PC56-HIST-xxxxLX
ControlLogix Platform
In-Rack PC with Data Historian
December 3, 2010
SETUP GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InRAX PC56-HIST LX Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ProSoft Technology InRAX PC56-HIST LX Series

  • Page 1 PC56-HIST-xxxxLX ControlLogix Platform In-Rack PC with Data Historian December 3, 2010 SETUP GUIDE...
  • Page 2: Your Feedback Please

    ProSoft Technology Product Documentation In an effort to conserve paper, ProSoft Technology no longer includes printed manuals with our product shipments. User Manuals, Datasheets, Sample Ladder Files, and Configuration Files are provided on the enclosed CD-ROM, and are available at no charge from our web site: www.prosoft-technology.com Printed documentation is available for purchase.
  • Page 3: Pc56 Products

    PC56 Products WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON-HAZARDOUS. AVERTISSEMENT - RISQUE D'EXPLOSION - AVANT DE DÉCONNECTER L'EQUIPMENT, COUPER LE COURANT OU S'ASSURER QUE L'EMPLACEMENT EST DÉSIGNÉ NON DANGEREUX. Warnings ATEX Warnings and Conditions of Safe Usage Power, Input, and Output (I/O) wiring must be in accordance with the authority having jurisdiction...
  • Page 4 Agency Approvals and Certifications EMC-EN61326-1:2006; EN6100-6-4:2007 CSA/cUL C22.2 No. 213-1987 CSA CB Certified IEC61010 ATEX EN60079-0 Category 3, Zone 2 EN60079-15 243333 ME06...
  • Page 5: Table Of Contents

    Limitation of Remedies ** ..................28 3.2.7 Time Limit for Bringing Suit ..................28 3.2.8 No Other Warranties ....................28 3.2.9 Allocation of Risks ....................28 3.2.10 Controlling Law and Severability ................28 Index ProSoft Technology, Inc. Page 5 of 29 December 6, 2010...
  • Page 6 Contents PC56-HIST-xxxxLX ♦ ControlLogix Platform Setup Guide In-Rack PC with Data Historian Page 6 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 7: Installing The Pc56 Embedded Pc

    This Setup Guide will help you get your PC56 Embedded PC up and running. If you need additional information, refer to the user manual located on the PC56- HIST CD-ROM shipped with your module. ProSoft Technology, Inc. Page 7 of 29 December 6, 2010...
  • Page 8: Package Contents

    Check jumper configurations (page 17, page 11, page 12, page 11) on each module Insert module in the ControlLogix rack (page 9) Connect your Peripherals (page 19) Verify Boot Up (page 20) Page 8 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 9: Installing Modules

    With a firm but steady push, snap the module(s) into place. If you are inserting multiple modules, make sure that all of the modules are aligned with their respective slots before you snap them into place. ProSoft Technology, Inc. Page 9 of 29 December 6, 2010...
  • Page 10: Optional Module Connections

    Insert the side-connect connector into the connector on the side of the PC56 as shown in the diagram. Be careful when inserting the connector as improper insertion may cause damage to the pins. Page 10 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 11: Verify Jumper Settings

    Jumpers are preconfigured, and in most cases, should not be changed. The following diagrams show the jumper configurations for the PC56 HIST module. 1.4.1 RS-232 (Default) 1.4.2 RS-422 Jumper Setting ProSoft Technology, Inc. Page 11 of 29 December 6, 2010...
  • Page 12: Rs-485 Jumper Setting

    This port permits a PC based terminal emulation program to view configuration and status data in the module and to control the module. The cable for communications on this port is shown in the following diagram: Page 12 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 13 This type of connection is required between the module and a modem or other communication device. The "Use CTS Line" parameter for the port configuration should be set to 'Y' for most modem applications. ProSoft Technology, Inc. Page 13 of 29 December 6, 2010...
  • Page 14 In-Rack PC with Data Historian RS-232: Null Modem Connection (Hardware Handshaking) This type of connection is used when the device connected to the module requires hardware handshaking (control and monitoring of modem signal lines). Page 14 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 15 (CTS) on the connector. If the port is configured with the Use CTS Line set to Y, then a jumper is required between the RTS and the CTS lines on the port connection. ProSoft Technology, Inc. Page 15 of 29...
  • Page 16 If communication in the RS-422 or RS-485 mode does not work at first, despite all attempts, try switching termination polarities. Some manufacturers interpret + and -, or A and B, polarities differently. Page 16 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 17 PC56-HIST-xxxxLX ♦ ControlLogix Platform Installing the PC56 Embedded PC In-Rack PC with Data Historian Setup Guide DB9 to RJ45 Adaptor (Cable 14) ProSoft Technology, Inc. Page 17 of 29 December 6, 2010...
  • Page 18 Installing the PC56 Embedded PC PC56-HIST-xxxxLX ♦ ControlLogix Platform Setup Guide In-Rack PC with Data Historian Page 18 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 19: Connecting Peripherals

    Just like any other PC, the PC56 is fully equipped for connections to a variety of devices. The inside label provides descriptions of the various ports and connectors. Caution: Make sure power to the ControlLogix rack is OFF before connecting peripherals to the PC56. ProSoft Technology, Inc. Page 19 of 29 December 6, 2010...
  • Page 20: Verify Operation

    Connect your peripherals such as monitor, keyboard, and mouse to the PC56 Historian using the appropriate connectors. Turn on power to the ControlLogix rack. The Windows desktop will appear on your monitor after boot up. Page 20 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 21: Support, Service & Warranty

    Return Material Authorization (RMA) Policies and Conditions ....23 LIMITED WARRANTY ................25 Contacting Technical Support ProSoft Technology, Inc. (ProSoft) is committed to providing the most efficient and effective support possible. Before calling, please gather the following information to assist in expediting this process:...
  • Page 22 Languages spoken include: Spanish, English Tel: +52-222-3-99-6565, Latin America (location in Puebla, Mexico) E-mail: soporte@prosoft-technology.com Languages spoken include: Spanish Tel: +55-11-5083-3776, Brasil (location in Sao Paulo) E-mail: brasil@prosoft-technology.com Languages spoken include: Portuguese, English Page 22 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 23: Return Material Authorization (Rma) Policies And Conditions

    The following Return Material Authorization (RMA) Policies and Conditions (collectively, "RMA Policies") apply to any returned product. These RMA Policies are subject to change by ProSoft Technology, Inc., without notice. For warranty information, see Limited Warranty (page 25). In the event of any inconsistency between the RMA Policies and the Warranty, the Warranty shall govern.
  • Page 24: Returning Units Under Warranty

    Return Material Authorization i. If a defect is found and is determined to be customer generated, or if the defect is otherwise not covered by ProSoft Technology s warranty, there will be no credit given. Customer will be contacted and can request module be returned at their expense;...
  • Page 25: Limited Warranty

    This Limited Warranty ("Warranty") governs all sales of hardware, software, and other products (collectively, "Product") manufactured and/or offered for sale by ProSoft Technology, Incorporated (ProSoft), and all related services provided by ProSoft, including maintenance, repair, warranty exchange, and service programs (collectively, "Services"). By purchasing or using the Product or Services, the individual or entity purchasing or using the Product or Services ("Customer") agrees to all of the terms and provisions (collectively, the "Terms")
  • Page 26: What Is Not Covered By This Warranty

    (collectively, "high risk activities"). ProSoft specifically disclaims any express or implied warranty of fitness for high risk activities. Page 26 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 27: Intellectual Property Indemnity

    The Warranty set forth in What Is Covered By This Warranty (page 25) are in lieu of all other warranties, express or implied, including but not limited to the implied warranties of merchantability and fitness for a particular purpose. ProSoft Technology, Inc. Page 27 of 29 December 6, 2010...
  • Page 28: Limitation Of Remedies

    Warranty shall remain in full force and effect. Any cause of action with respect to the Product or Services must be instituted in a court of competent jurisdiction in the State of California. Page 28 of 29 ProSoft Technology, Inc. December 6, 2010...
  • Page 29: Index

    PC56 Markings • 3 PC56 Products • 3 PC56™ Battery Warning • 3 Pinouts • 12, 17 ProSoft Technology® Product Documentation • 2 Return Material Authorization (RMA) Policies and Conditions • 23 Returning Any Product • 23 Returning Units Out of Warranty • 24 ProSoft Technology, Inc.
