- Page 1 VPEB VPEB Van Perlo Elektronica Van Perlo Elektronica & Besturingstechniek & Besturingstechniek DTS-100 Mounting Instructions Author: Leon J.A. van Perlo Version: Smart electronics for your miniature world Date: October 8 , 2020...
- Page 2 Control your Miniature World VPEB Mounting Instructions DTS100 Release Management This manual applies to: • Module DTS 100mm • Turntable Fleischmann 6052(C), 6152(C), 6652 (Märklin) ©2020 This document, or any information contained herein, may not be copied or distributed, in whole or in parts, in whatever form, without the explicit written approval of the original author.
- Page 3 Control your Miniature World VPEB Mounting Instructions DTS100 Contents Getting Started....................4 Introduction ....................4 In the Package ....................4 Further supplies ..................... 4 Preparation ..................... 5 Mounting ......................7 ©2020 Leon van Perlo Version 0.9 – October 8 , 2020...
- Page 4 The downside to this method is that you have to work accurately for it to fit properly. This manual will help you with that. The method described here only applies to the DTS-100 module. A different manual is available for the DTS-75. Its installation is simpler and requires even less space.
- Page 5 Control your Miniature World VPEB Mounting Instructions DTS100 2 Preparation The intention is that the DTS is mounted as centered as possible and as close as possible to the bottom of the turntable. The bottom of the turntable is not completely flat, so an exact size is difficult to give, but the highest desired position is that the DTS just does not touch the bottom, the lowest desired position is approx.
- Page 6 DTS-100 and through the extension plate. The other bolt (with washer) comes through the (only fitting) other hole in the plate. On the bolt that goes through the DTS you put a washer and wing nut, on the other bolt you put a washer and normal nut.
- Page 7 Control your Miniature World VPEB Mounting Instructions DTS100 3 Mounting We are now going to mount the blocks against the bottom of the table. It is essential that you work very accurately and therefore it is also essential that you use the supplied template.
- Page 8 Control your Miniature World VPEB Mounting Instructions DTS100 Now take the DTS with extension plates and place it over the 4 bolts of the base blocks. You don't have to put the filler blocks on it yet. It should fit, or almost. If it doesn't fit right away, you can turn the base blocks a few degrees to the left or right.
