CX250
CX450
CX550
CX750
CX950
CX1250
CX600
CX650
CX800
CX1000
CX1800
CX1100M
CX2000M
Congratulations on your
purchase of a
CHAOS EXXTREME Amplifier.
It has been designed, engineered
and manufactured to bring you
the highest level of performance
and quality, and will afford you
years of listening pleasure.
Thank you for making
your choice for car audio
entertainment!
Two Channel
MOSFET Car Audio
Amplifiers
Four Channel
MOSFET Car Audio
Amplifiers
Five Channel
MOSFET Car Audio
Amplifier
MonoBlock
MOSFET Car Audio
Amplifier
U S E R ' S M A N U A L
CONTENTS
page
2
2
3
3
4
4
4
5
6
9
2CH and Bridged Modes
13 2CH Power and Speaker wiring
TriMode
14 4CH Power and Speaker wiring
4CH and Bridged Modes
15 4CH Power and Speaker wiring
TriMode
16 5CH Power and Speaker wiring
5CH Mode
17 5CH Power and Speaker wiring
18 5CH Power and Speaker wiring
19 MonoBlock Power
CHAOS EXXTREME MOSFET Amplifier User's Manual - page 1
Speaker wiring
and
Advertisement
Table of Contents
Related Manuals for Boss Chaos Exxtreme CX2000
Summary of Contents for Boss Chaos Exxtreme CX2000
-
Page 1: Table Of Contents
CX250 Two Channel MOSFET Car Audio CX450 Amplifiers CX550 CX750 CX950 CX1250 CX600 Four Channel MOSFET Car Audio CX650 Amplifiers CX800 CX1000 CX1800 Five Channel MOSFET Car Audio Amplifier CX1100M MonoBlock MOSFET Car Audio CX2000M Amplifier Congratulations on your purchase of a CHAOS EXXTREME Amplifier. -
Page 2: Introduction
Introduction With the CHAOS EXXTREME MOSFET amplifier series, we are introducing eleven new amplifiers, all designed in the USA. This new series includes a two monoblock amps, six 2-channel, four 4-channel amplifiers and a 5-channel amp. All CHAOS EXXTREME models feature variable low pass and high pass crossovers and variable input gain controls. -
Page 3: Features
Features Your new CHAOS EXXTREME amplifier features the following: • Class A-B operation • Bridgeable outputs (except CX1100M and CX2000M) • Tri-Mode capable (except CX1100M and CX2000M) • MOSFET PWM (Pulse Width Modulated) Power Supply • 2 Ohm stable stereo operation with output power increase •... -
Page 4: General Precautions
General precautions Before installing and using your amplifier, please be- come familiar with all the infor- mation contained in this manual. Please keep this manual in a safe place for future reference. • Do not open or attempt to repair this unit yourself. -
Page 5: Connecting The Amplifier
Connecting the amplifier Before doing any wiring, look through this manual and identify the diagrams to follow for power, input and speaker connections for your particular installation. Be sure you understand all the connections before you proceed. 1. Connect the power ground terminal to the closest point on the chassis of the car. -
Page 6: Low Level Input Wiring
Low Level Input Wiring Low-level (RCA) input wiring is preferred for best audio performance. Always use a high-quality RCA cable for best audio performance. NOTE: Do not connect BOTH the high level and low level inputs from your receiver to your amplifier at the same time! 2-Channel Amplifiers CX250, CX450, CX550, CX750, CX950, and CX1250... -
Page 7: Channel Amplifier
Low Level Input Wiring Low-level (RCA) input wiring is preferred for best audio performance. Always use a high-quality RCA cable for best audio performance. NOTE: Do not connect BOTH the high level and low level inputs from your receiver to your amplifier at the same time! 5-Channel Amplifier CX1800 HIGH... - Page 8 Low Level Input Wiring Low-level (RCA) input wiring is preferred for best audio performance. Always use a high-quality RCA cable for best audio performance. NOTE: Do not connect BOTH the high level and low level inputs from your receiver to your amplifier at the same time! MonoBlock Amplifier CX1100M POWER...
-
Page 9: High Level Input Wiring
High Level Input Wiring The high level input(s) should only be used when your head unit lacks RCA outputs. If the RCA outputs are not present, connect the speaker outputs from the receiver to the high level input connector of the amplifier. Be sure to observe polarity to avoid audio phase problems. - Page 10 High Level Input Wiring The high level input(s) should only be used when your head unit lacks RCA outputs. If the RCA outputs are not present, connect the speaker outputs from the receiver to the high level input connector of the amplifier. Be sure to observe polarity to avoid audio phase problems.
- Page 11 High Level Input Wiring The high level input(s) should only be used when your head unit lacks RCA outputs. If the RCA outputs are not present, connect the speaker outputs from the receiver to the high level input connector of the amplifier. Be sure to observe polarity to avoid audio phase problems.
-
Page 12: 2Ch Power And Speaker Wiring
Power and Speaker Wiring 2 Channel and Bridged Modes Channel Mode SPEAKER CONNECTIONS BRIDGED Bridged Mode SPEAKER CONNECTIONS BRIDGED Connect the Positive (+) terminal of the subwoofer to the L (+) amplifier terminal. Connect the Negative (-) terminal of the subwoofer to the R (-) amplifier terminal. - Page 13 Power and Speaker Wiring Tri-Mode Tri-mode operation allows you to connect this amplifier to a pair of main speakers plus a subwoofer on one pair of output channels. The main speakers will operate in STEREO while the subwoofer simultaneously operates in MONO. To set up the amplifier to run in this mode, put the crossover switches in the FULL position.
-
Page 14: Bridged Mode
Power and Speaker Wiring 4 Channel and Bridged Modes Speaker Speaker Four Channel Mode SPEAKER Speaker IMPEDANCE 2-8 OHMS Speaker SPEAKER IMPEDANCE 4-8 OHMS RIGHT Subwoofer Bridged Mode LEFT Subwoofer CHAOS EXXTREME MOSFET Amplifier User’s Manual - page 14 CX600, CX650, CX800 and CX1000 SPEAKER IMPEDANCE 2-8 OHMS... -
Page 15: Trimode
Power and Speaker Wiring Tri-Mode Tri-mode operation allows you to connect this amplifier to a pair of main speakers plus a subwoofer on one pair of output channels. The main speakers will operate in STEREO while the subwoofer simultaneously operates in MONO. To set up the amplifier to run in this mode, put the crossover switches in the FULL position. - Page 16 Power and Speaker Wiring 5 Channel Mode Five Channel Mode Subwoofer SPEAKER IMPEDANCE 2-8 OHMS SPEAKERS SPEAKER IMPEDANCE 2-8 OHMS Speaker Speaker CHAOS EXXTREME MOSFET Amplifier User’s Manual - page 16 – Speaker Speaker – CH1/2 BRIDGED FUSES POWER CONNECTIONS GROUND REMOTE CH3/4 BRIDGED...
- Page 17 Power and Speaker Wiring Bridged Mode Subwoofer SPEAKER IMPEDANCE 2-8 OHMS Bridged Mode SPEAKERS LEFT SPEAKER IMPEDANCE Subwoofer 4-8 OHMS Connect the Negative (-) terminal of the RIGHT subwoofer to the CH2 (-) amplifier terminal. Connect the Positive (+) terminal of the RIGHT subwoofer to the CH1 (+) amplifier terminal.
- Page 18 Power and Speaker Wiring Tri-Mode Tri-mode operation allows you to connect this amplifier to a pair of main speakers plus a subwoofer on one pair of output channels. The main speakers will operate in STEREO while the subwoofer simultaneously operates in MONO. To set up the amplifier to run in this mode, put the crossover switches in the FULL position.
- Page 19 Power and Speaker Wiring MonoBlock Mode MonoBlock Mode SPEAKER Monoblock Amplifiers CX1100M and CX2000M Speaker – SPEAKER IMPEDANCE 2-8 OHMS FUSES POWER CONNECTIONS BATT+ REMOTE GROUND Chassis ground point to REMOTE TURN-ON terminal of head unit FUSE CHAOS EXXTREME MOSFET Amplifier User’s Manual - page 19 Battery...
-
Page 20: Troubleshooting
Troubleshooting If you experience operation or performance problems with this product, compare your installation with the electrical wiring diagram on the previous pages. If problems persist, read the following troubleshooting tips which may help eliminate the problems. SYMPTOM POSSIBLE REMEDY Amplifier will not Check to make sure you have a good ground connection. -
Page 21: Specifications
Specifications 2-Channel MOSFET Amplifiers MODEL CX250 RMS POWER 75W x 2 into 4 Ohms MAX POWER 200W X 2 into 2 Ohms BRIDGED POWER 400W X 1 into 4 Ohms Min. speaker 2 Ohm Stereo impedance 4 Ohm Mono Bridged 0.01% Frequency response 9Hz-50kHz... - Page 22 Notes...
