Aqua Creek Products F-806SLS Manual

Scout sling attachment

9889 Garrymore Ln

Missoula, MT 59808

888-687-3552 | +1-406-549-0769

www.aquacreek.com

Check entire box and all packing materials for parts. Before beginning assembly, read the

instructions and identify parts using the ﬁ gures and parts listed in this document.

It is critical that all parts be carefully inspected prior to installation. If any damage occurred in

transit, Aqua Creek Products, LLC must be notiﬁ ed within three days of receipt of unit.

Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's

warranty and may affect the safety of the user.

375 LB. [170 kg] MAXIMUM WEIGHT CAPACITY

LEAVE THIS MANUAL WITH LIFT OWNER

Lift safety can only be ensured if installed and operated

• NEVER permit children to play on or around the lift

• Do not allow children to use the lift without adult

supervision

• NEVER apply direct water pressure to the electronics

• NEVER use the lift with a dry pool

READ CAREFULLY

Scout Sling

Attachment

PART #: F-806SLS

MAXIMUM SETBACK: 28"

MANDATORY

Read and follow all instructions.

according to these instructions.

ADA COMPLIANT

Revised 12/13/16

Table of Contents

Need help?

Do you have a question about the F-806SLS and is the answer not in the manual?

Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notiﬁ ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user.
Page 2 F-030EZHB HANGER BAR F-032EZSB STANDARD SLING ASSEMBLY F-031EZCH STANDARD CHAIN SET QUICK LINK, 9/32” QUICK LINK, 9/32”, SS QUICK LINK, 3/8” QUICK LINK, 3/8”, SS F-QAB BOLT, QUICK ATTACH Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
Page 3 Attach the sling seat assembly to the lift by connecting the two (2) quick-attach bolts and knobs to the lifting arm and the control arm of the Scout lift. See the diagram below. CONTROL ARM LIFTING ARM QUICK-ATTACH BOLTS (2) QUICK-ATTACH SCOUT LIFT KNOB (2) SLING SEAT ASSEMBLY Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
