TPI HotPod Installation

HotPod™ Installation
I R
NSTALLATION EQUIREMENTS
• F S L
OLLOW ALL TATE AND
• E H P ™
ACH OT OD MUST BE SUPPLIED WITH A DEDICATED
120- AC . U
VOLT CIRCUIT
• F ONLY
OR INDOOR USE WITH
• M
INIMUM SPACE TO COMBUSTIBLE MATERIAL
C L (F
HOOSE OCATION IGURE
1. Install HotPod™ in horizontal position ONLY.
2. Select a 14" (35.6 cm) section of duct that is a MINIMUM of 4
feet (122 cm) from outlet register.
• Select section so that you can insert male crimped end into
inlet side of the HotPod™.
• Discharge end must point toward outlet register (arrows
show air flow direction).
• Position wiring enclosure to allow permanent access to the
wiring compartment.
I H P ™
NSTALL OT OD
1. Remove 14" (35.6 cm) section of duct.
F R M D
OR IGID ETAL UCT
• Crimp ends of the duct as needed to provide male ends
for insertion into the HotPod™.
• Fasten with a minimum of 3 sheet metal screws at both
ends and within 1.5" (3.8 cm) of the end of the housing.
F F D
OR LEXIBLE UCT
• Attach flexible duct directly to HotPod™ housing using
approved connection methods.
2. Support HotPod on both ends with duct hangers or
™
perforated straps. Vibration reduction is recommended.
F 1
IGURE
A. Cut out 14" (35.6 cm)
B. MINIMUM 4 ft (122 cm)
from outlet register
C. Wiring cover
D. Fasten w/ 3 sheet metal
screws both ends
I W
NSTALL IRING
Install a 24-VAC heating and cooling thermostat.
• Place thermostat in the designated room on wall opposite
from outlet register.
• Follow thermostat manufacturer's instructions.
Use 4-strand thermostat wire, 20ga. minimum.
.
OCAL CODES
15-
14 .
SE GA COPPER WIRE MINIMUM
6" .
ROUND DUCTWORK
- 1" (2.5
CM
1)
E. Insert male crimped end
F. IMPORTANT: 1" (2.5 cm)
from combustible material
G. Crimp the cut end
H. Add vibration-damped
supports at both ends
W
ARNING
R
EMOVE POWER FROM
D
O NOT ENERGIZE CIRCUIT UNTIL ALL CONNECTIONS ARE MADE AND
H P ™
OT OD
AMP
F 1440-
OR
.
IMPORTANT: To avoid short cycling, please try it at 720 watts
first. (Figure 3)
).
1. Remove wiring cover. Following all local codes, connect 120
VAC, 15 amp dedicated circuit. Provide strain relief for all
wiring.
A. Black/hot wire to "L1 in" terminal.
B. White/neutral wire to "NEUTL." terminal. Be sure Brown
and White HotPod™ wires are on "HEATER NEUTL."
C. Green or ground wire to green housing ground screw.
2. Connect thermostat wire to circuit board.
D. Red/hot wire to "R" terminal.
E. White/heating wire to "W" terminal.
F. Yellow or green, cooling/fan wire to "Y/G" terminal.
G. Blue/common wire to "C" terminal when applicable.
F 2
IGURE
1440 W
F 720-
OR WATT OUTPUT
3. Attach 120 VAC and thermostat wires as shown in Figure 2.
In addition move the Brown HotPod™ wire:
A. Loosen "HEATER NEUTL" terminal; remove Brown wire;
re-tighten terminal.
B. Fasten Brown wire to "SPARE" terminal.
F
IGURE
720 W
ATTS
T
EST
1. Apply power to the 120 VAC circuit.
2. Turn room thermostat to maximum heat. Check for
HotPod™ Fan and Heater operation.
• If there is no heat output at the outlet register, remove the
120 VAC power immediately. Re-check all connections in
the HotPod electrical enclosure.
• Have a qualified electrician use volt-ohmmeter to check
voltage supply from 120 VAC circuit.
Note: You may notice a slight odor the first time you use HotPod™.
This is normal as the heat oxidizes coatings used to protect metal
surfaces. Odor will dissipate after several uses.
© 2010 TPI Corporation, PATENT PENDING
PID PN 600555
120 VAC
CIRCUIT SELECTED
WIRING ENCLOSURE IS CLOSED AFTER INSTALLATION
(5,000 . .
WATT OUTPUT B T U
ATTS
(2,500 . . .) F
B T U
3
.
.
.) F 2
IGURE
3
IGURE
