Customer Support If you are unable to solve a problem after reading this manual, visiting the product support page, or searching the Knowledge Base, contact VersaLogic Technical Support at (503) 747- 2261. VersaLogic support engineers are also available via e-mail at Support@VersaLogic.com.
Careful parts sourcing and US-based technical support ensure the highest possible quality, reliability, service and product longevity for this exceptional product. Ordering Information Model Function VL-MPEe-E6E 1 Gigabit Ethernet Mini PCIe Module VL-MPEe-E6E-P 1 Gigabit Ethernet with POE Mini PCIe Module MPEe-E6E Hardware Reference Manual...
Introduction Technical Specifications Specifications are subject to change without notification. Board Size: Power Over Ethernet (POE): 30.00 mm x 50.95 mm x 15 mm (Mini PCIe standard) IEEE 802.3at-2009 Types 1 (POE) and 2 (POE+). Applies to MPEe-E6E-P only. Storage Temperature: -40°...
Introduction Warnings LECTROSTATIC ISCHARGE Warning! Electrostatic discharge (ESD) can damage circuit boards, disk drives and other components. The circuit board must only be handled at an ESD workstation. If an approved station is not available, some measure of protection can be provided by wearing a grounded antistatic wrist strap. Keep all plastic away from the board and do not slide the board over any surface.
-E6E M OUNTING The VL-MPEe-E6E is a full size Mini PCIe card which mounts into a full size Mini PCIe site. On VersaLogic CPU boards, the module is secured using two nylon screws. VersaLogic supplies 2 mm nylon screws (VL-HDW-110) and 2.5 mm nylon screws (VL- HDW-108).
The non-PoE SKU of this product uses the adapter cable VL-CBR-1605. This is a 12-inch, 16-pin Click-Mate to one RJ-45 connector adapter. The PoE SKU (VL-MPEe-E6E-P) uses cable CBR-1606. It connects to an RJ45 plug and has flying leads for connecting PoE power and the SDP IEEE-1588 signal. See the MPEe-E6E datasheet for full information on accessories and specifications.
Interfaces and Connectors The table below shows the function of each pin. Ethernet Table 1. Ethernet Connectors 10/100/1000 10/100/1000 10/100 Signals 10/100 Signals Signals Signals - Auto Switch (Tx or Rx) BI_DD- + Auto Switch (Tx or Rx) BI_DD+ - Auto Switch (Tx or Rx) BI_DB- + Auto Switch (Tx or Rx) BI_DB+...
Page 11
Interfaces and Connectors Pin Signal Name Mini Card Function Description I210-IT Ethernet controller. Ground PERST# Card reset Reset for I210-IT Ethernet controller PERn0 PCIe receive – PCIe output from the I210-IT 3.3VAUX 3.3V auxiliary source 3.3V power PERp0 PCIe receive + PCIe output from the I210-IT Ground Ground...
Interfaces and Connectors LEDs Table 3. Status LEDs Ref Des State Description Green Ethernet On - Green Link Good (pulses with activity) Link/Activity LED Link is not good or cable is not connected Green Ethernet D7 1-2 On - Green 100BaseT Speed Speed LED #1 (dual)
