  • Page 1 MINI-TEC Chargeur de Batterie Automatique 12 V/10 A - 24 V/05 A Automatic Battery Charger 12 V/10 A - 24 V/05 A MANUEL D'UTILISATION USER MANUAL...
  • Page 2 1 . 1 GARANTIE 2 ANS 1 . 2 RESPECT DES NORMES 1 . 3 PRÉCAUTIONS D'UTILISATION 1 . 4 ……………………………………………………………………………………………………………………… PRÉSENTATION DU MINI-TEC DESCRIPTION DE L'APPAREIL 2 . 1 CARACTÉRISTIQUES TECHNIQUES 2 . 2 ………………………………………………………………………………………………………………………………………… INSTALLATION MISE EN PLACE 3 .
  • Page 3: Garantie 2 Ans

    électriques, l'informatique industrielle... GARANTIE 2 ANS La garantie de cet appareil est de deux ans, pièces et main d'œuvre comprises, retourné chez TECSUP sous la responsabilité et aux frais de l'utilisateur. Seuls les éléments d'origine reconnus défectueux seront remplacés.
  • Page 4: Précautions D'utilisation

    Mini-Tec 80300073-A RESPECT DES NORMES Le marquage CE présuppose une stricte conformité des produits aux exigences imposées par les normes européennes de compatibilité électromagnétique CEM et de la sécurité des utilisateurs. Les normes CEM (EN61000-6-3: 2001, EN61000-6-1: 2001 et EN55022-classe A) imposent des valeurs limites de perturbations émises et une immunité aux pertur- bations subies.
  • Page 5: Descriptif De L'appareil

    80300073-A PRÉSENTATION du MINI-TEC DESCRIPTIF DE L'APPAREIL La gamme MINI-TEC fait appel au meilleur des technologies en vigueur. La conversion d'énergie haute fréquence, dite "à découpage", est synonyme : - de chargeurs légers et peu encombrants - d'une qualité de charge invariable, quelles que soient les perturbations de l'alimentation d'entrée (secteur, groupe électrogène) La régulation électronique des sorties permet de respecter fidèlement les paramétres de charge préconisés par les fabricants de batterie.
  • Page 6: Caractéristiques Techniques

    Mini-Tec 80300073-A CARACTÉRISTIQUES TECHNIQUES CAPACITÉ EN Ah. • Boîtier en aluminium extrudé et anodisé ; flasques en aluminium, peinture époxy • Tension d'entrée secteur universelle, c'est-à-dire que le chargeur peut fonctionner COURANT à partir de n'importe quelle tension comprise entre 100 et 245 VAC.
  • Page 7: Installation

    Mini-Tec 80300073-A INSTALLATION ATTENTION : pour des raisons de sécurité et de garantie, il est formellement interdit d'intervenir à l'intérieur du chargeur. De plus, il est impératif de brancher le chargeur au secteur après la connexion des batteries. Risques d’étincelles.
  • Page 8 - Le chargeur doit être impérativement branché sur une ligne protégée en tête par un disjoncteur bipolaire différentiel de 30 mA - Pour toute zone géographique à risque élevé de foudre, il est préférable d’installer un sur-tenseur anti-foudre en amont du chargeur ATTENTION : les dégâts occasionnés par la foudre ne sont pas couverts par la garantie TECSUP. AFFICHAGE La led bicolore implantée en face inférieure indique l’état de charge de l’appareil.
  • Page 9 1 . 1 TWO YEARS WARRANTY 1 . 2 STANDARDS REFERENCES 1 . 3 PRECAUTIONS 1 . 4 ……………………………………………………………………………………………………………… INTRODUCTION OF THE MINI-TEC OPERATIONAL DESCRIPTION 2 . 1 TECHNICAL CHARACTERISTICS 2 . 2 ………………………………………………………………………………………………………………………………………… INSTALLATION MOUNTING OPTIONS 3 . 1 CONNECTIONS 3 .
  • Page 10: Two Years Warranty

    The following items will not be covered under the terms of the warranty: packaging and transportation costs, damage sustained during transportation,either apparent or concealed. In case of misuse or damage during installation, the constructor’s warranty will not apply and the responsibility of TECSUP will be disclaimed in the concerned matter.
  • Page 11 Mini-Tec 80300073-A STANDARDS REFERENCES EC marking pre-supposes a strict conformity of the product supplied as to the demands imposed by the European standard on electromagnetic compatibility EMC and user’s safety. Theses EMC standards (EN 61000-6-3: 2001, EN 61000-6-1: 2001 and EN 55022-class A) place limitations on the level of interference emitted and immunity to interference received.
  • Page 12: Operational Description

    INTRODUCTION OF THE MINI-TEC OPERATIONAL DESCRIPTION All the MINI-TEC models are state of the art and incorporate the best technologies available to date. High frequency power conversion, commonly called switch mode technology gives the following advantages: - small, lightweight battery chargers - consistent power delivery to the battery regardless of any fluctuations of input voltage (mains or generator) Electronic Control of the outputs allows a strict adherence to the charging curves that are specified by various battery manufacturers.
  • Page 13: Technical Characteristics

    Mini-Tec 80300073-A TECHNICAL CHARACTERISTICS CAPACITÉ EN Ah. • Extruded aluminium casing, anodised for corrosion resistance. Aluminium end plates coated with epoxy paint COURANT • switch mode technology • Universal input voltage, that means the charger can operate from any input...
  • Page 14: Mounting Options

    Mini-Tec 80300073-A INSTALLATION CAUTION : For personal safety reasons and preservation of warranty, it is strictly forbidden to open the charger; mains power must only be supplied to the charger after connection to the battery to avoid risk of electric shock.
  • Page 15: Led Display

    - In geographic zones exposed to a high risk of lightning strikes, it may be recommended to fit a lightning protection to the inlet side of the charger CAUTION : Damage caused by lightning strike or power surges are not covered by TECSUP warranty.
