  • Page 1 USE AND MAINTENANCE SITREX FSP 100/150 SPREADER...

  • Page 3: Identification Labels

    -FOREWORD This manual is an integral part of the machine and contains information necessary for its operation and maintenance. Operators and maintenance staff are advised to read the manual before using the machine or carrying out any maintenance. This guide, or a copy of it, must always be kept in a convenient place for reference. It is strictly forbidden to change its content and tear off pages.

  • Page 4: Warranty

    - WARRANTY The manufacturer warrants new machinery to be free from defects in material and work- manship at the time of delivery to the original purchaser if correctly set up and operated according to this Operator's Handbook. The manufacturer undertakes to repair or replace free of charge any defective part which should be returned by the purchaser (freight prepaid) and found to be defective on in- spection authorised by the manufacturer during the warranty period.

  • Page 5: Accident Prevention Regulations

    - ACCIDENT PREVENTION REGULATIONS how to avoid ac- cidents • To avoid accidents, pay close attention to the warning notices affixed on the machine and read this guide carefully. • The use of the spreader is restricted to the functions, for which it has been designed and which are described in the present guide.
  • Page 6 YOU ARE ADVSED NOT TO: • load the hopper with wet products as these may clog the machine. • use the spreader to scatter stones or other dangerous materials. • dismantle safety devices and the covers protecting them. • transporting people is prohibited both while working and during transfers. The fertilizer spreader must never be used by employees under the age of eighteen.
  • Page 7 Position the tractor close to the machine, apply the handbrake and secure the drawbar to the tractor using the special pin (Fig.6). LOADING Everytime the spreader has to be filled up it is advisable to check that there aren’t any for- eign particles on the bottom that may obstruct the shutter.

  • Page 8: Maintenance

    - MAINTENANCE For efficient maintenance: disconnect the spreader from the tractor , clean the working ar- ea and use suitable utensils suitable to the type of work that the spreader is used for. After every 50 hours of work: - Grease the wheel-hub by way of the special lubricator -check that the screws are tight -check the pressure of the tyres - STORAGE...

  • Page 9: Transporting The Machine

    - TRANSPORTING THE MACHINE The machine is supplied disassembled and packed in cardboard and polythene; therefore read this instruction and maintenance booklet carefully. Dispose of the packing properly in binds provided for this purpose. - THECNICAL SPECIFICATIONS OVERALL DIMENSION Mod. Height Width Wheight Capacity FSP100...
  • Page 13 FERTILIZER SPREADING TABLE (METRIC)
  • Page 14 SEEDS SPREADING TABLE (METRIC)
  • Page 15 FERTILIZER SPREADING TABLE (US) SPREADING TABLE FOR FERTILIZER SPREADERS SERIES FSP Lbs/acre OF FERTILIZER TO BE SPREAD WITH SPREADING MPH/h FERTILIZER ENGINE R.P.M. AS IN COLUMN Mph/h OPENING TYPE RANGE (yards) 616 1016 1298 1601 1940 2343 2578 2899 3176 3573 937 1030 1164 1294 1452 COARSE-GRAINED 15,5...
  • Page 16 SEEDS SPREADING TABLE (US) SPREADING TABLE FOR SEEDS SPREADERS SERIES FSP Lbs/acre OF SEEDS TO BE SPREAD WITH SPREADING MPH/h ENGINE R.P.M. AS IN COLUMN Mph/h SEEDS RANGE OPENING (yards) WHEAT BARLEY RYE GRASS TURNIP SEEDS RED CLOVER...
  • Page 18 Zona Industriale-Viale Grecia, 8 06018 TRESTINA-(Perugia)-ITALY Tel. +39.075.8540021-Telefax +39.075.8540523 e-mail: sitrex@sitrex.it www.sitrex.com...

  • Page 19: Spare Parts List

    SPARE PARTS LIST ASSEMBLY USE AND MAINTENANCE SITREX FS SPREADER...
  • Page 22 The manufacturer warrants new machinery to be free from defects in material and workmanship at the time of delivery to the original purchaser if correctly set up and operated according to this Operator's Handbook. The manufacturer undertakes to repair or replace free of charge any defective part which should be returned by the purchaser (freight prepaid) and found to be defective on inspection authorised by the manufacturer during the warranty period.
  • Page 35 SPREADING TABLE...
  • Page 36 SEEDS SPREADING TABLE...

  • Page 37: Spare Parts List

    SPARE PARTS LIST...
  • Page 38 SPARE PARTS LIST 600.448 Three holes 630.782 mounting Two holes gearbox mounting gearbox...
  • Page 39 SPARE PARTS LIST - LISTE DBS PIECES DETACHEES Part.No.- Qty. - Code DESCRIPTIO N DES CRIPTIO N Rèf Q.tè 400 .05 0 Frame Chàssis 400 .05 1 FS 50 Hopp er Trèmie FS 5 0 400 .05 2 FS 100 Hoppe r Trèmie FS 100 400 .05 3 FS 150 Hoppe r...
  • Page 40 SPARE PARTS LIST - LISTE DBS PIECES DETACHEES Part.No.- Qty. - Code DESCRIPTIO N DES CRIPTIO N Rèf Q.tè 600 .11 5 Wa sh er Rond eile 600 .55 3 E cro u 600 .00 6 Screw V is 600 .06 0 Screw V is 600 .18 4...
  • Page 41 CARDAN SHAFT 600.396 CARDAN SHAFT/ARBRE A CARDAN 600.396 ITEM PART NO Q.ty DESCRIPTION NOTE 610.099 YOKE 610.100 CROSS JOURNAL ASS. 610.101 YOKE WITH OUTER TUBE 610.102 YOKE WITH INNER TUBE 610.103 RING FOR OUTER TUBE 610.104 RING FOR INNER TUBE 610.057 COMPLETE PUSH BUTTON 610.105...
