Summary of Contents for Eltako InWall-10
- Page 1 MANUAL InWall-10...
-
Page 2: Scope Of Supply
The in-wall cut-out dimensions are 215.0 x 305.0 x 78.0 mm. A PoE AC/USB-A power supply adapter is also available as an option. The InWall-10 is an in-wall docking station with a charging function to receive permanently mounted Apple iPad 10.2” or 10.5” devices in portrait or landscape format and equipped with a Lightning connector. -
Page 3: General Information
All connection and installation work must be conducted by certifi ed electricians in compliance with the general rules and directives for electrical installations. The InWall-10 has a smooth and shiny surface which is prone to scratches. Handle with care to avoid damage. We recommend wearing soft cotton wool gloves during installation. - Page 4 MANUAL InWall-10 Preparing the Power Connection - Option 1: High Voltage Connect the AC/USB converter to a 240 V AC power line and put it in the back box of the docking station. This option requires a certifi ed electrician for installation!
- Page 5 MANUAL InWall-10 Installing in a brick wall Before placing the back box in the brick wall, remove the break-out for the cable outlets. Then place the installation protective card in the back box using the fi xing screws. Route the power cable through the grommet in the back box.
-
Page 6: Installation
MANUAL InWall-10 Installing in a cavity wall Installation Before installing the back box in a cavity wall, remove the break-out for To install the iPad, plug the original Apple charging cable to the USB socket the cable outlets. Mount the protective card as a template and place in a of the supplied power supply adapter. - Page 7 Store & charge the iPad High Voltage Power Supply Power Supply 100-240 V AC to USB 5 VDC/3A Recommended Accessory (not included) InWall-10 security-kit (Description on next page) Operating Temperature 0 - 35°C or 32 - 95°F Operating Humidity 20% - 90% Cleaning The product requires no special care, but only a regular cleaning of the glass.
-
Page 8: Electrical Safety Information
Protection against Theft Eltako’ s InWall-10 security kit secures the iPad through a glue-on plate that‘ s connected to a wires rope. However, the InWall-10 security kit does not provide any protection against theft. Unauthorized and/or forceful removal of the iPad cannot be prevented. Eltako GmbH does not accept any liability for the theft of... -
Page 9: Fcc Compliance Statement
WEEE Directive. Declaration of Conformity Hereby the Eltako GmbH declares, that this Eltako GmbH device, is in compliance with the essential requirements and other relevant provisions of Directive 2014/35/EU & 2014/30/EU. - Page 10 InWall-10 Premium iPad In-Wall Docking Station. Made out of high-quality glass and Aluminium. Horizontal or vertical fl ush mounting. vertical Eltako GmbH D-70736 Fellbach Technical Support English: horizontal +49 711 94350025 technical-support@eltako.de eltako.com Must be kept for later use! 02/2021 Subject to change without notice.
