3.5 mA For the initial tests, you can connect the supply voltages and the end switch to the MK1/100, and plug the 9-pin Sub-D jack on the front panel of the MK1/100 into the serial interface of the computer.
Switch off the power supply, before you connect the encoder to the MK1/100. For error-free operation it is necessary for the encoder to be connected with the MK1/100 via a shielded cable. In making the connection it is important to keep the cables as short as possible and to route them as far away from power cables as possible.
If the test is not completed successfully and the message "position error" appears, this may have two causes: 1. there is no connection between the motor and the MK1/100. 2. the polarity of the motor does not coincide with signals A and B of the encoder. As a result, the motor turns uncontrolled at top speed in one direction.
This can be expressed in the following logical equation: Detected_index impulse = /A * /B * Index In order to enable the MK1/100 to detect the index impulse, the MK1/100 must be informed of the count per turn of the encoder.
By increasing K a reduction in the overcorrection can be observed. With ITERATION K and K Manual MK1/100 · Hardware Installation zub machine control AG Seite 8...
The index impulse can not be The requirement that the A, Connect the /A- and /B-signals detected. B and /index signals are simul- of the encoder to the MK1/100, taneously low has not been ful- provided they exist (instead of A filled. and B).
–3 V … +5 V DC Input voltage high, U +13 V DC … U Input current low, I –0.1 mA … +0.1 mA Input current high, I < 1 mA Manual MK1/100 · Hardware Reference zub machine control AG Seite 11...
Defined output condition 200 ms after connecting the power supply Zero current = 0,5 mA (not connecting) +24 V load any output D – in case with inductive load user MK1/100 Manual MK1/100 · Hardware Reference zub machine control AG Seite 12...
105 mm; with brackets 130 mm for 19" systems 3 HE Height 54 mm inclusive cooling facility for 19" systems 11 TE Depth 160 mm Weight ca. 775 g Manual MK1/100 · Hardware Reference zub machine control AG Seite 13...
