Quincy lab 160 Series Operating Manual

Quincy Lab, Inc.

Specifications

Overall Dimensions
INCHES W x H x D
Working Area
Weight (lbs)
Standard Electrical*
* Working Max Operating
Temperature Range (F)
* Measured with workpiece in place - (varies with piece size and length).
Common Unit Construction
Exterior: Powder-Coated Steel
Power Controls: On/Off Toggle & Power Light
Safety Precautions
Read Operating Instructions thoroughly prior to operation. Use only a grounded outlet that is rated for
your models' electrical requirement. Conduct periodic maintenance as required.
EXPOSED ELEMENT - Operate unit well away from flammable solvents, gasses and materials.
Operate on non-combustible surface only.
Receiving
After unpacking, verify receipt of correct quantities of each component and that each component has
not suffered any shipping damage.
Damaged/Missing Item Report.
Issue Rev A 0908
Copyright Quincy Lab Inc. 2008
MODEL
03-160
15.125x5.5x7.25
38.45x14x18.4
(CM) W x H x D
12"
7 lbs
SHIPPING
6 lbs
STAND ALONE
115 / 125
VOLTS / WATTS
1.08
AMPS
Read Operating Instructions Thoroughly Prior to Operation
Quincy Lab Inc. 1925 N. Leamington Ave.
Plastic Forming Strip Heaters
OPERATING MANUAL
MODEL
03-160
SHOWN
MODEL
13-160
25x5.5x7.25
63.5x14x18.4
21"
9 lbs
7 3/4 lbs
115 / 200
1.72
Plug/Cord Assy: UL SJOW 18/3
Heater: Resistive-Tubular Incoloy
If there are any problems, please refer to the enclosed
Chicago, Illinois 60639 1-800-482-HEAT (4328)
Model Series 160
CAUTION HOT SURFACES
AND EXPOSED ELEMENT
MODEL
23-160
36x5.5x7.25
91.4x14x18.4
33"
12 lbs
10 1/2 lbs
115 / 350
3.02
CAUTION:
PAGE 1
