- Page 1 Master Assembly ORION W1S/T AM 071 AM 071 (Part)
-
Page 2: Table Of Contents
1 PREFACE The following extracts are taken from the Master Assembly Manual for the Orion, to cover the layout of the organ modules, testing, and cable-form wiring. 2 TABLE OF CONTENTS Preface.....................................Error! Bookmark not defined. Table of Contents ..................................Error! Bookmark not defined. FIGURES......................................................3 TABLES ......................................................3 Initial Operation and Adjustments ...................................... -
Page 3: Figures
2.1 FIGURES Figure 1 Layout of the building blocks in the organ top..........................................4 Figure 2 Block diagram of the audio wiring and associated DC controls.......................................5 Figure 3 Schematic layout of the wiring harness GO 1 ........................................13 2.2 TABLES Table 1 Wire List of Harness GO 1 .................................................14 AM 071 (Part) - Page 4 Figure 1 Layout of the building blocks in the organ top AM 071 (Part)
-
Page 5: Initial Operation And Adjustments
Figure 2 Block diagram of the audio wiring and associated DC controls 3 Initial Operation and Adjustments We suppose that power supply, tone generator and electronic keyers have passed the previous tests and are in good working order (see chapter G II). We further assume that the organ is equipped with an operating power amplifier (built-in for W 1 S /external for W 1 T, connected to jack "Output"... -
Page 6: First-Time Power On
( ) Push home all drawbars(including master controls). ( ) Jam a key of each manual in the depressed position. While holding on to the amplifier terminal, touch the terminals "SQ" or "SIN" of the keyer block. Again, ( )Set the "Wah Wah" and "Slalom" controls to their right-hand stops. tones at various pitches should be heard. -
Page 7: Fixed Stop Voices Of The Lower Manual
( ) Clip the test lead to terminal S 4 of the preamp. This activates the drawbars of 3. Horn 8': "Hollow" sound. the upper manual. 4. Violin 4': Same as Viola 8' but pitched one octave higher. ( ) Turn on the switch "Soft Attack" (upper left cheek block). When depressing a key on the upper manual the tone buildup should be slower than before. -
Page 8: Testing Of The Frequency Vibrato
( ) Verify that the pitch of the entire organ varies by an exact octave when the 4.Saxophone16': Rich in harmonics, becoming increasingly "hollow" towards the "Slalom" control is moved from stop to stop. Remark: If you installed a "Slalom" bass end control which is different from the one you tested the tone generator with the of the manual. -
Page 9: Testing Of The Slalom Modes (Autoglide)
We find that the switch "Slow Vibrato" is shown in Fig. 46. The control wire is No. It took us quite a few words to describe this procedure. We hope that you 7 3. The wire list states that the other end of wire No. 73 is connected to the tone understand the fundamental idea behind all trouble-shooting. -
Page 10: Testing Of The Selector Switches "Drawbars/Fixed Stop
( ) Repeat the entire procedure from the beginning of this paragraph Xl for the ( ) Turn the master pitch control (underside of organ top) from stop to stop. The upper manual. overall pitch of the organ should vary by about plus and minus a halftone. ( ) Activate the right-hand foot switch en the swell pedal (W 1 T only: Postpone 3.11 Testing of the Wersivoice this test until the swell pedal is connected). -
Page 11: Testing Of The Swell Pedal And Reverb
( )Turn on the switch "Heavy" (also called "Celeste"). The intensity of the vibrato ( ) Set the treble control P 3 on V V 1 (top) and the bass control P 4 (center) to should increase. the center of rotation. Later on, you may want to re-adjust these controls to match the organ sound to the room acoustics. -
Page 12: Testing Of The Piano, Wersidata Registration Programming And Wersimatic Rhythm/Auto Accompaniment
( ) Push all connectors onto the pedal electronics board P E 13. But, please, tome your haste and spend some time for the final cleanup. Inspect the instrument for loose particles and tools. Use a vacuum cleaner to suck up the ( ) Pull the volume control "Bass guitar"... - Page 13 Figure 3 Schematic layout of the wiring harness GO 1 AM 071 (Part)
- Page 14 The wiring list on the following pages contains the wire numbers, colors and types of wires used in the harness GO 1. Beginning and end of each wire are also identified as to subunit name and terminal designation as far as the wiring of the organ is concerned, we do not make use of this list. It is provided as an aid in trouble-shooting and for future reference.
- Page 15 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 16 W blue Power supply, PS 1, -15V Fixed stops U/M an, G P 1, plug 2, pin -15 Neg. supply voltage 17 W blue Power supply, PS 1, -15V Fixed stops L/Man, G P 1, plug 2, pin - 15...
- Page 16 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 36 W green Programming, P R 1, plug 2, pin 15 Envelope switches, U/Man, US 1, "Soft "Programmed Minus"...
- Page 17 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 54 W black Power suppIy,PS 1,G N D Wah wah control, term.E Ground 55 W black Power suppIy,PS 1, G N D Transposer,TP, point "M"...
- Page 18 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 75 L gray Switches " Reverb '; V S 2, plug 1, pin Tone generator, G 1, plug A, pin 1 Vibrato III 76 L red/blue Switches "...
- Page 19 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 89 W yellow Piano, PI 1, plug 1, pin SPEED Tremolo speed control, term. A 88 and 89 are interchangeable 90 W brown Piano, PI 1, plug 2, pin Ki.
- Page 20 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 108 W red/blue Wersivoice, WV 7, pin 1c Fixed stops L/Man, G P 1, plug 1, pin FR- "Fixed Stops to Wersivoice"...
- Page 21 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 120 S white Wersivoice, WV 7, pin 5 (shield cut off) Volume control Spec. eff.term. S (shield to Audio from Spec.
- Page 22 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 132 W wh/blue Pedal electronics, P E 1 3, plug 5, pin 7 Rocker switch "Stringbass" S 1,term. 3 Control for Stringbass 133 W yel/brn Pedal electronics, P E 1 3, plug 5, pin 8 Rocker switch "Tuba"...
- Page 23 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 148 S black Preamp, V V 2, plug 3,pin E 2 (shield Drawbars L/M an, term. 13 (shield to term. Audio from L/M an cut off) drawbars to preamp...
- Page 24 Wire Material/Color Starts at: Ends at: Purpose, Remarks W = stranded (Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal) wire S = shielded cable 162 S red Spec. eff., E F 1, plug 2, pin 16 (shield Perc. drawbars,term. 9 shield to term. 8 Audio from perc.
- Page 25 1999 Thomas Erlebniswelt Musik This document has been reproduced for the benefit of current owners of WERSI organs. It should not be used for any commercial purposes. AM 071 (Part)
