Summary of Contents for GTK GTKPRO2
- Page 1 GTKPRO2 Quick Start Guide GPS TRACKING ADVANCED VEHICLE TELEMATICS gatortracking.com.au...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of contents..........2 Important information........3 Introduction...........4 Inclusions............4 Detailed product overview........5 Features............5 Knowing your device........6 Led indications..........7 Setting up your device........8 Wiring diagram..........10 Installation tips..........11 Location and orientation considerations..12 Server connection and new account setup..13 Portal login screen...........14 Main screen.............15 Add object............16 Devices............17... -
Page 3: Important Information
•The following instructions are based upon this unit being connected to the Gator Tracking Server which requires an active paid subscription to be entered into within 30 days of activation of the SIM card in this device. The GTKPRO2 is a subscription based model and requires ongoing payment, details can be found at: gatortracking.com.au/subscriptions. -
Page 4: Introduction
Thank you for purchasing the Gator GTKPRO2 GPS Tracking Advanced Telematics Device. The GTKPRO2 is designed to work in conjunction with the Gator Tracking Server (web portal and app). The GTKPRO2 comes supplied with a M2M SIM Card operating on the Telstra M2M CatM1 Network, it includes 30 days of included tracking. -
Page 5: Detailed Product Overview
DETAILED PRODUCT OVERVIEW The GTKPRO2 is a professional real-time tracking device with GNSS and LTE CAT-M1 connectivity and backup battery. This device is pre-configured to simultaneously use the US based GPS and the Russian based GLONASS global satellite navigation systems. This device also includes a 4G network LTE CAT-M1 transceiver for data communications to the tracking server. -
Page 6: Knowing Your Device
KNOWING YOUR DEVICE... -
Page 7: Led Indications
LED INDICATIONS NAVIGATION LED INDICATIONS BEHAVIOUR MEANING Permanently on GPS signal is not received Blinking every second Normal operation, GPS is connected Device is not working or Device is in sleep mode Blinking fast constantly Device firmware is being flashed STATUS LED INDICATIONS BEHAVIOUR MEANING Blinking every second... -
Page 8: Setting Up Your Device
SETTING UP YOUR DEVICE 1. Gently remove the bottom cover using a plastic pry tool from both sides. Then remove the top cover. 2. Insert the supplied M2M Micro-SIM card. Make sure that Micro-SIM card cut-off corner is pointing forward to the left looking from above. Do not insert a 3rd party SIM card in this device. Figure 1 Cover removal Figure 2 SIM card insertion IMPORTANT: DO NOT INSERT THE INCLUDED SIM CARD IN ANY OTHER DEVICE OTHER THAN... - Page 9 SETTING UP YOUR DEVICE 3. Connect the battery as shown. Position the battery in place where it does not obstruct other components. 4. Once battery is connected then re-attach the cover. Figure 3 Battery connection Figure 4 Batterry connected Right now is a good time to take a photo of the top of your unit with your smart phone or to notate the IMEI number of your device.
-
Page 10: Wiring Diagram
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
Page 11: Installation Tips
INSTALLATION TIPS (Here are some additional points to be aware of) Wiring colours - When wiring up your device, please pay careful attention to the dual colours of some wires. Connecting the constant power wire - Some vehicles have a function where after some time certain circuits will be completely switched off, we recommend connecting the constant power wire either directly to the battery or to a circuit that never switches off. -
Page 12: Location And Orientation Considerations
LOCATION AND ORIENTATION CONSIDERATIONS IMPORTANT NOTE: The Unit must be installed with the writing side of the module facing up. Failure to do so will result in poor GPS positioning. (It is advised to secure the module in place AFTER your wiring is complete and you have turned the device on to test that it’s working. -
Page 13: Server Connection And New Account Setup
SERVER CONNECTION AND NEW ACCOUNT SETUP Notes about our service: The Gator Tracking server is for the exclusive use of Gator branded tracking devices. Gator customers are eligible to register an account at anytime for free. However the devices added to the account require a subscription in order to work beyond 30 days from activation. -
Page 14: Portal Login Screen
PORTAL LOGIN SCREEN Select “Register" at the top, and enter the email address you would like to use, make sure you get this correct as a password will be sent directly to it (one-time). Click ”I agree to the terms of service” Press "Register"... -
Page 15: Main Screen
MAIN SCREEN You can now add your Gator tracking device to your account by pushing the "Add Object" button in the main view. -
Page 16: Add Object
ADD OBJECT When you select add object this will bring up a box that lets you enter details about the device, confirm that you've configured it, and saved it. You will also have the option of adding a subscription for your tracker. -
Page 17: Devices
DEVICES Now your device has been added to your account, the GTKPRO2 is ready to track. Ensure the device is powered on (i.e. turn on the vehicle ignition), click on the device icon in the tracking portal and the map will automatically move to the tracker location. -
Page 18: Smartphone App
GATOR TRACKING SMARTPHONE APP FOR SMARTPHONES & TABLETS The Gator Tracking Smartphone App allows you to monitor your vehicle, track its location, create geofences and receive alerts when events are triggered. This App is for both iOS and Android devices. Search gator tracking. -
Page 19: App Login Screen
TECHNICAL SPECIFICATIONS GNSS GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS (Configured for GPS and GLONASS only) Receiver Tracking: up to 33 satellites Tracking sensitivity -165 dBM Accuracy < 3 M (Accuracy depends on PDOP metrics (satellite qty and spread) < 1 s Hot start Warm start <... -
Page 20: Technical Specifications
TECHNICAL SPECIFICATIONS BLUETOOTH/ CAN 4.0 + LE Supported BT peripherals Temperature and Humidity sensors, Universal BLE sensors support (Requires extra configuration and server admin approval) Supported CAN peripheral Peripheral data to server is not supported under all subscription plans. CAN data plans on request. (Requires extra configuration and server admin approval) INTERFACE 3 Sensor Inputs... - Page 21 TECHNICAL SPECIFICATIONS PHYSICAL SPECIFICATION Dimensions 65 x 56.6 x 20.6 mm (L x W x H) Weight 55 g OPERATING ENVIRONMENT Operating temperature (without battery) -40 °C to +85 °C Storage temperature (without battery) -40 °C to +85 °C Operating humidity 5% to 95% non-condensing Ingress Protection Rating IP41...
-
Page 22: Technical Assistance
TECHNICAL ASSISTANCE If you need assistance setting up or using your Gator product now or in the future, call Gator Support. Australia TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST Copyright © 2021 by TDJ Australia All rights reserved. - Page 23 IMEI SIM NUMBER SAFEGUARD Copy the IMEI/I.D. number (10-digit bar code of the device), and the SIM card number and place here for safe keeping before installing the device. IMEI number SIM number Retailer Date of purchase...
