SERVICE MANUAL
Ver.1.0 2001.1
System
Type
Active Subwoofer (magnetically shielded design)
Speaker unit
Woofer: 20 cm dia. (8 in.), cone type
Amplifier section
Continuous RMS output :
Canadian model (0.8%) 50W
European model (DIN) 50 W
Other models (0.8%) 50 W
Reproduction frequency range
28 Hz – 200 Hz
High frequency cut-off frequency
50 Hz – 200 Hz
Phase selector
NORMAL, REVERSE
Inputs
Input jacks
LINE IN: input pin jack
SPEAKER IN: input terminals
Output jacks
SPEAKER OUT: output terminals
Sony Corporation
9-873-806-11
2001A0900-1
Audio Entertainment Group
© 2001. 1
General Engineering Dept.
SA-WM20
SPECIFICATION
General
Power requirements
Canadian model: 120 V AC, 60 Hz
European model: 230 V AC, 50/60 Hz
Power consumption
50 W
Dimensions
Approx. 270 x 325 x 385 mm
(10
3
/
x 12
7
/
x 15
4
8
Mass
10 kg (22 lb 1oz)
Supplied accessories
Foot pads (4)
Audio connecting cord (1 phono plug – 1 phono
1
plug), 2 m (6 ft 6
Speaker cords, 2.5 m (8 ft 2
Design and specifications are subject to change
without notice.
US Model
Canadian Model
AEP Model
UK Model
E Model
1
/
in.) (w/h/d)
4
/
in.) (1)
2
1
/
in.) (2)
2
ACTIVE SUBWOOFER
1

Advertisement

Table of Contents
loading

Related Manuals for Sony SA-WM20

Summary of Contents for Sony SA-WM20

  • Page 1 SA-WM20 SERVICE MANUAL US Model Canadian Model Ver.1.0 2001.1 AEP Model UK Model E Model SPECIFICATION System General Type Power requirements Active Subwoofer (magnetically shielded design) Canadian model: 120 V AC, 60 Hz European model: 230 V AC, 50/60 Hz Speaker unit Woofer: 20 cm dia.

  • Page 2: Table Of Contents

    CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU PUBLISHED BY SONY.

  • Page 3: General

    SA-WM20 SECTION 1 SECTION 2 GENERAL DIAGRAMS • Location of controls THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. – Front view (a part) – (In addition to this, the necessary note is printed in each block.) For printed wiring boards.

  • Page 4: Printed Wiring Board

    SA-WM20 2-2. PRINTED WIRING BOARD • See page 3 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D101 D102 D103 D104 D301 D302 D303 D304 D401 D402 D403 D404 IC101 IC102 Q301 Q302 Q303 There are a few cases that the part isn’t mounted in Q304 model is printed on diagram.

  • Page 5: Schematic Diagram

    SA-WM20 2-3. SCHEMATIC DIAGRAM...

  • Page 6: Exploded View

    SA-WM20 SENTION 3 EXPLODED VIEWS NOTE: 3-2. AMP SECTION • -XX and -X mean standardized parts, so they • Items marked “*” are not stocked since they The components identified by mark 0 or dotted line with mark may have some difference from the original are seldom required for routine service.

  • Page 7: Electrical Parts List

    SA-WM20 SECTION 4 CONTROL MAIN ELECTRICAL PARTS LIST NOTE: Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks • Due to standardization, replacements in the • COILS When indicating parts by reference number, parts list may be different from the parts uH: µH...
  • Page 8 SA-WM20 MAIN SWITCH POWER IC Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R308 1-215-868-00 METAL OXIDE D103 8-719-991-33 DIODE 1SS133T-77 D104 8-719-991-33 DIODE 1SS133T-77 R309 1-249-433-11 CARBON 1/4W D301 8-719-991-33 DIODE 1SS133T-77 R310 1-249-433-11 CARBON...
  • Page 9 SA-WM20 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks MISCELLANEOUS ************** 0 T1 1-435-879-11 TRANSFORMER, POWER (US,MX,CA) 0 T1 1-435-880-11 TRANSFORMER, POWER (AEP,UK,MY,SP) 0 T1 1-435-881-11 TRANSFORMER, POWER (E) ************************************************************* ACCESSORIES & PACKING MATERIALS ******************************* 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
  • Page 10 SA-WM20 Ref. No. REVISION HISTORY Part No. Description Remarks Ref. No. Part No. Description Remarks Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page.
