Please note these are basic keystroke details to setting up your system. For in-depth
information, please consult your manual.
Also Note that before applying any of the following keystrokes the controller would
need to be taken out of idle mode this can be done by pushing any button (the back
light on display switches on)
Setting the Clock:
Press
"CLOCK"
button
Hour "00" blinks on display
Press
"+
-"button to adjust hour
Press
"CLOCK"
button
Minute "00" blinks on display
Press
"+
-"button to adjust minute
Press "ESC"button to save set value
Setting the Timed Heating:
Press
"SET"
button twice (2x)
"THTS" is displayed
Press
"+
"button twice (2x)
"TH1O" is displayed (Heating period 1 on) Default 03:00, 52 Deg (Electrical
element will switch on at 03:00am if the temperature is below 52 Deg)
Press
"SET"
button
"03" (hour) blinks, use
Press
"SET"
button
"00" (Minute) blinks, use
Press
"SET"
button
"52.0" (Temperature) blinks, use
Press
"ESC"
button
"TH1O" is displayed
Press
"+
"button"TH1F" is displayed (Heating period 1 off) Default 06:00, 58 Deg
S
S
UN
CAN™
Quick Setup Guide
"+ -"
button to adjust
"+ -"
button to adjust
"+ -"
button to adjust
SR81
Advertisement
Summary of Contents for SUNSCAN SR81
- Page 1 SR81 CAN™ Quick Setup Guide Please note these are basic keystroke details to setting up your system. For in-depth information, please consult your manual. Also Note that before applying any of the following keystrokes the controller would need to be taken out of idle mode this can be done by pushing any button (the back...
- Page 2 (Electrical element will switch off at 06:00am or if the temperature reaches 58 Deg before) Press “SET” button “06” (hour) blinks, use “+ -“ button to adjust Press “SET” button “00” (Minute) blinks, use “+ -“ button to adjust Press “SET”...
- Page 3 Press “ESC” button “TH2F” is displayed Press “+ “button “TH3O” is displayed (Heating period 3 on) Default 15:01, 52 Deg (Electrical element will switch on at 15:01pm if the temperature is below 5 2 Deg) Press “SET” button “15” (hour) blinks, use “+ -“...
- Page 4 Press “+ -“ button to adjust desired temperature Press “Manual Heating” button Note that this will heat the tank to the pre-set above one time and that when the pre-set is reached it will switch off and revert to the pre programmed timed heating sessions.
