Summary of Contents for Bestar 93612

  • Page 1 ASSEMBLY INSTRUCTIONS INSTRUCTIONS D’ASSEMBLAGE INSTRUCCIONES DE ENSAMBLAJE Certi ed/Certi é/Certi cado ISO 9001...
  • Page 2 Thank you for choosing product. Your total satisfaction is our #1 priority. Should you have a problem or need more information concerning the warranty, do not call to the place of purchase. Please have your assembly instruction manual on hand when you call. Our products are warranted to the original purchaser against defects in material or workmanship in the furniture.
  • Page 3 PIEZAS PARTS code / código qty / qté / cant. code / código qty / qté / cant. code / código qty / qté / cant. code / código qty / qté / cant. molduras Moldings QUINCALLAS HARDWARES code / código qty / qté...
  • Page 4: Important Notice

    NOTA IMPORTANTE IMPORTANT NOTICE / Asegúrese de completar correctamente la etiqueta. Duly complete the self-adhesive sticker. / COLOR : ASSEMBLY INSTRUCTIONS INSTRUCTIONS D’ASSEMBLAGE INSTRUCCIONES DE ENSAMBLAJE Certified Important/Importante Please retain the self-adhesive sticker which you will install at step 5 of the instruction manual. Conserve la etiqueta que será...
  • Page 5: Hardware Installation

    INSTALACIÓN DE LAS QUINCALLAS HARDWARE INSTALLATION / CREDENCIA CREDENZA / PA-844 H-03 H-36 Code / Código Qty / Qté / Cant.
  • Page 6: Pre-Assembly

    NOTA IMPORTANTE IMPORTANT NOTICE / Sistema principal de quincalla Main hardware system / Make sure to properly tighten each cam to ensure furniture solidity. Otherwise, parts could be damaged or the user could be injured. Asegúrese de apretar bien cada arandela para garantizar la tighten insert tools required...
  • Page 7 INSTALACIÓN DE LAS QUINCALLAS HARDWARE INSTALLATION / CREDENCIA CREDENZA / H-03 PF-108 H-36 Code / Código Qty / Qté / Cant.
  • Page 8 PREENSAMBLAJE PRE-ASSEMBLY / CREDENCIA CREDENZA / Assemble on the back edge important / importante Realice el ensamblaje sobre el borde delantero Assembling sequence Secuencia de ensamblaje / Piezas: Parts / tighten 70 31 + apretar insert insertar two people are required to assemble and move this model.
  • Page 9 AJUSTE ADJUSTMENT / For future reference and to better serve you, Important/Importante please complete and apply the self-adhesive sticker in an accessible space such as under the part 40. Model Production Number Customer Service Para uno mejor servicio en caso de necesidad, ponar la etiqueta en un lugar de fácil acceso como por ejemplo la parte inferior de la pieza AJUSTE...
  • Page 10: Product Care

    MANTENIMIENTO DEL PRODUCTO PRODUCT CARE / Avoid placing the furniture in the sunlight or near a source of heat. Use a soft dry cloth for dusting. To clean heavy dirt, use a cloth dipped in a solution of mild detergent and water. Avoid leaving wet objects on the surface or using commercial chemical cleaning products.
  • Page 11: Problems And Solutions

    Problems and Solutions / You are at a step of hardware installation and some H-36 are missing: Before calling to order your missing bolts (H-36), please make sure you have not installed any bolts (H-36) in the wrong place. To remove a bolt (H-36) which is not in the correct place, please refer to your instruction manual. How to separate and install your CO-249 and CO-684 slides: The CO-249 &...
  • Page 12 OUR FURNITURE IS GARANTEED FOR 10 YEARS. NO MATTER THE PROBLEM, OUR CUSTOMER SERVICE IS THERE FOR YOU. NOS MEUBLES SONT GARANTIS POUR 10 ANS. PEU IMPORTE LE PROBLÈME, N’HÉSITEZ PAS À COMMUNIQUER AVEC NOTRE SERVICE À LA CLIENTÈLE. NUESTROS MUEBLES TIENEN UNA GARANTIA DE 10 AÑOS. NO IMPORTA EL PROBLEMA, COMUNIQUE CON NUESTRO SERVICIO À...
