MULTI INPUT MODULE
INSTRUCTION MANUAL
SCM-MIM
DOC: GLT-295-7-12
ISS: 001
DATE: 10.02.2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMART CONNECT MULTI-LOOP SCM-MIM and is the answer not in the manual?

Questions and answers

Related Manuals for Zeta Alarm Limited SMART CONNECT MULTI-LOOP SCM-MIM

Summary of Contents for Zeta Alarm Limited SMART CONNECT MULTI-LOOP SCM-MIM

  • Page 1 MULTI INPUT MODULE INSTRUCTION MANUAL SCM-MIM DOC: GLT-295-7-12 ISS: 001 DATE: 10.02.2021...

  • Page 2: Installation

    MULTI INPUT MODULE INSTRUCTION MANUAL General The SCM-MIM is a six input module that is designed to be DIN mounted inside of a Smart Connect Multi-loop control panel. It’s powered and interfaced to the panel via a RJ45 connection. The module has six class B inputs that are commonly used to monitor and raise alarms from any ancillary equipment such as sprinkler flow switches, aspiration detectors, secondary fire control panels, beam detectors, and external power supplies etc.
  • Page 3 MULTI INPUT MODULE INSTRUCTION MANUAL TRM RJ45 Port Address Designation Each RJ45 port on the Smart Connect Multi-loop termination has its own unique port address. This port address is important to keep note of as it is displayed on Alarm/Fault messages and is used when configuring or setting up cause and effects on the panel (See SCM operation manual GLT-261-7-10).

  • Page 4: Power-On Procedure

    MULTI INPUT MODULE INSTRUCTION MANUAL Power on Procedure 1. After the above has been completed, turn the panel on (Via AC Only). The panel will follow the same power up sequence described in initial power up section above 2. The panel will now display one of the following messages Message Meaning Panel has not detected any modules fitted...

  • Page 5: Field Wiring

    MULTI INPUT MODULE INSTRUCTION MANUAL Check that the module configuration is as expected using the to navigate the through the port     numbers. Press the icon to confirm the changes. The new module is now configured into the panel and is ready for use. Since the batteries are not connected, the panel will report them as removed, lighting the yellow “Fault”...

  • Page 6: Wiring Recommendations

    MULTI INPUT MODULE INSTRUCTION MANUAL Wiring recommendations Wire Gauge (AWG) Maximum Wiring Run (Metres) RECOMMENDED CABLE: 1450 Cable should be BS approved FPL, 2300 FPLR, FPLP or equivalent. Front Unit LED Indications LED Indication Description LED Indication Description On steady when the input is in an alarm Pulses to show communication between condition.
