CRUISING ELECTRONICS SD9X Instructions

Please read these instructions in full before operation

Thank you for purchasing this Megaphone from Cruising Electronics.

This unit is not waterproof!

The unit can be operated using 6 internal D cells or the supplied cable with cigar lighter plug
D CELLS Use good quality, eg Duracell. Do not use Eclipse (Jaycar), they are oversize in diameter
Re-chargeable batteries have lower voltage, and the unit may not work correctly with them installed
When installing any batteries, first ensure that no operation buttons are depressed.
To open the battery compartment, press the button on the rear underside above the handgrip, grip
the rear panel on either side, and lift the hinged rear panel upwards. See the illustration below.
BATTERY CABLE OPERATION Use only on a 12 volt system. Severe damage will be caused
if it is used on 24 volt. The cable can be used whether or not internal batteries are installed.
The internal batteries will not be charged. Insert the small plug into the DC 12V socket on the top
of the Megaphone. Insert the cigar lighter plug into the socket in your motor vehicle.
OFF/ON button, with no other buttons depressed, acts the same as the TRIGGER, engaging the
megaphone function.
Alarm can then be used by depressing the ALARM button.
If feedback (howling) is experienced during speaking, reduce the VOLUME slider control a little.
Speak very close, at the correct angle and with good volume into the microphone.
ALARM Initiates a fixed alarm sound, volume adjustable with the VOLUME slider.

RECORD

THE RECORD FUNCTION IS DISABLED ON THIS MODEL

PLAYBACK

THE PLAYBACK FUNCTION IS DISABLED ON THIS MODEL
For a period of 12 months from date of purchase Cruising Electronics will either repair,
replace or refund, should any defect arise resulting from faulty manufacture.
The Warranty does not cover failure or damage caused by improper storage,
misuse, exposure to liquids or other harmful substances, or any consequential
damage or loss whatsoever.
The purchaser is responsible for the cost and security of returning the faulty unit to
Cruising Electronics. Cruising Electronics will pay for return carriage within NZ
PLEASE NOTE

WARRANTY

Do not clean with solvents!
Battery Holder
Release Button
CRUISING ELECTRONICS
17 MOREY ROAD CABLE BAY
NORTHLAND 0420
Tel. 09 4062020 or 027 255 2852
don@cruisingelectronics.co.nz
www.cruisingelectronics.co.nz
Battery
Insertion
NEW ZEALAND
