Summary of Contents for Schäfer SPULBOY NU
- Page 1 OPERATION MANUAL LINE ® UNIQUE! SPÜLBOY NU ® 100% HYGIENIC SPÜLBOY NU water+ ® CLEAN GLASSES Schäfer Produkte GmbH Simonshöfchen 53 42327 Wuppertal /Germany Phone: +49 (0) 202 695 32-0 E-Mail: info@spuelboy.de www.spuelboy.de...
- Page 2 Purpose Your NU water+ glasswasher ® ® consists of the following parts: • 1 x Unit incl. pre-wash and rinsing system • 1 x Bayonet middle brush with head • 1 x Brush strip • 1 x Overflow pipe • 1 x Water connection hose incl.
-
Page 3: Device Components
Device components brush head bayonet middle brush brush strip overflow pipe 2 step head valve upper glass protection connection hose easy clix with ® 3/8˝ thread suction feet Dimensions W/H/D: 39.7 x 33.7 x 27cm & Weight Canister Ø: 17cm - 20cm (oval) Internal glass height: 26cm Weight: 3kg (net) -
Page 4: Spare Parts And Accessories
Spare parts & accessories Art.- name Art.- no................................... brush head, standard 1700370 ® brush head, big 1700372 ® ..................................bayonet middle brush with head, standard 1700360 ® bayonet middle brush, XL with big head 1700362 ® ..................................brush strip, standard 1700350 ®... - Page 5 Setup & assembly Attach the enclosed connection hose to the device. Please make sure that the sealing ring is lodged in thedesignated groove on the unit side to avoid leaks. CLIX Set the safety slide to OFF, attach the connector to the connection nozzle and ®...
-
Page 6: How To Install
How to install? connect the device to the main water supply (3/8” or likewise) easy clix ® 3/8” waste water regulate the water pressure between 2 to max. 4 bar fresh rinse water check the system fill in fresh water •... -
Page 7: First Commissioning
First commissioning push check and keep the cleanliness of the device and the work environment fill the pre-sink with fresh water; the NU water+ ® push button fresh place an original water SPÜLBOY tab into ® the pre-washing canister renew the NU tab, ®... - Page 8 How to clean a glass? move the glass with steady up and down movements completely over the brush, at least 3-4 times don‘t twist! let the glass drain off briefly over the pre-washing canister Step 1 Step 2 push down the 2 stage valve for at least 2-3 seconds;...
- Page 9 How to clean SPÜLBOY ® End of the day: take off the brushes hours and place them with brush sanitizer ® into a bucket /sink fill up the sink with warm water and wait for appr. 12 hours wipe off the device thoroughly with a clean sponge In the morning:...
- Page 10 Attention! In case of glass damage: stop the rinsing process immediately take the device off the water pressure let the water drain out of the pre-washing canister take off the brushes carefully and rinse them clean carefully remove all broken glas place the brushes back into the device check the system...
-
Page 11: Safety Instructions
Safety instructions! • Continuously check the visual cleanliness of the NU / NU water+. ® ® • Check the connection hose and hose connections for damage or leaks. • Clean the glasswasher at a maximum temperature of 70 °C in a dishwasher. •... -
Page 12: Warranty
Warranty ® The original SPÜLBOY warranty Schäfer Produkte GmbH offers you a manufacturers warranty of 2 years from the date of purchase. We remedie all defects free of charge during this period, which are proven to be due to faulty material or workmanship and substantially impair its function. - Page 13 Sustainability & disposal We are responsible • certified according to DIN 6653-3 for manual glasswashers • Company certification according to DIN EN ISO 9001: 2015 • 100% hygiene without power consumption • 100% cleanliness with the lowest fresh water consumption: Ø 8cl per glass cleaning •...
