Summary of Contents for Clarion NP509
- Page 1 Installation manual Manuel d’installation Guía de Instalación NP509...
- Page 2 Once you’re registered, we can keep you informed of important product information. Register at www.clarion.com - it’s easy to keep your Clarion product up to date. INFORMATIONS DE L’ENREGISTREMENT DE PRODUITS CLARION Pour les Étas Unis et le Canada seulement www.clarion.com...
-
Page 3: Table Of Contents
Thank you for purchasing the Clarion NP509. • Please read this manual thoroughly before operating this equipment. • After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). • Check the contents of the enclosed warranty card and keep it carefully with this manual. -
Page 4: Installation And Wire Connection Manual
• Do not install this unit in a place exposed to direct sunlight, heat or a place where the Car battery vent holes or heat radiation holes are covered. NP509... - Page 5 • After wiring cables, fix them with insulation tape. • Be sure to switch off the vehicle when connecting or disconnecting cords to/from the unit, otherwise an electric shock, injury or accident may occur. NP509...
-
Page 6: Package Contents
SD card. You can import the location database of Safety Camera stored in SD card to the internal memory. 3. USB port Use this port to import updated map data when it is available in the future via a USB memory stick. NP509... -
Page 7: Installing The Navigation Unit
• Do not wax or paint the cover of the GPS antenna. This may reduce the performance of the GPS antenna. • Install the GPS antenna at least 10 cm away from the windshield. • Wipe off the dirt of the mounting surface before installing the GPS antenna. NP509... - Page 8 3. Wire the GPS antenna cord. Fasten the cord using the cord holders. Stick it on a horizontal place of the dashboard towards the center of the road. GPS antenna Cord holder (Shows an example in case of the left-hand traffic.) NP509...
-
Page 9: Wire Connection
Ground Connect to a metal part of the vehicle to connect ground. No connection Fuse Yellow Main power supply Connect to the +12V power supply where power source is always supplied. NP509 VZ509 3 GPS antenna 4 System cable NP509... - Page 10 Connect to a metal part of the vehicle to connect ground. +12V Accessory Fuse Yellow Main power supply Connect to the +12V power supply where power source is always supplied. NP509 3 GPS antenna 2-ZONE POWER TILT SOUND SOURCE OPEN –...
- Page 11 Clarion Co., Ltd. All Rights Reserved.Copyright © 2009: Clarion Co., Ltd. QY-5012B Printed in China / Imprimé en Chine / Impreso en China 2009/1...
