TE DreamLED WDL-100 User Manual

PACKAGE CONTENTS
The DreamLED Wireless Charging Desk Light packaging includes:
* Wireless Charging Desk LED lamp
* Power adapter with 1.8m cable
* Manual
FEATURES
• Type of LED: 2835 HP • Wireless charging output: 5V/1A 5W max
• Desk lamp LED: 40 pcs HP SMD • Power supply: 100-240V AC-DC 5V/2A
• Max. wattage: 7W (depends on mode) • Instant start
• Color temperature: 2700~6500K • Operating temp.: -10 ~ +40 degrees
• Lifetime: > 35000 hours • Material: ABS + PC
• Lumen: max. 400 Lm • Color: White matte paint
• Color rendering index: > 80 Ra • Weight: 481 Grams
• Wireless charging: Standard Qi 1.1.2
INSTALLATION
• Connect the power adapter to the power input at the back of the lamp.
• Plug the power adapter into an outlet with an input voltage of 110V-240V AC.
WIRELESS CHARGING
The Wireless Charging works with devices with built-in wireless charging receiver modules (such
as Samsung S6/S7/S8, iPhone 8/8 Plus, iPhone X, Google Nexus 4/5/6/7,...) devices with reserved
wireless charging input ports (such as Galaxy S5, Galaxy Note4,...) and wireless charging cases
with receiver modules (iPhone 5, iPhone 6/6 Plus,...). Verify if your phone supports wireless
charging in your smartphone manual.
Place your Qi standard smartphone on the Smart Charging Pad, aligning it properly with the
charging zone - wireless charging will start immediately
! max. charging distance between wireless pad and the to charge device can be max 8mm (mostly
thickness of smartphone covers)
OPERATION by TOUCH
See illustration
1. Light Mode-button
Auto brightness dimmer: There are different levels of brightness within each lighting mode.
Press and hold the Power button to change the brightness.
• Study mode (5000-5500K): High-range color temperature. Increases attention & concen-
tration. Ideal for research & studying.
• Reading mode (4000-4500K): Mid-range color temperature. Stimulates concentration &
reduces eye strain. Ideal for reading.
• Relax mode (2700-3000K): Low-range color temperature. Promotes relaxation. Ideal for
leasure activities.
2. Power ON/OFF: Press once to turn the lamp ON/OFF.
3. Auto Off Timer: Press and hold the Timer button to activate or deactivate the timer. The
lamp will flash 2 times and will now turn off automatically after 1 hour. If you press the Timer
button again, the 1-hour countdown will start again.
Note: When turned back ON, the lamp will go back to the last saved setting before being turned
OFF.
ERGONOMIC DESIGN
The lamp is foldable and adjustable to create different light angles and positions.
Note:
• When adjusting the position of the arm, always hold the lamp base.
• Excessive adjustment may cause damage!
SAFETY INSTRUCTIONS
• Never open the Wireless Charging Desk Light
• Never touch the plug contacts with sharp or metal objects.
• Only use the provided original charger for the lamp
• Keep the lamp away from magnetic fields
• Make sure that cables cannot cause a trip hazard.
• Use only the original power supply and original accessories.
• Never place the device in the vicinity of heat sources.
• Never place the unit on surfaces that are heat sensitive.
• Protect the device and the wireless charging pad from special liquids, vapors and high hu-
midity environments.
• Unplug the unit at the main power socket before cleaning. Do not use any solvent based
cleaning agents, only a soft, dry anti-static cloth.
• Do not attempt repairs yourself.
• If the unit is not properly installed or operated DreamLED® cannot accept liability .
SUPPORT
For more information, technical questions and return requests concerning this product, you
support@dream-led . eu .
should contact:
GUARANTEE
Copyright © DreamLED® . DreamLED® is a registered trademark of TE-Group NV . The DreamLED®
brand stands for superior product quality and outstanding customer service . That is why
DreamLED® warrants this product against all defects in material and workmanship for a period
of two (2) years from the date of original purchase of the product. The terms of this guarantee
and the extent of responsibility of DreamLED under this warranty can be downloaded from the
www . dream-led . eu .
website:
GB
ILLUSTRATIONS
Lamppost
Wireless charging area
Light mode button
ON/OFF button
Timer button
DECLARATION OF CONFORMITY
Hereby, Par la présente,
Company: TE-GROUP nv
/ Entreprise:
Address: Kapelsestraat 61, 2950 Kapellen - BELGIUM
/ Adresse:
declare that the following equipment: / déclare que le dispositif suivant :
Product Name: DreamLED Wireless Charging Desk Light
/ Nom du
produit: WDL-100
Product Type: Wireless Charging Desk Light
/ Type de produit:
conforms with the following safety requirements of the directives 2011/65/EU, 2014/30/
EU & 2014/35/EU. Conformity is guaranteed by the CE-symbol. This product has been
tested against following standards and specifications, applying versions valid in January
2018. The full text of the EU declaration of conformity is available at the following internet
address:
www.dream-led.eu.
est conforme aux exigences de sécurité suivantes des directives 2011/65/EU, 2014/30/EU
& 2014/35/EU. La conformité est garantie par le symbole CE. Ce produit a été testé par
rapport aux normes et spécifications suivantes, appliquant les versions valides en Janvier
2018. Le texte complet de la déclaration UE de conformité est disponible à l'adresse
internet:
www.dream-led.eu.
Standards:
EN 55015:2013+A1:2015, EN 61547:2009
EN 61000-3-2:2014, EN 61000-3-3:2013
EN 60598-2-4:1997, EN 60598-1:2015
EN 60335-1:2012/A11:2014, EN 62233:2008
EN 60950-1:2006/A2:2013, EN 61558-2-16:2009/A1:2013
EN 61347-1:2008/A2:2013, EN 61347-2-13:2014
EN 62493:2015, AfPS GS 2014:01 PAK 3.1
Authorized Signature
S. Izaks, TE-Group NV
January 2018, Kapellen
------------ Manual/DreamLED Wireless Charging Desk Light/01-18/V01 -------------
Copyright © DreamLED
Lamp head
Rotation Point
Base
Adapter input
DC 5V
WIRELESS CHARGING
DESK LIGHT WDL-100
®
User's Manual
NL FR D
GB
