Description Self-contained visible-beam laser tool for aligning any EZ-SCREEN Type 2 LAT-1-LS emitter/receiver pair. Includes retroreflective target material and mounting clip. LSA-LAT-2 Replacement adaptor (clip) hardware for EZ-SCREEN Type 2 models LSA-LAT-1 Clip-on retroreflective LAT target BRT-THG-2-100... -
Page 58: Standards And Regulations
10 Standards and Regulations The list of standards below is included as a convenience for users of this Banner device. Inclusion of the standards below does not imply that the device complies specifically with any standard, other than those specified in the Specifications section of this manual. -
Page 59: International/European Standards
® EZ-SCREEN Type 2 Light Screen 10.3 International/European Standards EN ISO 12100 Safety of Machinery – General Principles for EN 60204-1 Electrical Equipment of Machines Part 1: Design — Risk Assessment and Risk Reduction General Requirements ISO 13857 Safety of Machinery – Safety Distances to IEC 61496 Electro-sensitive Protection Equipment Prevent Hazard Zones Being Reached IEC 60529 Degrees of Protection Provided by Enclosures... -
Page 60: Glossary
11 Glossary The following terms are used in this manual. Where possible, definitions are from the U.S. and international product performance standards that govern the design of the Banner device. For more definitions, visit www.bannerengineering.com. ANSI (American National Standards Institute) - Page 61 Component failure modes that produce either no effect or a Lockout condition are permitted; failures which cause an unsafe Final Switching Device (FSD) condition (a failure to danger) are not. Banner safety products are The component of the machine’s safety-related control system that extensively FMEA tested.
- Page 62 (after the operation) by the operator. PSDI is commonly confused with "Trip Initiate." PSDI is defined in OSHA CFR1910.217. Banner safety light curtain systems may not be used as PSDI devices on mechanical power presses, per OSHA regulation 29 CFR 1910.217.
- Page 63 A circuit with the capability to electronically verify that all of its own Start Up Test critical circuit components, along with their redundant backups, are operating properly. Banner safety light curtain systems and safety For certain safety devices, like safety light curtains or safety gates, modules are self-checking.
- Page 64 ® EZ-SCREEN Type 2 Light Screen Test Piece Auto Start/Restart (Trip) Initiate An opaque object of sufficient size used to block a light beam to The resetting of a safeguard causing the initiation of machine test the operation of a safety light curtain system. motion or operation.
- Page 65 Index Final Switching Device (FSD) 5 applications suitable 7 routing corsets 23 indicator Emitter Power/Fault 37 initial power-up 26 control reliability 8 sensor swapability 9 corsets status indicators 10 routing 23 suitable applications 7 LEDs system response time 12 emitter 36, 37 receiver 36, 37 light-emitting diodes 36, 37 DIP Switches 8–10...
