Wiring
Having correctly identified the wiring from your existing light fitting,connect to the quick fit connection block in the
•
following way:
Check that...
•
You have correctly identified the wires.
•
The connections are tight.
Microwave Movement Sensor
•
This product is fitted with a microwave movement sensor. Please see the additional instruction leaflet for
detailed operating instructions. Please note that the sensor is already installed inside the product.
Care and Safety
•
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could
damage the finish.
•
For your safety, always switch off the supply before cleaning.
WWW.saxbylighting.com
•
No loose strands have been left
out of the terminals.
Iss .2 26/01/2019
Saxby lighting. BH23 3PE
Instruction leaflet
Broco Flush MW
78586
Advertisement
Table of Contents
Summary of Contents for Saxby Lighting Broco Flush MW
- Page 1 Wiring Instruction leaflet Having correctly identified the wiring from your existing light fitting,connect to the quick fit connection block in the • following way: Broco Flush MW 78586 Check that... • You have correctly identified the wires. • No loose strands have been left out of the terminals.
- Page 2 Layout Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Please retain these instructions for future reference. • Plan the desired layout of these fittings carefully, ensuring the cables will reach the distances each light fitting.
