Dyna-Glo DGSS287CB-D User Manual

Heavy-duty charcoal grill & offset smoker box
Hide thumbs Also See for DGSS287CB-D:

Advertisement

Quick Links

Download this manual
ATTACH YOUR RECEIPT HERE
Serial Number ________________________________ Purchase Date _________________________________
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST,
Monday – Friday or email customerservice@ghpgroupinc.com.
70-10-587
Charcoal Grill &
Offset Smoker Box
1
Heavy-Duty
MODEL #DGSS287CB-D /
DGSS287CB
Français p. 24
Español p. 47
Rev. 07/22/19

Advertisement

loading
Need help?

Need help?

Do you have a question about the DGSS287CB-D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dyna-Glo DGSS287CB-D

Summary of Contents for Dyna-Glo DGSS287CB-D

  • Page 1 Heavy-Duty Charcoal Grill & Offset Smoker Box MODEL #DGSS287CB-D / DGSS287CB Français p. 24 Español p. 47 ATTACH YOUR RECEIPT HERE Serial Number ________________________________ Purchase Date _________________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST, Monday –...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information ........................2 Package Contents ........................4 Hardware Contents ........................5 Preparation ..........................5 Assembly Instructions ........................ 6 Operation Instructions ......................... 16 Tips On Smoking ......................... 19 Care and Maintenance ........................ 21 Warranty ............................22 Replacement Parts List ......................23 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate, or install the product.

  • Page 3: Safety Information

    SAFETY INFORMATION • DO NOT use this product in a manner other than its intended purpose. It is NOT intended for commercial use. It is NOT intended to be installed or used in or on a recreational vehicle and/or boats. •...

  • Page 4: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Lid Handle Lid Bracket Cooking Grate Side Handle - Left / Right Charcoal Grate Access Tray Damper Plate - Tray and Firebox Access Tray Handle Leg Assembly - Left / Right Firebox Bottom Section Firebox Top Section Firebox Adapter Plate...

  • Page 5: Hardware Contents

    HARDWARE CONTENTS M6 x 12 M6 Nut M6 Lock Nut Bolt Qty. 2 Qty. 29 Qty. 9 PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents above. If any part is missing or damaged, do not attempt to assemble the product.

  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Remove the pre-installed bolt and washer from the left lid hinge and slide the lid (C) off the hinges. Pre-installed Hardware Attach the left and right leg assembly (J) to the bottom section of the firebox (K) using three M6 x 12 bolts (AA) per leg.
  • Page 7 ASSEMBLY INSTRUCTIONS Attach bottom section of the firebox (K) to the top section (L) using six M6x12 bolts (AA). Hardware Used M6 x 12mm Bolt Insert the edge of the lid bracket (B) into the slotted opening on the top section of the firebox (L).
  • Page 8 ASSEMBLY INSTRUCTIONS Attach the firebox adapter plate (M) using six M6 x 12 bolts (AA). Hardware Used M6 x 12mm Bolt Attach the damper plate (H) to the inside of the adapter plate (M) using one M6 x 12 bolt (AA) and one M6 lock nut (CC).
  • Page 9 ASSEMBLY INSTRUCTIONS Attach the side handle (E) to the adapter plate (M) using two M6 x 12 bolts (AA) and two M6 nuts (BB). Use two M6 x12 bolts (AA) and two M6 nuts (BB) for filling the two holes on the bottom section of the firebox (K).
  • Page 10 ASSEMBLY INSTRUCTIONS Attach the lid handle (A) to the lid (C) using the pre-installed bolts, washers and nuts. Re-attach the lid (C) using the pre-installed Pre-installed washer and bolt. Hardware...
  • Page 11 ASSEMBLY INSTRUCTIONS Attach the access tray handle (I) to the access tray (G) using two M6 x 12 bolts (AA) and two M6 nuts (BB). Hardware Used M6 x 12mm Bolt M6 Nut Attach the damper plate (H) to the inside of the access tray (G) using one M6 x 12 bolt (AA) and one M6 lock nut (CC).
  • Page 12 ASSEMBLY INSTRUCTIONS Place the charcoal grate (F) inside the access tray (G) and slide the tray into the offset smoker box. Place the cooking grates (D) on the top rail of the firebox.
  • Page 13 ASSEMBLY INSTRUCTIONS Using the Firebox as an Offset Smoker (Optional). This grill is also compatible as an offset smoker box for Dyna Glo grill models DGSS675CB-D and DGSS443CB-D. Optional Step A. NOTE: The leg assemblies (J) can remain on the offset smoker box, or removed prior to installing.
  • Page 14 ASSEMBLY INSTRUCTIONS Optional Step C. Attach the offset box to the offset support bracket (not included) using the two M6 x 12 bolts (AA) and two M6 nuts (BB) that were included in the original hardware pack. Hardware Used M6 x 12mm Bolt M6 Nut DGSS675CB-D Bracket...
  • Page 15 ASSEMBLY INSTRUCTIONS DGSS675CB-D DGSS443CB-D...

  • Page 16: Replacement Parts List

    REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-877-447-4768, 8:00 a.m. - 4:30 p.m. CST, Monday - Friday or email customerservice@ghpgroupinc.com. PART DESCRIPTION PART # PART DESCRIPTION PART # Lid Handle 70-01-584 Access Tray Handle 70-01-534 Leg Assembly - Left/ Lid Bracket 70-01-528...
