- Page 1 SMART AIR PURIFIER PREMIUM Manual Guide Legate Smart Appliances...
-
Page 2: Let's Get Started
Let’s Get Started. Install the app Download the Legate Smart Home from Google Play or the App Store on a compatible phone or tablet. Register and login Register on the app by using your contact number or Email address. Connect to wifi Make sure that your mobile phone and smart device are connected to 2.4 GHz... - Page 3 Legate Smart Air Purifier Premium to Legate Smart Home App...
- Page 4 Turn on the Smart Air Purifier, into the power socket. press & hold the Mode Button for 5 seconds until the Wifi Indicator Light blink rapidly. Legate Smart Air Purifier Premium - Connecting the Smart Device to Legate Smart Home app...
- Page 5 Add Smart Device Open Legate Smart Home app, Under “Small Home Appliances” tab Click “+” or Add Device. Click “Air Purifier”. Legate Smart Air Purifier Premium - Connecting the Smart Device to Legate Smart Home app...
- Page 6 Network Configuration Click “Confirm indicator Enter your Wifi Password. Then rapidly blink” button. click “Confirm” button. (note: Only 2.4 GHz Wifi network are supported) Legate Smart Air Purifier Premium - Connecting the Smart Device to Legate Smart Home app...
- Page 7 Wait for the Smart Device Click “Done” button when the Smart connects to the app. Device is successfully added. (note: You can change the device’s name) Legate Smart Air Purifier Premium - Connecting the Smart Device to Legate Smart Home app...
- Page 8 Legate Smart Air Purifier Premium Features...
- Page 9 Main Function Set the Mode Settings of Adjust the Speed Level of the Smart Air Purifier. the Smart Air Purifier’s fan. Legate Smart Air Purifier Premium- Features...
- Page 10 Main Function Enable or Disable the different Set Schedule to automatic turn functions of the Smart Air Purifier. ON/OFF the Smart Air Purifier. Legate Smart Air Purifier Premium- Features...
- Page 11 Push Notification Enable to turn off the notification. Click “Me” button on Legate Click “Push Notification” Can turn on or turn off the Smart Home app. Then click tab. “Enable notification” “Settings”. Legate Smart Air Purifier Premium- Features...
- Page 12 Remove Device from Legate Smart Home app The device will restore to default settings. Click “ ” button on upper Click “Remove Device” Click “Confirm” button to right corner of Smart Camera tab. completely remove the device main page. from the Legate Smart Home app.
- Page 13 Legate Smart Air Purifier Premium Product Information...
- Page 14 HEPA composite filter screen: To filter out smoke, dust, pollen, oxygen source, pollutant and fine particles over 0.3 micron, together with harmful gas such as benzene, formaldehyde and odor. Packing Details Body WIFI Specifications Primary Filter Screen 2PCS Remote Control HEPA Composite Filter Screen 2PCS Legate Smart Air Purifier Premium - Product Information...
- Page 15 Applicable Area 56 ~ 96m Intelligent Purification Mode of Operation Rated Voltage 220V - 240V Rated Frequency 50Hz / 60Hz Rated Power Size (LxWxH) 40x 40 x 66.9 cm Net weight 14.0 KG Legate Smart 2in1 Air Purifier - Product Information...
- Page 16 Product Structure 解锁 锁定 复 位 极速 Remote controller Air Quality Indicator HEPA composite HEPA composite filter screen filter screen Rear cover Front cover Primary filter screen Primary filter screen Host Legate Smart Air Purifier Premium - Product Information...
- Page 17 Timing Mode Child lock Air speed Front cover Display Panel Front cover Standby Power on Switch key Green Function key Mode Child lock Air speed Timing Filter screen AUTO topspeed SLEEP WiFi Legate Smart Air Purifier Premium - Product Information...
- Page 18 No display filter screen. filter screen PM Value Correspondence Table PM2.5 concentration ug/m³ 76-150 151-500 1-35 36-75 Air quality (Green) Fair (Orange) Bad (Red) Dirty (Blue) Good Legate Smart Air Purifier Premium - Product Information...
- Page 19 1. Take out the filter screen from the plastic bag. A. Remove the front and rear covers B. Remove the filter screen C. Take out the filter screen from the plastic bag Legate Smart Air Purifier Premium - Product Information...
- Page 20 Then the POWER key changes to green , and the machine enters the AUTO mode by default. At the same time, the front panel of the machine displays: AUTO (automatic mode). Legate Smart Air Purifier Premium - Product Information...
- Page 21 The timing shall be set in the range of 1-12 hours. (The icon of the key is on when the timing shutdown function is activated, and the icon is half-lit when deactivated.) Legate Smart Air Purifier Premium - Product Information...
- Page 22 If the machine has been paired with the WIFI before and it has the memory function, the machine can control the start-up, shutdown and other functions by the WIFI in the standby state. Filter screen Power Timing Mode Child lock Air speed Legate Smart Air Purifier Premium - Product Information...
- Page 23 B) Place the hand in the position of the handle and open it at a certain angle outwards. At this time, lift the back cover up to a certain distance and take down it from the product. Position of the handle Legate Smart Air Purifier Premium - Product Information...
- Page 24 (pay attention to the direction of the filter screen. The two straps should be outward), and then buckle up the upper buckle. The two insertion pieces are to be inserted into the card slot of the body Legate Smart Air Purifier Premium - Product Information...
- Page 25 HEPA composite Primar y filter Front cover filter screen screen Legate Smart Air Purifier Premium - Product Information...
- Page 26 Cleaning of the machine Cleaning of the host surface: Clean the dirt with a dry wipe, Do not wash the machine with water. Legate Smart Air Purifier Premium - Product Information...
- Page 27 Take out the air outlet grille, and stir and clean the dust on the anion emitter with cotton swab from the iron net over the emitter. This cleaning should be carried out on a regular basis. Legate Smart Air Purifier Premium - Product Information...
- Page 28 Do not place any articles at dust, lint, hair or other substances block the the air inlet and outlet, so as not to affect the air inlet. flow of the air and reduce the purification efficiency. Legate Smart Air Purifier Premium - Product Information...
-
Page 29: Troubleshooting
It indicates that the timing of the HEPA composite filter screen has reached the set value. After the filter screen The alarm light for filter screen is is cleaned, keep pressing the FILTER SCREEN key for normally on resetting. Legate Smart Air Purifier Premium - Product Information... - Page 30 Your one stop shop for all your Smart Home needs www.legate.com.sg...
