Marlow - 2 Drawer 2 Door Robe
Assembly Instructions -
Dimensions
Width - 91.1cm
Depth - 49.5cm
Height - 191.8cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
427/7712
426/6455
424/5256
MADE IN
BRITAIN
Issue 1 - 05/06/15
Advertisement
Related Manuals for Marlow 427/7712
Summary of Contents for Marlow 427/7712
- Page 1 Marlow - 2 Drawer 2 Door Robe Assembly Instructions - 427/7712 Please keep for future reference 426/6455 424/5256 Dimensions Width - 91.1cm Depth - 49.5cm MADE IN Height - 191.8cm BRITAIN Important - Please read these instructions fully before starting assembly...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 61kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below 5 Base Rail (DF3628) (79.7 x 7.8cm) 3 Top (DF3625) (91.1 x 49.5cm) 6 Large Rail (DF3742)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the 2 drawer fronts Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Fit 2 legs to the left side Screw 2 legs to the left side using 18 screws Note: The top of the legs must be flush with the top of the left side. Step 9 Fit 2 legs to the right side Screw 2 legs to the...
- Page 8 Assembly Instructions Step 10 Prepare the left side Place 2 runners the left side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 9 Assembly Instructions Step 11 Prepare the right side Place 2 runners the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 10 Assembly Instructions Step 12 Prepare the horizontal Insert 4 large locking nuts into the horizontal Note: The arrow on the Finished locking nut must point front edge towards the hole in the edge of the panel. Tap 4 wooden dowels into the horizontal Step 13 Fit the horizontal to...
- Page 11 Assembly Instructions Step 15 Fit the base rail Push the base rail onto the right side Use a screwdriver to tighten the large locking fitted to the base rail Finished front edge Step 16 Prepare the large rails Insert 2 large locking nuts into each of the 2 large rails...
- Page 12 Assembly Instructions Step 18 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 5 large locking nuts fitted to the horizontal , the base rail and the 2 large rails Step 19 Fit the top Attach the top to the...
- Page 13 Assembly Instructions Step 20 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 14 Assembly Instructions Step 22 Fit the drawers Starting with the bottom drawer, slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners Working from the inside of the drawer, insert 2 screws...
- Page 15 Assembly Instructions Step 24 Fit doors and handles Note: The easiest way to attach the left door and right door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the...
- Page 16 Assembly Instructions Step 25 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 17 Assembly Instructions Step 26 Screw Fit the overbalance Washer protector Wall fixing Strap (not supplied) Strap To prevent possible Washer overbalancing we recommend that this unit Screw is secured to a suitable (not supplied) wall by fitting of the overbalance protector kit to the unit, or an alternative fixing method of your choice.
- Page 20 ALR3185...
