Summary of Contents for Teknika 5425303
- Page 1 Teknik www.teknikoffice.co.uk Deep shelves for tall tales. Bookcase with Door NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Canyon Lane Collection | Model 5425303 PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 6-18 Safety Electric drill with 1/8" bit (ONLY in indicated step) Page 2...
- Page 3 Now you know Part Identifi cation our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. TOP (1) BOTTOM (1) DOOR (1)
- Page 4 Hardware Identifi cation HIDDEN CAM - 8 CAM SCREW - 8 WOOD DOWEL - 6 SHELF PIN - 12 PULL - 1 STRIKE PLATE - 1 MAGNETIC CATCH - 1 L-WRENCH - 1 HINGE - 2 APPLIQUE CARD - 2 FURNITURE TIPPING RESTRAINT KIT - 1 Page 4...
-
Page 5: Table Of Contents
Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. BLACK 1-9/16" PAN HEAD SCREW - 4 BLACK 1/2" HEX HEAD SCREW - 8 BLACK 1/2" FLAT HEAD SCREW - 2 BLACK 1/2" PAN HEAD SCREW - 21 SILVER 1/2"... - Page 6 Step 1 Assemble your unit on a carpeted fl oor or on the empty carton to avoid å scratching your unit or the fl oor. Turn eight CAM SCREWS (2) into the TOP (A), and ENDS (B and C). å Push four HIDDEN CAMS (1) into the large holes in the ENDS (B and C).
- Page 7 Step 2 Push four HIDDEN CAMS (1) into the large holes in the å FIXED SHELF (D). Some assembly Insert six WOOD DOWELS (3) into the ENDS (B and C) å (and snacks) required. and FIXED SHELF (D). Meet Part (D). This component has been engineered to be lighter, stronger, faster…...
- Page 8 Step 3 Fasten the ENDS (B and C) to the FIXED SHELF (D). å Tighten four HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the FIXED SHELF å insert into the ENDS. Page 8...
-
Page 9: Black 1-9/16" Pan Head Screw
Step 4 Open the FURNITURE TIPPING RESTRAINT KIT (98) and å fasten the SAFETY STRAP to the TOP (A). Use the provided short screw. Fasten the TOP (A) to the ENDS (B and C). Tighten four å HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the ENDS insert into å... -
Page 10: Black 1/2" Hex Head Screw
Step 5 Fasten the LEGS (J) to the BASE (N). Tighten four BLACK å 1/2" HEX HEAD SCREWS (12) using the L-WRENCH (9). BLACK 1/2" HEX HEAD SCREW (4 used in this step) Page 10... -
Page 11: Black 1/2" Pan Head Screw
Step 6 Carefully turn your unit over onto its front edges. å Caution Unfold the LARGE BACK (H) and lay it over your unit. å Do not stand the unit upright without the BACK fastened. The unit may collapse. Make equal margins along all four edges of the LARGE BACK (H). å... - Page 12 Step 7 Carefully stand your unit upright. å Now might be a Place your unit in its fi nal location against a wall. Locate å good time to refresh the center of a stud in your wall near your unit and mark your drink.
-
Page 13: Black 1/2" Flat Head Screw
Step Step 8 This unit has the option of the door opening to the left or right. This step will show å you how to open the DOOR to the right. The next two steps will show you how to open the DOOR to the LEFT. -
Page 14: Black 3/4" Machine Screw
Step Step 9 Fasten the DOOR (K) to the RIGHT END (C). Use eight å SILVER 1/2" FLAT HEAD SCREWS (15). Fasten the PULL (5) to the DOOR (K). Use two BLACK 3/4" å MACHINE SCREWS (16). DOOR OPEN RIGHT Fasten the MAGNETIC CATCH (7) to the FIXED SHELF (D). - Page 15 Step 10 The following two steps will show you how to assemble the door to open left. å Fasten two HINGES (8) to the DOOR (K). Use four SILVER 1/2" FLAT å HEAD SCREWS (15). Fasten the STRIKE PLATE (6) to the DOOR (K). Use two BLACK 1/2" FLAT å...
- Page 16 Step Step 11 Fasten the DOOR (K) to the LEFT END (B). Use eight å SILVER 1/2" FLAT HEAD SCREWS (15). Fasten the PULL (5) to the DOOR (K). Use two BLACK 3/4" å MACHINE SCREWS (16). DOOR OPEN LEFT Fasten the MAGNETIC CATCH (7) to the FIXED SHELF (D).
- Page 17 Step Step 12 Refer to the enlarged diagram to identify the parts on å the HINGES. If you're doing this to help a friend, don't The DOORS may need some adjustments. Follow the text å leave without a bite. below to make needed adjustments. DOOR ADJUSTMENTS: å...
- Page 18 Step Step 13 Insert the SHELF PINS (4) into the hole locations of your choice in the ENDS (B and C). Set the ADJUSTABLE å SHELVES (L and M) onto the SHELF PINS. Peel APPLIQUES from the APPLIQUE CARD (10) and stick them onto each visible HIDDEN CAM å...
- Page 19 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves. •...
