Copyright 2012 ValuePoint Networks, Inc. All rights reserved.
Note: To download the current firmware you need your ValuePoint Webstore
account. Please contact sales@valuepointnet.com if you need more
information.

1. Configuring the Controller

1.1. Connect to the Controller:

The default LAN IP Address of the Controller is:
IP: 192.168.1.1
Set you managing computer to:
IP 192.168.1.100
Netmask 255.255.255.0
Or DHCP
Connect the LAN cable, and open a web browser to address 192.168.1.1. Default
Username / Password for the administrator is
Username: "root"
Password: "root"
We recommend changing the default password after the first login.

1.2. Configure WAN settings:

Depending on your broadband ISP, set the Controller to DHCP, PPPoE or Static Address.

1.2.1. WAN DHCP

If your WAN connection is TCP/IP, and you expect the Controller to receive a dynamic
address from a DHCP server, use this setting. This is most common with Cable Modem
service, or if you are connecting the Controller to an existing routed network or T1 router.
Simply select
Express Setup – DHCP Client

1.2.2. WAN PPPoE

If your WAN connection is DSL, or another kind of PPP-based network, use this setting.
You will need a Name and Password from your ISP to connect. Select
Express Setup – PPPoE
Network Controller 3560
Quick Start Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3560 and is the answer not in the manual?

Questions and answers

Related Manuals for Value Point 3560

Summary of Contents for Value Point 3560

  • Page 1 Copyright 2012 ValuePoint Networks, Inc. All rights reserved. Network Controller 3560 Quick Start Guide Note: To download the current firmware you need your ValuePoint Webstore account. Please contact sales@valuepointnet.com if you need more information. 1. Configuring the Controller 1.1. Connect to the Controller: The default LAN IP Address of the Controller is: IP: 192.168.1.1...
  • Page 2 Copyright 2012 ValuePoint Networks, Inc. All rights reserved. Provide The User and Password in the text fields. When connecting or reconnecting PPPoE it is recommended to reset or reboot the DSL Modem first and then reboot the Controller 3500. 1.2.3. Static WAN IP Address If you have Static IP settings provided by your ISP, or you are adding the Controller to an existing network, select Express Setup –...
  • Page 3 Copyright 2012 ValuePoint Networks, Inc. All rights reserved. Password: guest 1.4.1. Configure Local Authentication To manage user accounts directly from the Controller without an external authentication server, select: Security – Authentication – Local Authentication Click on Add/Modify User to see the current user database and make any changes. 1.4.2.
  • Page 4 Copyright 2012 ValuePoint Networks, Inc. All rights reserved. explicitly agreed to a legal terms of service to protect the venue. The terms of service feature will only allow access to users who specifically “click through” a legal agreement which you or the venues owner specifies. To enable Terms of Service select: Security –...
  • Page 5 Copyright 2012 ValuePoint Networks, Inc. All rights reserved. Customization – Login Page – External Portal Provide the URL of the page you wish unauthenticated users to be directed to in the text box. You will also need to add this URL to the URL Pass through table, so that unauthenticated users can access it.
  • Page 6 Note: If you have any HTTP GUI display problems please clear your Internet file cache in Internet Explorer by selecting Tools – Internet Options – Delete Files – Delete All Files. 2. Controller 3560 Default Settings Web configuration login (case sensitive): username: root - password: root Default LAN IP: 192.168.1.1...
  • Page 7 Copyright 2012 ValuePoint Networks, Inc. All rights reserved. Optimizing Controller Performance The Controller 3560 is designed to satisfy multiple network configurations and business models. If you are deploying the Controller in a high stress public environment where you will be using authentication, login redirect, Auto-IP, Auto-Proxy and other sophisticated features you can maximize the performance of the Controller by simplifying the WAN connection and providing a Static IP Address.
