Keystone EPI2-MAN-652NA-OM1 User Manual

I/o module
Hide thumbs

Advertisement

Quick Links

Download this manual
EPI
Quarter-turn Electric Actuators
2
Instruction and operating manual
EPI
-MAN-652NA-OM1
2
I/O Module
User's Manual
2 NA
June 07
2 NA
May 07
2 NA
Sept. 06
2
Jun 06
1
Feb 06
0
Sept 2005
Rev.
Date
Note:
Tyco Valves & Controls has taken every care in collecting and verifying the documentation
contained in this Instruction and Operating Manual.
The information herein contained is reserved property of Tyco Valves & Controls.
® Copyright by Tyco Valves and Controls. All rights reserved.
A tyco International Ltd. Company
N.A Version revision 2
of N.A Version revision 1
N.A Version Created
Revision
Revision
First Issue
DESCRIPTION
T.K.
T.K. / D. L. P.
T.K. / D. L. P.
A.G.
G.A.
A.G.
G.A.
A.G.
G.A.
Prepared
Approved
1

Advertisement

loading

Summary of Contents for Keystone EPI2-MAN-652NA-OM1

  • Page 1 Quarter-turn Electric Actuators Instruction and operating manual -MAN-652NA-OM1 I/O Module User’s Manual 2 NA T.K. June 07 N.A Version revision 2 2 NA May 07 of N.A Version revision 1 T.K. / D. L. P. 2 NA Sept. 06 N.A Version Created T.K.

  • Page 2: Table Of Contents

    Quarter-turn Electric Actuators Instruction and operating manual INDEX OPTIONAL MODULE 1 (OM1)....................... 3 INSTALLATION............................3 SETTING AND CONFIGURATION ....................... 6 MONITOR RELAY FUNCTIONALITY AND SETTING ..............10 OM1 WIRING DIAGRAM......................11 ® Copyright by Tyco Valves and Controls. All rights reserved. A tyco International Ltd.

  • Page 3: Optional Module 1 (Om1)

    Quarter-turn Electric Actuators Instruction and operating manual OPTIONAL MODULE 1 (OM1) The optional OM1 I/O module can be installed by the factory or ordered as a kit and installed in the field. The OM1 provides the following functions: • Positioner that will accept an analogue signal input of 4-20 mA or 0-10 Vdc or can be turned off to allow use of module as a retransmission/monitor relay/additional switch module only •...
  • Page 4 Quarter-turn Electric Actuators Instruction and operating manual Pull out the 4 black cables (already installed in the base Remove the local mechanical indicator by pulling actuator) (fig. 4) upward (fig. 5) Fig. 4 Fig. 5 Connect the flat ribbon cable to connector J9 on the OM1 card to connector J8 on the logic card in the actuator (Figures 6 and 7) Connector J9 Connector J8...
  • Page 5 Quarter-turn Electric Actuators Instruction and operating manual Connect the 2-pin connector to connector J7 on the Connect the 2-pin connector to connector J7 on the Connect the 3-pin connector to connector J6 on the Connect the 3-pin connector to connector J6 on the OM1 card (figure 10).

  • Page 6: Setting And Configuration

    Quarter-turn Electric Actuators Instruction and operating manual SETTING and CONFIGURATION IMPORTANT: The following instructions assume that all start-up and calibration instructions for the base actuator has been performed per the basic instruction handbook MAN 652NA or MAN 652NA_SG. OM1 configuration and setup is done using the controls on the card. To access these controls, the actuator cover must be removed.
  • Page 7 Quarter-turn Electric Actuators Instruction and operating manual The OM1 has the following default settings: Default Value Function Relay AUX1 0 to 9 Relay AUX2 0 to 9 Relay AUX3 0 to 9 Relay AUX4 0 to 9 100% 0 (stay-put) Fail position on loss of signal 1 (fully open) Stay-put...
  • Page 8 Quarter-turn Electric Actuators Instruction and operating manual Selecting 4-20 mA Command Signal To return to the default input command setting of 4 – 20 mA: Enter setup / configuration mode - move SW4 switch to the ON position Refer to function number 14 in the table above Rotate Switches SW8, SW7 and SW9 to the positions indicated Confirm by pushing the ENTER pushbutton SW2, the red LED will illuminate to confirm the selection Referring to Figure 20 (below) move SW3_1 to the OFF position, SW3_2 to the ON position and SW5 to the ON...
  • Page 9 Quarter-turn Electric Actuators Instruction and operating manual Auxiliary output relays AUX1, AUX2, AUX3 and AUX4 To modify the trip points of the auxiliary relay outputs: Enter setup / configuration mode - move SW4 switch to the ON position Refer to function numbers 1-4 in the table above Rotate Switches SW7 and SW8 to the positions indicated in the charts below Confirm each setting by pushing the ENTER pushbutton SW2, the red LED will illuminate to confirm the selection Exit configuration mode (move SW4 to position 1)

  • Page 10: Monitor Relay Functionality And Setting

    Quarter-turn Electric Actuators Instruction and operating manual MONITOR RELAY FUNCTIONALITY AND SETTING The monitor relay provides remote indication of the following parameters: Table 2: Monitor relay functionality 4-20mA input signal lost Over-torque Incorrect direction of travel High temperature Position sensor failure Selector switch in “local”...

  • Page 11: Om1 Wiring Diagram

    Quarter-turn Electric Actuators Instruction and operating manual OM1 WIRING DIAGRAM 5) 4-20 mA OR 0-10VDC to be selected on the OM1 board ® Copyright by Tyco Valves and Controls. All rights reserved. A tyco International Ltd. Company...
  • Page 12 Quarter-turn Electric Actuators Instruction and operating manual ® Copyright by Tyco Valves and Controls. All rights reserved. A tyco International Ltd. Company...
