  • Page 1 Technical Reference 020-001915-01 Secure Series II LCD Panels...

  • Page 2: Warranty

    Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or consequential damages in connection with the performance or use of this material.
  • Page 3 Set sound input ........................22 Increase/Decrease Volume ....................23 Increase/Decrease Balance ....................23 Set Language ........................24 Set OSD Time ........................24 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 4 Get Input Source ........................ 38 Get Picture Mode ......................... 39 Get Brightness ........................39 Get Contrast ........................39 Get Saturation ........................40 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 5 Serial command list ......................52 Power control ........................53 Input Source ........................54 Backlight ..........................54 Contrast ..........................55 Brightness .......................... 55 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 6 Serial Number Read ......................59 Model Name Read ....................... 60 Firmware Version Read ......................60 Scheme Selection ........................ 61 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 7 Commands sent from an automation/control system or PC to the display must have the following format. Format : [HEAD][SET ID][COMMAND][END] Example (Power on) : K:ALLPON Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 8 If the data is data write mode, it returns the data of the PC computer. Format : [ALL][:][Command][=][A] Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 9 Direct Control Sharpness 1step Down Color temperature set to Direct Control Studio1 Color Temperature set to Direct Control Studio2 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 10 OSD Time 5Sec Direct Control OSD Time 10Sec Direct Control OSD Time 20Sec Direct Control Power Save Off Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 11 Window1 Input DP2 Direct Control Window1 Input HDMI1 Direct Control Window1 Input HDMI2 Direct Control Window1 Input HDMI3 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 12 Remote control Menu key Direct Control Remote control Info key Direct Control Mute On Direct Control Mute Off Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 13 000 to 100 Status check HDR10 000=Off, 001=On 000 = DP1 Status check Audio Input Status 001 = DP2 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 14 002 = Preset2 Status check Preset Mode status 003 = Preset3 004 = Preset4 005 = Preset5 006 = Preset6 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 15 003 = HDMI2 Status check Window3 Source Status 004 = HDMI3 005 = HDMI4 007 = OPS-HDMI 008 = OPS-DP Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 16 005 = HDMI4 007 = OPS-HDMI 008 = OPS-DP 000 = Off Status check Mute Status 001 = On Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 17 Sets the source to OPS HDMI. K:ALLSH8. Sets the source to OPS DP. Set the sourcel to DP1: K:ALLSH1. Result: ALL:SH1=A Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 18 Command (ASCII) Description Values K:ALLBLU. Increases the brightness by one step. — K:ALLBLD. Decreases the brightness by one step. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 19 Increase the black level by one step: K:ALLBRU. Result: ALL:BRU=A Increases or decreases the saturation by one step. Set Picture mode to user. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 20 Sets the color temperature to cool. K:ALLCT5. Sets the color temperature to user. Set the picture mode to standard: Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 21 K:ALLBGU. Increases the blue gain by one step. — K:ALLBGD. Decreases the blue gain one by one step. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 22 Values K:ALLPIR. Runs the picture reset. — Run the picture reset: K:ALLPIR. Result: ALL:PIR=A Sets the sound input. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 23 Command (ASCII) Description Values K:ALLBCU. Increases the balanace by one step. — K:ALLBCD. Decreases the balanace by one step. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 24 Sets the on-screen display turn off time to 10 seconds. K:ALLOT3. Sets the on-screen display turn off time to 20 seconds. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 25 Set the interface select to OPS RS232. Set the interface select to off: K:ALLUA0. Result: ALL:UA0=A Sets the OPS/HDMI4 EDID. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 26 K:ALLAIO. Sets the auto source switch to on. Set the auto source switch to off: K:ALLAIF. Result: ALLAIF:=A Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 27 Sets the preset mode to 3. K:ALLRN4. Sets the preset mode to 4. K:ALLRN5. Sets the preset mode to 5. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 28 Sets the input of window1. Select Preset mode before sending this command. Command (ASCII) Description Values K:ALLW10. Sets the window1 input to DP1. — Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 29 Set the window2 input to DP1: K:ALLW20. Result: ALL:W20=A Sets the input of window3. Select Preset mode before sending this command. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 30 Sets the window4 input to OPS DP. Set the window4 input to DP1: K:ALLW40. Result: ALL:W40=A Runs the preset recall. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 31 Enables or disables the mute functionality (for sound). Command (ASCII) Description Values K:ALLMON. Enables the mute functionality. — K:ALLMOF. Disables the mute functionality. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 32 Direct command control Enable mute: K:ALLMON. Result: ALL:MON=A Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 33 Command (ASCII) Description Values K:ALLBRT<value>. Sets the black level to the specified value. value = 0 to 100 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 34 Sets red gain. Set Color temperature to user. Command (ASCII) Description Values K:ALLRGN<value>. Sets the red gain. value = 0 to 100 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 35 Sets the volume. Command (ASCII) Description Values K:ALLVOL<value>. Sets the volume to the specified value. value = 0 to 100 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 36 ALL: PWM=A Select the Preset mode. Command (ASCII) Description Values K:ALLPRS<value>. Select the Preset mode. 0 = Off Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 37 2 = Preset 2 … 20 = Preset 20 Set Preset mode to 1: K:ALLPRS001. Result: ALL: PRS=A Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 38 5 = HDMI4 7 = OPS HDMI 8 = OPS DP Get the input source value: K:ALLSRC? Result: ALL: SRC=000 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 39 Command (ASCII) Description Returned values K:ALLCON? Returns the contrast value. 0 to 100 Get the contrast value: K:ALLCON? Result: Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 40 0 = studio1 1 = studio2 2 = warm 3 = normal 4 = cool 5 = user Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 41 Returns the blue gain value. Command (ASCII) Description Returned values K:ALLBGN? Returns the blue gain value. 0 to 100 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 42 7 = OPS HDMI 8 = OPS DP Get the audio input value: K:ALLAUT? Result: ALL: AUT=001 Returns the volume value. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 43 4 = Italizn 5 = Russian 6 = Korean Get the on-screen display language value: K:ALLLAT? Result: ALL: LAT=001 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 44 Return the OPS/HDMI4 EDID value. Command (ASCII) Description Returned values K:ALLEDI? Return the OPS/HDMI4 EDID value. 0 = UHD 1 = FHD Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 45 20 = Preset20 Get the Preset mode value: K:ALLPRS? Result: ALL: PRS=001 Returns the Power Off mode value. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 46 Returns the gamma status. 0 = Off 1 = On Get gamma status value: K:ALLGMT? Result: ALLGMT: =001 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 47 1 = dual1 2 = dual2 3 = dual3 4 = dual4 5 = triple1 6 = triple2 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 48 0 = DP1 1 = DP2 2 = HDMI1 3 = HDMI2 4 = HDMI3 5 = HDMI4 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 49 2 = HDMI1 3 = HDMI2 4 = HDMI3 5 = HDMI4 7 = OPS HDMI 8 = OPS DP Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 50 Returns the mute status. 0 = Mute off 1 = Mute on Get the mute status: K:ALLMUT? Result: ALL: MUT=001 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 51 [REPLY] is the parameter setting for the command, acknowledged by the display panel in its response to a command. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 52 0 to 100 0 to 100 Brightness 42 52 4C 0 to 100 0 to 100 Saturation 53 41 54 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 53 47 56 45 version User Scheme selection Standard 53 43 4D Dynamic Sets or gets the power control. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 54 07 01 02 42 52 49 50 08 Sets the backlight to the specified value. 0 to 100 (0 to 0x64) Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 55 07 01 02 42 52 4C 50 08 Result: 07 01 00 42 52 4C 50 08 Sets or returns the saturation. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 56 Turn off the backlight: 07 01 02 42 4C 43 00 08 Result: 07 01 00 42 4C 43 00 08 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 57 07 01 02 55 53 52 50 08 Result: 07 01 00 55 53 52 50 08 Sets or returns the green gain. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 58 07 01 01 42 52 41 08 Returns the baudrate. — Set the baudrate 115200: 07 01 02 42 52 41 00 08 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 59 07 01 02 41 4C 4C 00 08 Result: 07 01 00 41 4C 4C 00 08 Reads the serial number. Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 60 07 01 00 47 56 45 30 30 30 39 00 32 08 0 . 0 . 0 .9 - 0 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 61 Set the Picture mode to user: 07 01 02 53 43 4D 00 08 Result: 07 01 00 53 43 4D 00 08 Secure Series II LCD Panels Technical Reference 020-001915-01 Rev. 1 (03-2021) Copyright 2021 Christie Digital Systems USA, Inc. All rights reserved. ©...
