Posted on May 27, 2021
ReX is a range extender of communication signals that expands the radio
communication range of Ajax devices fitted with a hub up to 2-fold. Developed
only for indoor use. It has a built-in tamper resistance and is equipped with a
battery that provides up to 35 hours of operation without external power.
The extender is compatible only with the
! Connection to
and
is not provided.
The device is configured via the
for iOS and Android
smartphones. Push-notifications, SMS messages and calls (if enabled) notify
ReX user about all events.
The Ajax security system can be used for independent monitoring of the site and
can be connected to the Central Monitoring Station of the security company.
Advertisement
Related Manuals for AJAX Systems ReX
Summary of Contents for AJAX Systems ReX
- Page 1 Posted on May 27, 2021 ReX is a range extender of communication signals that expands the radio communication range of Ajax devices fitted with a hub up to 2-fold. Developed only for indoor use. It has a built-in tamper resistance and is equipped with a battery that provides up to 35 hours of operation without external power.
- Page 2 1. Logo with light indicator 2. SmartBracket attachment panel (perforated section is necessary to trigger the tamper during an attempt to lift the fixed ReX from the surface) 3. Power connector 4. QR-code 5. Tamper button 6. Power button ReX expands the radio communication range of the security system allowing installation of Ajax devices at a greater distance away from the hub.
- Page 3 5 ReX Connecting multiple ReX to the hub is supported by devices with OS Malevich 2.8 and later. At the same time, ReX can only be connected directly to the hub and connecting one range extender to another is not supported.
- Page 4 5. Ensure that the hub is disarmed and is not updating by checking its status in the mobile application. 6. Connect ReX to external power. Only users with administrator rights can add a device to the hub. 1. Click Add Device in the Ajax application.
- Page 5 In order for detection and interfacing to occur, ReX must be located within radio communication range of the hub (on the same guarded facility). The request for connection to the hub is transmitted for a short time at the time of switching on the device.
- Page 6 Wings radio protocol. A device can only be paired with one ReX. When a device is assigned to a range extender it is automatically disconnected from another connected range extender.
- Page 7 Shows the status of the device: active, completely disabled by the user, or only Temporary Deactivation notifications about triggering of the device tamper button are disabled Firmware ReX firmware version Device ID Identifier of the device 1. Devices 2. ReX 3. Settings...
- Page 8 Opening ReX User Manual Disconnecting the extender from the hub and Unpair device deleting its settings The ReX LED indicator may light red or white depending on the state of the device. Event State of logo with LED indicator Device is connected to the hub...
- Page 9 The functionality testing of the associated to ReX devices will be added to the next updates of OS Malevich. The Ajax security system allows conducting tests for checking the functionality of connected devices. The tests do not start straight away but within a period of 36 seconds when using the standard settings.
- Page 10 Take whatever action is necessary to improve the quality of the signal! At the very least, move ReX or hub — relocation even by 20 cm can significantly improve the reception quality.
- Page 11 It is strictly forbidden to disassemble the device connected to the power supply! Do not use the device with a damaged power cable. Do not disassemble or modify ReX or its individual parts — this may interfere with the normal operation of the device or lead to its failure.
- Page 12 Up to 1,800 m (any obstacles absence) Installation method Indoors Operating temperature range From -10°С to +40°С Operating humidity Up to 75% Overall dimensions 163 × 163 × 36 mm Weight 330 g Service life 10 years 1. ReX 2. SmartBracket mounting panel...
- Page 13 COMPANY products is valid for 2 years after the purchase and does not apply to the pre-installed accumulator. If the device does not work correctly, contact the support service first — technical issues can be resolved remotely in half of the cases! Technical support:...
