Giovenzana FCR Instruction Manual

Strawinskylaan 1105
1077 XX Amsterdam, The Netherlands
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Cam switch technical data . . . . . . . . . . . . . . . . . . . . . . . . 2
Certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Main components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Overall dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ROD POSITIONING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation dimensions and rods calibration . . . . . . . . . 7
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
VERSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cam switch operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
MT-FCR-EN / 10 .06 .2021
FCR
POSITION LIMIT SWITCH
Before use, read this booklet carefully to
acquaint yourself with the features of the
product . This booklet is an integral part of
the product and therefore must be kept until
the product is dismissed .
Giovenzana International B .V . reserves the
right to change the features and data shown
in this document at any time and without
notice . This document cannot therefore be
considered a contract with third parties .
Position limit switches FCR are designed and
manufactured according to IEC international
standard and EN European regulations .
Any improper installation or any tampering
of the device may cause serious personnel
injury or property damage, therefore, the
installation and maintenance must be
performed by specialized and authorized
personnel .
The use of this device is not allowed in
environment with a potentially explosive
atmosphere or in presence of corrosive
substances and in salt spray .
The FCR limit switches rotary gear position
are used to control several handling systems:
• Bridge cranes: the limit switch controls the
operating system, for example a PLC, and
allows the bridge crane to slow down or
stop .
• Hoists: the limit switch is used to stop the
hoist whenever it reaches a limit position .
They are suitable for use in industrial
environment with machinery monitoring and
protection purpose .
Rev . 2
EN
instruction manual
