Summary of Contents for REDEKOP SCU
- Page 2 1 Seed Control Unit - General Information General Information 2 Seed Control Unit - Operation Combine Sieve Accessability / Road Transportation Operation Modes (Chop only / Chop and SCU / Windrow - Case IH) SCU Drive Engagement Combine Loss Checking Windrow Operation (John Deere)
- Page 3 This is to be kept in mind when reading this manual. - If you do not understand the information in this manual, or if you have questions, contact Redekop Customer Service.
- Page 4 0.3 Understand Signal Words 0.3.1 A signal word - DANGER, WARNING, or CAUTION - is used with the safety-alert symbol. DANGER identifies the most serious hazards. WARNING or CAUTION safety signs are located near specific hazards or precautionary areas in this manual. 0.4 Follow Safety Instructions 0.4.1 Carefully read all safety messages in this manual and on your machine.
- Page 7 0.12 Avoid High-Pressure Fluids 0.12.1 Inspect hydraulic hoses periodically - at least once per year - for leakage, kinking, cuts, cracks, abrasion, blisters, corrosion, exposed wire brand or any other signs of wear or damage. Replace worn or damaged hose assemblies immediately. Escaping fluid under pressure can penetrate the skin causing serious injury.
- Page 9 0.18 Fire Extinguisher 0.18.1 A 6 kg (15 lb) general-purpose fire extinguisher meeting national certification requirements must be installed on left side of operator’s platform. Maintain fire extinguisher to keep it in operating condition. Make sure that the fire extinguisher is always ready for use. Refer to the fire extingisher’s manual for instructions on how to operate it. Once extinguisher is operated - no matter how long - it must be recharged. Keep the engine clean and free of dust, chaff and straw to prevent the possibility of fire. 0.19 Remove Accumulated Crop Debris 0.19.1 The build up of chaff and crop debris in the engine compartment, on the engine, and near moving parts is a fire hazard. Check and clean these areas...
- Page 10 0.21 Safety Decals Pictorial Safety Signs At several important places on this machine, safety signs are affixed intending to signify potential danger. The hazard in identified by a pictorial in a warning triangel. An adjacent pictorial provides information on how to avoid personal injury. These safety signs and a brief explanatory text follow. Hand Injury / Rotate Danger RP1089 Risk of injury caused by rotating parts.
- Page 11 Keep Hands out of Belt Area / Rotate Danger RP874 Do not touch any moving parts. Wait until all moving parts have stopped Kickback Hazard / Stand Clear RP1086 Avoid personal injury. Kickback hazard when removing access panel. Caution / Hearing Protection Required RP1090 Use hearing protection whenever operating the machine.
- Page 59 Check oil is circulating - check suction strainer screen at pump inlet. Check that correct oil has been used - Synthetic 75W90 GL4/5 Check that coolers are clean. If static buildup, add static discharge chain to SCU. 5.5 Can the stator rings be reused? The stators are designed to wear on only one side for each rotor - left or right.
- Page 61 All warranty claims must be submitted with photographs of problem, photo of serial #, photo of monitor hour meter, photo of monitor service history. Warranty not provided when foreign object enters SCU and seizes or damages unit. Warranty not provided on items due to wear...
- Page 62 445mm Dia. SC253CK Kit Blade Fan SCU - includes: - SC252LC & SC252RC (x4) - SC253LC & SC253RC (x4) - SC204LC & SC204RC (x4) SC174K Kit Bushing Blade SCU (32) - includes: - SC163-01 (16) - SC165H (16) RP1017K Kit Scraper SCU Rotor Top (8) SC151A Shaft Driveline SCU (MY21 and earlier)
- Page 63 7 STANDARD WEAR REPLACEMENT PARTS BE2C103K VBelt 2C 103L Kevlar - JD OEM FC, JD MAV FC - SCU BE2C112K VBelt 2C 112L Kevlar - JD OEM FC - Slow Chopper BE4M107K VBelt 4M 107L Kevlar - JD OEM XFC - SCU...
