WatchMate
AIS
Plotting range
Current
Profile
Nav Aid
Your
position
Guard range
Transmit warning
Triangle points in the direction of the target's heading.
This target meets one or more of your alarm criteria.
An aid to navigation.
Search and rescue transponder (AIS SART).
Target is marked as a member of your "fleet".
Selected target. Press the Select button to view the complete
target details.
Target is "lost". No AIS data has been received from the target
within the expected intervals.
N
Display is oriented North-Up for this profile. Use setup to change.
AIS data is not being transmitted. Check the AIS Status screen.
!
You must configure your vessel MMSI in order to transmit.
WMX850 Getting Started Guide
®
[6nm]
Coastal
!
Ordinary target
Your heading
045
T
1 Filtered
Dangerous target
Total targets and
filtered targets
6 Targets
Next
Prev
Select
Menu
1 Msg
Safety messages
Advertisement
Table of Contents
Related Manuals for vesper marine WatchMate 850
Summary of Contents for vesper marine WatchMate 850
- Page 1 WatchMate WMX850 Getting Started Guide ® Total targets and Your heading Plotting range filtered targets [6nm] 6 Targets Coastal 1 Filtered Next Current Profile Prev Nav Aid Select Your position Menu Guard range 1 Msg Ordinary target Safety messages Transmit warning Dangerous target Triangle points in the direction of the target’s heading.
- Page 2 VHF and GPS Antenna Information A dedicated VHF antenna or Vesper Marine AIS/VHF Antenna Splitter is required. Mount the antenna as high as possible and as far as practical from any existing VHF, HF or radar antennas. Make sure your VHF antenna is well tuned at the AIS end of the band (VSWR 2:1 or less at 162MHz).
- Page 3 Closest point of approach in nautical miles. The nearest a target will come to your vessel if both maintain their course and speed. TCPA Time until closest point of approach will occur (minutes and seconds). Bearing from your vessel in degrees magnetic, true or relative. Range from your vessel in nautical miles.
- Page 4 WatchMate is not a substitute for proper seamanship. or reliable and the Vesper Marine Limited cannot be held liable for any injury, damage or loss, caused by, during, or because of the installation, use or inability to use this device. The WatchMate is to be installed and used entirely at your own risk.
