Safety – Operation – Maintenance
Keep this document in a safe place
Read and understand this manual before operating your vacuum
Warthog Vacuum Tank
Poly Toxic Dust
Model: 603-105T, 603-107T, 603-115T
Scan this QR code for
online instructions and
documentation, or visit
www.ClaytonHowTo.com
603-105T
WARNING
SAFETY LEGEND
Read and understand operator's manual before
using this equipment.
Hearing protection is recommended when
operating this equipment.
• A HEPA Filter must be installed in this vacuum at all times
• If this vacuum is used to collect hazardous material, personal protective equipment should be used when opening the vacuum or emptying its contents
• If this vacuum is intended for Dust Ignition Proof Operation, it must be used with supplied or recommended accessories from Clayton Associates
• Any alteration to this equipment by a third party will nullify its warranty
603-107T
WARNING
WARNING
603-115T
WARNING
Eye protection is required when operating
this equipment.
WARNING
Respiratory protection is recommended when
operating this equipment.
April 2020
