- Page 1 UG-1032 6LAP5 LAN Adapter Panel Dual Modem December 2018...
- Page 2 The information in this document has been carefully checked and is believed to be accurate. However, no responsibility is assumed or implied for inaccuracies. Further more, QEI, reserves the right to make changes to any products herein described to improve reliability, function or design. QEI does not assume liability arising to the application or use of any product or circuit described herein;...
- Page 3 & spacing Revised to Reflect Designations June 1999 in Schematic Formatting Update March 2000 Formatting Update August 2001 Functional Description March 2008 Formatting Update September 2012 Formatting Update February 2016 Updated QEI Address December 2018 Copyright © 2016 QEI Revisions...
-
Page 4: Table Of Contents
Bell 202 Compatible Modem ..........5 Central Processor Panel Connections ......... 6 Test Tone ................7 8 Interconnection Cables ............7 9 Ordering Information ..............7 10 Other Related Equipment and/or Programs ......7 11 Other Related Documentation ..........8 Copyright © 2016 QEI Contents... -
Page 5: General Description
Configuration Table software. Refer to the 6CPP6 ConfigWiz Manual for information and instructions. WARNING The 6LAP5 is designed to connect to the 6CPP6 panel at JP4 and JP5 only. Do not connect the 6LAP5 to JP6/JP7 or any other connectors on the 6CPP6!!!! Copyright © 2016 QEI General Description... -
Page 6: Modem Hardware Specification
2.10 Test tone An alternate Mark/Space frequency tones can be sent from either one of the modems to the communication line for line alignment test. 2.11 Line Configuration 2-Wire or 4-Wire, jumper selectable Modem Hardware Specification Copyright © 2016 QEI... -
Page 7: Line Impedance
4.75 in. L x 4.00 in. W. x 1.00 in. H Power +12Vdc, -12Vdc, and +5Vdc from 6CPP6 through DIN connectors JP4 and JP5. Environment Temperature: 0 to +70 C Humidity: 5 to 95% @ +70 C, non-condensing. Weight 4 ounces Copyright © 2016 QEI General Specifications... -
Page 8: Strapping Description
Without pre-emphasizing JP14 JP13 Insert jumper for BYTE oriented protocol, remove the jumper for Bit oriented protocol. JP16 JP15 Insert jumper for test tone carrier. NOTE This jumper must be inserted for normal operation! Strapping Description Copyright © 2016 QEI... -
Page 9: Connection To The Line Transformers
Another amplifier is connected to the modem receiver input. Its gain is jumper selectable for -30 or -45 dBm input sensitivity, also measured across the external transformer of 600 ohm line. The micro-controller initializes the modem IC and Copyright © 2016 QEI Connection to the Line Transformers... -
Page 10: Central Processor Panel Connections
+5Vdc) as well as all interface signals between the 6LAP5 and the Central Processor Panel. WARNING The 6LAP5 is designed to connect to the 6CPP6 panel at JP4 and JP5 only. Do not connect the 6LAP5 to JP6/JP7 or any other connectors on the 6CPP6!!!! Functional Description Copyright © 2016 QEI... -
Page 11: Test Tone
The 6LAP5 works with specific 6CPP6 firmware. Refer to the documentation supplied with specific systems. 10 Other Related Equipment and/or Programs Model No. DESCRIPTION QEI Part Number 6CPP6 CENTRAL PROCESSOR PANEL 40-057552-XXXX 6CPP6 RTU ConfigWiz Software 80-000053-001 Copyright © 2016 QEI Interconnection Cables... -
Page 12: Other Related Documentation
6LAP5 LAN Adapter Panel Dual Modem UG-1032 11 Other Related Documentation Doc. No. Document Name UG-1024 6CPP6 CENTRAL PROCESSOR PANEL User's Guide ConfigWiz User’s Manual UM-2012 TP-803 6CPP6 TEST PANEL SOFTWARE INSTRUCTION MANUAL Other Related Documentation Copyright © 2016 QEI...
