Summary of Contents for Denso TEN FT0091A
- Page 1 FT0091A Operating Manual OEM Part No. 39100-T Supplier Part No. 139000- TEN Confidential...
- Page 2 Switch Information Switch Switch name Time BEEP Function Type DAY / NIGHT Brightness setting Hard DAY(100%) Night(50%) OFF Button POWER Audio Power ON (At the time of Audio Power OFF) Below 0.8sec Audio Power OFF PUSH Hard (At the time of Audio Power ON) Button Volume control (rotary) TURN...
- Page 3 SOURCE Touch Change of AUDIO source Switch Audio Touch Change to AUDIO screen Switch App List Touch Change to a list of application screen Switch Rating 1.Rated Voltage 12V (10.5~16.0V) - GROUND 2.Rated Current 5.0A Max (+B=13.2V, 1W output) 3.Backup Current 6.5mA Max 4.Load Impedance ×4ch...
- Page 4 TEN CONFIDENTIAL...
- Page 5 Illumination button AUDIO Mode NAVI Mode (NON operating) Setting Mode HOME HOME Home button : Back to the HOME screen MENU MENU Menu button : Open the MENU screen BACK Back button : Back to previous screen AUDIO Power Rotary encoder: Left or right Vol adjustment Pressing AUDIO Power ON/OFF...
- Page 6 Other FCC ID BABFT0091A FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Co-location: This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
- Page 7 IC No 2024B-FT0091A High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. Les radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu'ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz, et ces radars pourraient causer...
