RFS INSTALLATION GUIDELINES
Direct Connection RRH HYBRIFLEX
®
Guidelines and Instructions
HYBRIFLEX
®
CABLE|603400210500|September 2020
Visit
www.rfsworld.com
for the most current product specifications
Page 1 of 43

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYBRIFLEX RRH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RFS HYBRIFLEX RRH

  • Page 1 RFS INSTALLATION GUIDELINES Direct Connection RRH HYBRIFLEX ® Guidelines and Instructions HYBRIFLEX ® CABLE|603400210500|September 2020 Visit www.rfsworld.com for the most current product specifications Page 1 of 43...
  • Page 2: Table Of Contents

    Installation of the Grounding Kit ........................17 Fiber Inspection ............................26 Fiber Cleaning Introduction .......................... 29 Cleaning ODC plug and socket connector ....................34 RFS RRH jumper with FULLAXS COMPATIBLE connector installation guide ..........37 HYBRIFLEX Bulkhead Connector Fitting Installation ..................40 HYBRIFLEX ®...
  • Page 3: Introduction To Hybriflex

    HYBRIFLEX combines optical fiber, power and alarm wire in a single jacketed cable and can connect multiple RRHs with a single feeder. Standard RFS CELLFLEX® coaxial cable accessories may be used with HYBRIFLEX cable. Both pre-terminated and on-site terminated options are available. The rugged jacket facilitates easy transportation, handling, and installation.
  • Page 4: Hybriflex Feeder Configuration

    RFS INSTALLATION GUIDELINES HYBRIFLEX Feeder Configuration This installation guideline supports HYBRIFLEX cable available in small, medium and large riser trunk configurations, 6x12 and 6x24. The trunk cable assemblies comprise of 4, 6 or 10AWG DC wires, and twelve (12) or twenty-four (24) pairs of single mode fiber terminated with ODC-LC connector.
  • Page 5 RFS INSTALLATION GUIDELINES 6x12 / RRH Configuration for demonstration purpose only Breakout point for separate fiber and power conductors Single-Mode Jumper Hoisting grip attached no less without FULLAXS Fiber jumper with ODC than 5 feet from breakout point Compatible Connector...
  • Page 6: Hybrid Riser Kit Model Numbering Structure

    Helpful tip - The following are just a few examples of hybrid riser cables kits for this application. Please check with your local RFS representative for additional product variations and options. Hybrid riser kit model numbering structure HB078-05U6S12-xxM-KIT-01, HB114-13U6S12-xxM-KIT-01, HB158-21U6S12-xxM-KIT-01,...
  • Page 7 RFS INSTALLATION GUIDELINES Quick reference Cable type HB078-05U6S12- HB114-13U6S12- HB158-21U6S12- Cable brand HYBRIFLEX® HYBRIFLEX® HYBRIFLEX® Conductor gauge 10 AWG 6 AWG 4 AWG Number of conductors 6 pairs 6 pairs 6 pairs Number of fibers 12 pairs 12 pairs 12 pairs...
  • Page 8 RFS INSTALLATION GUIDELINES Cable type HB158-21U6S24- Cable brand HYBRIFLEX® Conductor gauge 4 AWG Number of conductors 6 pairs Number of fibers 24 pairs Hybrid armor type Corrugated aluminum Hybrid fiber mode Single-Mode Hybrid termination Top: ODC Bottom: LC Hybrid weight (kg/m (lb/ft)) 3.65 | 2.5...
  • Page 9: Transporting, Shipping And Handling The Drum

    RFS INSTALLATION GUIDELINES Transporting, Shipping and Handling the Drum Drums must be handled carefully to avoid any damage to the drum and/or the hybrid cable. • If the drum will be shipped by van or truck the drum must be secured against rolling. Pay special attention to careful loading and unloading.
  • Page 10: Protective Sleeve Removal/Packing

    RFS INSTALLATION GUIDELINES Protective Sleeve Removal/Packing It is recommended that all assemblies are inspected and pre-tested before hanging, to do so no need to unreel the assembly. Both optical end faces are easily accessible. Use this quick instruction to unwrap and test the fiber.
  • Page 11: Hoisting/Pulling Hybriflex Cable

    RFS INSTALLATION GUIDELINES Hoisting/Pulling HYBRIFLEX Cable • Note: when hoisting and pulling HYBRIFLEX always use caution. • Do not remove the protective sleeve. If it is removed during pre-testing, re-attach securely before hoisting the cable. • Do not attach the hoisting grip over the protective sock.
  • Page 12 RFS INSTALLATION GUIDELINES HYBRIFLEX cable is supplied in specific cut lengths with fully terminated and polished factory connectors. Short lengths of small HYBRIFLEX can be hoisted manually, otherwise a winch is recommended. Provide a pulley high enough on the tower to enable the HYBRIFLEX line to be raised sufficiently.
  • Page 13: Hybriflex Bending

    RFS INSTALLATION GUIDELINES HYBRIFLEX Bending • The minimum-bending radius should be strictly observed. [See product spec sheet]. HYBRIFLEX cable should be bent manually with a force applied in a distributed manner, pressing carefully while the hand slides along the cable [see diagram 1]. Avoid rapid, sharp motions.
  • Page 14 Minimum bend radius is the tightest bend an installer can bend a section of the cable without causing performance degradation and/or damage. Refer to product data sheet for specific hybrid cable bend radius. RFS specifies two types of minimum bending radius for a cable. • Single bend – irreversible minimum bend section of the cable •...
  • Page 15: Fixation/Mounting Of The Cable

    Crush resistance may vary for different outer materials. This should be considered when tightening the clamps (especially if these clamps have not been approved by RFS). Several different clamps may be used, we recommend using the SNAP-IN type. The SNAP-IN is suitable for all fixing situations while at the same time it is a safer clamp (less chance of failure) offering many advantages.
  • Page 16: Hybriflex Tower Accessories And Installation Tools

    Caution! Only use approved accessories and tools. Also note: RFS HYBRIFLEX® does not require the use of grommets. Note: Hangers are sold in kits of 10 with hardware included (three options available)
  • Page 17: Installation Of The Grounding Kit

    Installation of the Grounding Kit RFS recommended that hybrid cable be grounded regardless of size. Recommended 3 Kits per run up to 200ft plus 1 for every additional 200ft. Although the HYBRIFLEX jacket removal tool (HTPT’s series) can be used, to avoid ripping off too much jacket the J-Strip is recommended.
  • Page 18 Please follow the included installation instruction carefully. For removal of the jacket we also strongly recommend the use of a manual jacket stripping tool, examples model JSTRIP-114-2 or JSTRIP-114 for 1-1/4” size. Check with you local RFS representative for other cable sizes. ▪...
  • Page 19 RFS INSTALLATION GUIDELINES Note: If the tool has been started to cut in a spiral, the tool will move continuously by itself in the same direction. If the marked area is reached, this movement must be stopped by pushing carefully in the opposite direction.
  • Page 20 RFS INSTALLATION GUIDELINES 1-1/4 |1-5/8 inch Armor cutting tool instruction The following instructions can be use for 1-5/8” HYBRIFLEX cable. The cutting tool is a special design. An “off the shelf” pipe cutter from local hardware store should not be used. Note: This is not a combo tool;...
  • Page 21 RFS INSTALLATION GUIDELINES tool 7/8 |5/8-inch Armor cutting Instruction The following instructions are designed for use with the 5/8 and 7/8” HYBRIFLEX cable. This is not a combo tool, size must be purchased as either 5/8” or 7/8”. The cutting tool is a special design. An “off the shelf” pipe cutter from a local hardware store should not be used.
  • Page 22 RFS INSTALLATION GUIDELINES Hybriflex Jacket removal tool instruction Part Number Hybriflex size HTPT-1-058 5/8” HTPT-1-078 7/8” HTPT-1-114 1-1/4” HTPT-1-158 1-5/8” HYBRIFLEX ® CABLE|603400210500|September 2020 Visit www.rfsworld.com for the most current product specifications Page 22 of 43...
  • Page 23 RFS INSTALLATION GUIDELINES Hybriflex Armor Removal Ripcord Instruction (Click here for video) HYBRIFLEX ® CABLE|603400210500|September 2020 Visit www.rfsworld.com for the most current product specifications Page 23 of 43...
  • Page 24 RFS INSTALLATION GUIDELINES Armor trimming procedure for HYBRIFLEX™ cable Overview: This cable is constructed with a ripcord, located right under the cable aluminum corrugation. The ripcord is designed to cut through the armor and jacket, to expose the individual fiber and power wires as necessary for the installation.
  • Page 25 RFS INSTALLATION GUIDELINES collar), at minimal speed to slice both jacket and the aluminum armor. The mandrel should be centered on the cable and in contact with the jacket surface (see Figure 7). 8. After the ripcord reaches the stop collar, remove the ripcord from the mandrel by running the drill in reverse.
  • Page 26: Fiber Inspection

    RFS INSTALLATION GUIDELINES Fiber Inspection Optical Interface Connectors In addition to the LC and ODC connectors on the main trunk, jumpers with ODC plug and socket connectors attach the RRH to the main trunk. Tools and test equipment Use ONLY approved test equipment recommended by the mobile network operator.
  • Page 27 RFS INSTALLATION GUIDELINES Fiber interface zones, per IEC Template 613000-3-3 (for single-mode fiber) A. Critical zone B. Cladding zone C. Adhesive zone D. Contact zone Zone Description Diameter Allowable defect Allowable size diameter scratches Core zone 25μm None @200x None @200x Cladding 25-120μm...
  • Page 28 RFS INSTALLATION GUIDELINES LC connector inspection 1. Inspect the LC fiber end-face using approved test equipment probe and the appropriate LC fiber tips. If the test fails due to too much debris, clean end-face accordingly and retest. LC end-face inspection...
  • Page 29: Fiber Cleaning Introduction

    RFS INSTALLATION GUIDELINES Fiber Cleaning Introduction Warning: Before attempting to clean or inspect fiber optics it is strongly recommended that the technician have a good understanding of the IEC 61300-3-35 fiber optics standard procedure. This document can be obtained simply by performing an internet search for IEC 61300-3-35.
  • Page 30 RFS INSTALLATION GUIDELINES • Always keep a protective cap on unplugged fiber connectors. • Always store unused protective caps in a re-sealable container to prevent the possibility of the transfer of dust to the fiber. Locate the containers near the connectors for easy access.
  • Page 31 RFS INSTALLATION GUIDELINES Inspect the connector. 6. If the connector is still dirty, clean it with a wet cleaning technique followed immediately with a dry clean to ensure no residue is left on the end-face. Note: Wet cleaning is not recommended for bulkheads and receptacles. Damage to equipment can occur.
  • Page 32 RFS INSTALLATION GUIDELINES • For manual advance cleaners, pull on the cleaning material from the bottom of the device until a new strip appears in the cleaning window, and then go to step 5. 5. Hold the Ferrule tip lightly against the cleaning area and rotate one quarter turn.
  • Page 33 RFS INSTALLATION GUIDELINES Caution: Improper cleaning can cause damage to the equipment. The primary concern with the use of isopropyl alcohol is the ability to remove any residue completely from the connector or adapter. Residual liquid alcohol acts as a transport mechanism for loose dirt on the end face. If the alcohol is allowed to evaporate slowly off the ferrule, it can leave residual material on the cladding and fiber core.
  • Page 34: Cleaning Odc Plug And Socket Connector

    RFS INSTALLATION GUIDELINES Cleaning ODC plug and socket connector If the ODC plug or socket end-face shows any particles or debris, clean the end-face using the following 1.25mm one click type cleaner or swab stick. Swab stick One-click type cleaner...
  • Page 35 RFS INSTALLATION GUIDELINES Mobile operator specific optical testing Note: OTDR unidirectional measurements lead to inaccuracies when fibers with different Mode Field Diameters (MFD) are connected. The inaccuracies usually are in the form of “gainers” or “exaggerated losses”. At MFD mismatched connection OTDR backscattered light is greater or smaller, depending on the direction.
  • Page 36 Note: When using OTDR, the longer the loopback the better Loopback the test result. RFS recommends a loopback of 30m (min) be recommenm used. Lookback modules may be used with power meters but not recommended for OTDR.
  • Page 37: Rfs Rrh Jumper With Fullaxs Compatible Connector Installation Guide

    RFS INSTALLATION GUIDELINES RFS RRH jumper with FullAXS compatible connector installation guide Use the following instruction to properly install/attach the FullAXS compatible connector. Failure to follow these procedures entirely may cause damage to the Fiber or Connector. For factory pre-installed assembly, skip to step 4a: Carefully feed compression nut over fiber jumper connector and slide onto jacketing.
  • Page 38 RFS INSTALLATION GUIDELINES Engage the compression nut thread to the body 3-4 revolutions to keep the grommet in place but do not tighten fully to allow for adjustment during RRU connection. a) Remove protective dust cap (top), disengage the compression nut (bottom), adjust the jumper to proper length Slide FullAXS compatible gland body down jacketing to allow access to the fiber end connector.
  • Page 39 RFS INSTALLATION GUIDELINES Heat Shrink exposed Finish threading the compression nut to complete the installation. Thread compression nut until it bottoms out (no gap) with the extended (front) inner body. No gap Reverse steps 6 to 1 to remove sleeve for maintenance. Note: Once the Nut is tight, spring fingers are compressed tightly.
  • Page 40: Hybriflex Bulkhead Connector Fitting Installation

    RFS INSTALLATION GUIDELINES HYBRIFLEX Bulkhead Connector Fitting Installation The bulkhead fitting kit is designed to be used with HYBRIFLEX cable, to secure the riser trunk line to the equipment cabinet. No additional boot is required. The bulkhead fitting forms a mechanical and water- tight connection providing ground continuity (for metal types) between the cable’s armor and the metal...
  • Page 41 1. Remove the connector from the package and inspect it to ensure there are no missing pieces or damage. DO NOT DISASSEMBLE OR TIGHTEN THREAD (Figure 1). 2. Prep the cable by removing 2.6 inches of the jacket using RFS jacket stripping tool or knife to expose the aluminum outer armor (Figure 8).
  • Page 42 RFS INSTALLATION GUIDELINES Figure 8 Figure 9 Figure 10 Figure 11 (Plastic fitting) (Metal fitting) HYBRIFLEX ® CABLE|603400210500|September 2020 Visit www.rfsworld.com for the most current product specifications Page 42 of 43...
  • Page 43 RFS INSTALLATION GUIDELINES Trademarks RFS®, CELLFLEX® and HYBRIFLEX® are registered trademarks of Radio Frequency Systems. Document Control Document Number: 603400210500 Completed Approved Release Date ECO # Comments/Changes E. Redvil M. Gauvin 02 Aug 19 RFS19323 Released version M. Gauvin M. Gauvin...
