- Page 1 Publication No. II 3477-D 11/97 Kodak INSTALLATION INSTRUCTIONS for the KODAK Miniloader 2000 P Humidifier up to SN 5031 CAT. Number 7197007 and for the KODAK Miniloader 2000 P Humidifier from SN 5032 CAT. Number 7192636 © KODAK AG STUTTGART, 1997...
- Page 2 The information contained herein is based on the experience and knowledge relating to the subject matter gained by Kodak prior to publication. No patent license is granted by this information. Kodak reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information.
-
Page 3: Table Of Contents
INSTALLATION INSTRUCTIONS TABLE OF CONTENTS INTRODUCTION ........................... 1-2 PACKING LIST ..........................1-3 INSTALLATION ..........................1-4 Part 1 ML2000 P up to SN5031..................1-4 Part 2 ML2000 P from SN 5032 ..................1-5 FINAL TEST ..........................1-13 KODAK AG, Stuttgart 11/1997... -
Page 4: Introduction
HUMIDIFIER ML2000 P II 3477-D INTRODUCTION The KODAK MINILOADER 2000 P HUMIDIFIER allows the relative humidity inside the ML2000 P to be increased. The HUMIDIFIER should be set to 50%. l e f t - h a n d I N N E R S I D E P A N E L H U M I D I F I E R A S S Y . -
Page 5: Packing List
G9906393 SEAL 9198031 T-ADAPTER G9907057 PRESSURE HOSE with SEALS The following PANELS are only needed up to SN 5031. They are part of CAT. No. 7197007 9310916 OUTER RIGHT-HAND SIDE PANEL 9310536 INNER RIGHT-HAND SIDE PANEL KODAK AG, Stuttgart 11/1997... -
Page 6: Installation
- h a n d S I D E P A N E L figure 1-2 Place the new inner right-hand Side Panel on a flat surface. Continue with step 4 of Part 2. 11/1997 KODAK AG, Stuttgart... -
Page 7: Part 2 Ml2000 P From Sn 5032
C O V E R P L A T E S 2 . R e m o v e t h e s e S C R E W S a n d d i s c a r d t h e m figure 1-3 KODAK AG, Stuttgart 11/1997... - Page 8 Connect the 2 small FLAT TAB CONNECTORS to the FAN. (white to -, red to +) figure 1-5 WARNING If the white wire is connected to + and the red wire to -, the FAN does not run. Q3 on PCB A16 will be- come hot and will eventually burn out. 11/1997 KODAK AG, Stuttgart...
- Page 9 H O S E C L A M P P R E S S U R E H O S E C O N N E C T O R A 4 X 3 1 figure 1-6 KODAK AG, Stuttgart 11/1997...
- Page 10 Mount PCB A16. Use 4 SCREWS M4x16 and 4 STANDOFFS. P C B A 1 6 Connect the HUMIDITY SENSOR to the small CONNECTOR M L 2 0 0 0 P H A R N E S S A 4 X 3 1 figure 1-8 11/1997 KODAK AG, Stuttgart...
- Page 11 T h i s s i d e o f t h e T W I N W A T E R V A L V E m u s t b e c l o s e d . Connect the 2 large FLAT TAB CONNECTORS to the outer TWIN WATER VALVE figure 1-9 KODAK AG, Stuttgart 11/1997...
- Page 12 T-ADAPTER and MANUAL VALVE with PIPE THREAD TAPE TL2190 (PN 952960) Connect the other end of the T-ADAPTER to the WATER SUPPLY. NOTE The PRESSURE HOSE for the WATER SUPPLY is not supplied with the HUMIDIFIER KIT. 11/1997 1-10 KODAK AG, Stuttgart...
- Page 13 MANUAL VALVE To avoid leakes, use PIPE THREAD PRESSURE TAPE TL2190 HOSE to SEAL (PN 952960). HUMIDIFIER DETAIL B MANUAL VALVE 1/2 in. 3/8 in. from WATER PROCESSOR SUPPLY WATER IN ADAPTER T-ADAPTER figure 1-10 KODAK AG, Stuttgart 1-11 11/1997...
- Page 14 O V E R F L O W figure 1-11 Fix the self adhesive SEAL to the BASE of the ML2000 P. s e l f a d h e s i v e S E A L figure 1-12 11/1997 1-12 KODAK AG, Stuttgart...
-
Page 15: Final Test
Adjust R5 until the voltage reading is 5 VDC. This is equal to a relative humidity of 50 % RH. If the relative humidity is below 50% the HUMIDIFIER FAN will start. and the WATER RESERVOIR is filled. KODAK AG, Stuttgart 1-13 11/1997... - Page 16 INSTALLATION INSTRUCTIONS HUMIDIFIER ML2000 P II 3477-D figure 1-14 11/1997 1-14 KODAK AG, Stuttgart...
- Page 17 W A T E R L E V E L S E N S O R H U M I D I F I E R O V E R F L O W figure 1-16 KODAK AG, Stuttgart 1-15 11/1997...
- Page 18 CARTRIDGE must be replaced during PMs or a minimum of twice a year NOTE The replacement of the HUMIDIFIER FILTER CARTRIDGE must only be done by SERVICE PERSONAL authorised by KODAK. Open the HUMIDIFIER ACCESS PANEL. Insert slowly the HUMIDIFIER FILTER CARTRIDGE to prevent spilling water inside the ML2000 P and to prevent water from flowing over electrical components.
- Page 19 II 3477-D HUMIDIFIER ML2000 P INSTALLATION INSTRUCTIONS NOTE For installations in Germany do step 17. Place the DVGW LABEL close to the DATA PLATE of the ML2000 P. KODAK AG, Stuttgart 1-17 11/1997...
- Page 20 Kodak AG Hedelfinger Str. 54-60 70327 Stuttgart Germany...
